| Ref | Part Number | Description |
|---|
| 2 |
01550-0625A |
BOLT (6X25) Price: $2.37 |
| 3 |
09169-06074 |
WASHER (6.5X24X1.6) Price: $10.10 |
| 4 |
09320-11021 |
CUSHION (11.5X32X12.2) Price: $5.09 |
| 5 |
63112-34K00 |
COVER, REAR FENDER Price: $10.40 |
| 6 |
09409-08008 |
CLIP Price: $1.97 |
| 7 |
63122-34K00 |
SHIELD,REAR FENDER Price: $13.17 |
| 8 |
63123-34K00 |
SHIELD,REAR FENDER Price: $11.62 |
| 9 |
63124-34K00 |
SHIELD,REAR FENDER Price: $11.34 |
| 10 |
63127-34K00 |
SHIELD,REAR FENDER Price: $9.03 |
| 11 |
63128-34K00 |
SHIELD,REAR FENDER Price: $8.91 |
| 12 |
09111-06088 |
BOLT (6X13.5) Price: $2.46 |
| 13 |
09320-08029 |
CUSHION Price: $2.83 |
| 14 |
51553-15D40 |
CUSHION (50X42X2.0) Price: $9.12 |
| 15 |
03541-0620A |
SCREW Price: $2.58 |
| 16 |
33652-47F00 |
CUSHION,LICENSE PLATE(10X30X6 Price: $4.57 |
| 17 |
63251-34K03 |
COVER,REAR This part replaces 63251-34K00. Price: $22.24 |
| 18 |
63252-34K01 |
BOX,INNER This part replaces 63252-34K00. Price: $32.63 |
| 19 |
63253-34K01 |
LID,OUTER This part replaces 63253-34K00. Price: $28.45 |
| 20 |
63255-34K00 |
CUSHION,REAR COVER Price: $1.55 |
| 21 |
63256-34K00 |
CUSHION,REAR COMB NO.2 Price: $17.92 |
| 22 |
63371-34K00 |
BRACKET,REAR COVER Price: $23.91 |
| 23 |
93191-09F20 |
BAND,REAR BOX Price: $13.66 |
| 24 |
09111-06088 |
BOLT (6X13.5) Price: $2.46 |
| 25 |
09320-08018 |
CUSHION (8X26X7) Price: $3.70 |
| 26 |
01550-0612A |
BOLT Price: $2.37 |
