| Ref | Part Number | Description |
|---|
| 1 |
17251-KE8-690 |
GROMMET, AIR CLEANER HOUSING Price: $3.26 |
| 3 |
63102-ZY3-010 |
SEAL, ENGINE COVER Price: $85.32 |
| 4 |
63107-ZY3-010 |
SEE PART DETAILS - PRI; BRACKET, HOOK Price: $44.66 |
| 5 |
63108-ZY3-000 |
DAMPER, HOOK Price: $7.16 |
| 6 |
63111-ZX2-C00ZA |
COVER, FR. *NHB14M* (AQUA MARINE SILVER METALLIC) Price: $50.46 |
| 6 |
63111-ZX2-C00ZC |
COVER, FR. *NH565* (GRAND PRIX WHITE) Price: $48.86 |
| 7 |
63119-ZX2-C00 |
SPRING, LOCK ADJUSTER Price: $4.02 |
| 11 |
90105-ZW9-000 |
BOLT, FLANGE (6X20) (ENGINE NO.) Price: $3.94 |
| 12 |
90109-ZY3-010 |
BOLT, COVER LOCK Price: $5.00 |
| 13 |
90133-ZY3-000 |
BOLT, SOCKET (6X16) Price: $3.84 |
| 14 |
90504-921-010 |
WASHER, PLAIN (6MM) Use from Frame SN 4800713. Price: $1.74 |
| 15 |
90507-ZY3-000 |
WASHER, PLAIN (12MM) Price: $3.06 |
| 16 |
91556-ZY3-000 |
COLLAR, DISTANCE (6.5X9X3) Price: $3.40 |
| 17 |
93911-141J0 |
SCREW, TAPPING (4X10) Price: $3.42 |
| 18 |
94002-06490-0S |
SEE PART DETAILS - PRI; NUT, HEX. (6MM) Price: $3.38 |
| 19 |
95551-20000 |
PLUG, BLIND (20MM) Price: $6.52 |
