| Ref | Part Number | Description |
|---|
| 2 |
90183-05042-00 |
NUT, SPRING Price: $1.00 |
| 3 |
90480-01559-00 |
GROMMET Price: $6.49 |
| 4 |
90167-05076-00 |
SCREW, TAPPING Price: $2.85 |
| 5 |
90464-04005-00 |
CLAMP Price: $5.49 |
| 6 |
90520-04019-00 |
DAMPER, PLATE Price: $0.90 |
| 7 |
1RC-2413B-02-00 |
EMBLEM This part replaces 1RC-2413B-01-00. Price: $22.99 |
| 8 |
B5U-2837N-00-00 |
GRILL, AIR INTAKE Price: $47.99 |
| 9 |
90167-05076-00 |
SCREW, TAPPING Price: $2.85 |
| 10 |
90480-01559-00 |
GROMMET Price: $6.49 |
| 11 |
B5U-2838N-00-00 |
DUCT 1 Price: $57.99 |
| 12 |
90167-05076-00 |
SCREW, TAPPING Price: $2.85 |
| 13 |
90183-05042-00 |
NUT, SPRING Price: $1.00 |
| 14 |
90269-06001-00 |
RIVET Price: $6.49 |
| 15 |
B5U-28345-00-00 |
MOLE 1 Price: $45.99 |
| 16 |
90269-06001-00 |
RIVET Price: $6.49 |
| 17 |
90183-05042-00 |
NUT, SPRING Price: $1.00 |
| 18 |
B5U-2842M-00-00 |
COVER 1 Price: $12.49 |
| 19 |
90269-06001-00 |
RIVET Price: $6.49 |
| 20 |
90183-05042-00 |
NUT, SPRING Price: $1.00 |
| 21 |
90387-06205-00 |
COLLAR Price: $8.49 |
| 22 |
90111-06175-00 |
BOLT,HEX. SOCKET BUT Price: $6.40 |
| 23 |
90109-06043-00 |
BOLT Price: $3.00 |
| 25 |
90183-05042-00 |
NUT, SPRING Price: $1.00 |
| 26 |
90480-01559-00 |
GROMMET Price: $6.49 |
| 27 |
90167-05076-00 |
SCREW, TAPPING Price: $2.85 |
| 28 |
90464-04005-00 |
CLAMP Price: $5.49 |
| 29 |
90520-04019-00 |
DAMPER, PLATE Price: $0.90 |
| 30 |
1RC-2413B-02-00 |
EMBLEM This part replaces 1RC-2413B-01-00. Price: $22.99 |
| 31 |
B5U-2837R-00-00 |
GRILL, AIR INTAKE Price: $46.99 |
| 32 |
90167-05076-00 |
SCREW, TAPPING Price: $2.85 |
| 33 |
90480-01559-00 |
GROMMET Price: $6.49 |
| 34 |
B5U-2838R-00-00 |
DUCT 2 Price: $45.99 |
| 35 |
90167-05076-00 |
SCREW, TAPPING Price: $2.85 |
| 36 |
90183-05042-00 |
NUT, SPRING Price: $1.00 |
| 37 |
90269-06001-00 |
RIVET Price: $6.49 |
| 38 |
B5U-28346-00-00 |
MOLE 2 Price: $45.99 |
| 39 |
90269-06001-00 |
RIVET Price: $6.49 |
| 40 |
90183-05042-00 |
NUT, SPRING Price: $1.00 |
| 41 |
B5U-2842N-00-00 |
COVER 2 Price: $12.49 |
| 42 |
90269-06001-00 |
RIVET Price: $6.49 |
| 43 |
90183-05042-00 |
NUT, SPRING Price: $1.00 |
| 44 |
90387-06205-00 |
COLLAR Price: $8.49 |
| 45 |
90111-06175-00 |
BOLT,HEX. SOCKET BUT Price: $6.40 |
| 46 |
90109-06043-00 |
BOLT Price: $3.00 |
| 47 |
B5U-241B1-00-00 |
COVER, TANK Price: $22.99 |
| 48 |
90269-06001-00 |
RIVET Price: $6.49 |
| 49 |
90520-10039-00 |
DAMPER, PLATE Price: $1.55 |
