| Ref | Part Number | Description |
|---|
| 1 |
12216-ZE2-300 |
CLIP, VALVE GUIDE (Honda Code 2089597). Price: $2.36 |
| 1 |
28101KGF910 |
GEAR, STARTER DRIVEN (13T/54T) Price: Call Us |
| 2 |
15332-ZY1-000 |
GUIDE, OIL (S,L) Price: $10.50 |
| 2 |
28102KGF910 |
SHAFT, STARTER REDUCTION Price: Call Us |
| 3 |
19210-ZW9-A32 |
SEE PART DETAILS - PRI; IMPELLER, PUMP (UL) Price: $21.50 |
| 3 |
28110KGF910 |
GEAR COMP., STARTING CLUTCH (59T) Price: Call Us |
| 4 |
19215-ZW9-020 |
SEE PART DETAILS - PRI; HOUSING ASSY., IMPELLER Price: $66.52 |
| 4 |
31200KTF981 |
MOTOR ASSY., STARTING Price: Call Us |
| 5 |
19231-ZW9-000 |
COVER, IMPELLER Price: $11.60 |
| 5 |
31201KPCD51 |
BRUSH SET A, CARBON Price: Call Us |
| 6 |
19232-ZW9-000 |
GASKET, IMPELLER Price: $2.94 |
| 6 |
31202KPCD51 |
BRUSH SET B, CARBON Price: Call Us |
| 7 |
19240-ZY1-C00 |
SEE PART DETAILS - PRI; HOUSING, WATER PUMP (S,L) Price: $142.30 |
| 7 |
31203KPCD51 |
BRUSH HOLDER Price: Call Us |
| 8 |
19251-ZW9-000 |
TUBE, WATER (S) Price: $51.00 |
| 8 |
31204MEW921 |
SPRING, CARBON BRUSH Price: Call Us |
| 9 |
19253-ZW9-000 |
RING, WATER TUBE SEAL Price: $5.24 |
| 9 |
31205KPCD51 |
BOLT SET Price: Call Us |
| 10 |
24311-ZY1-C00 |
SEE PART DETAILS - PRI; ROD B, SHIFT (S) Price: $31.76 |
| 10 |
31206MEW921 |
BOLT, TERMINAL Price: Call Us |
| 11 |
24312-ZV7-000 |
JOINT, SHIFT ROD Price: $19.72 |
| 11 |
31207HP5601 |
RING Price: Call Us |
| 12 |
24320-ZW9-000 |
ROD A, SHIFT (S) Price: $30.96 |
| 12 |
31208MEW921 |
INSULATOR Price: Call Us |
| 13 |
24341-ZY1-C00 |
SEE PART DETAILS - PRI; ROD, PUSH Price: $27.12 |
| 13 |
31209MEW921 |
STOPPER, TERMINAL Price: Call Us |
| 14 |
31210MEW921 |
WASHER Price: Call Us |
| 14 |
41112-ZY1-C00 |
SEE PART DETAILS - PRI; SHAFT, VERTICAL (S) Price: $340.96 |
| 15 |
32413KTF980 |
CABLE, STARTER BATTERY EARTH Price: Call Us |
| 15 |
41116-ZW9-A30 |
SLINGER, OIL (UL) Price: $15.62 |
| 16 |
41131-ZY1-000 |
GEAR, PINION Price: $69.36 |
| 16 |
90071MB0000 |
NUT-WASHER, 6MM Price: Call Us |
| 17 |
41135-ZY1-000 |
WASHER A, THRUST BEARING Price: $9.74 |
| 17 |
91309425003 |
O-RING, 24.4X3.1 (ARAI) Price: Call Us |
| 18 |
41136-ZY1-010 |
WASHER B, THRUST BEARING Price: $8.84 |
| 18 |
41137-ZY1-010 |
WASHER C, THRUST BEARING Price: $8.84 |
| 18 |
91320MB0000 |
O-RING Price: Call Us |
| 19 |
90102-ZW9-000 |
BOLT, FLANGE (6X12) Use from Frame SN 1005249. Price: $2.90 |
| 19 |
91540S30003 |
CLIP, HARNESS BAND (NATURAL) (151.5MM) Price: Call Us |
| 20 |
90105-ZW9-000 |
BOLT, FLANGE (6X20) (ENGINE NO.) Price: $3.94 |
| 20 |
938920501208 |
SCREW-WASHER, 5X12 Price: Call Us |
| 21 |
90121-ZW9-000 |
BOLT-WASHER (6X50) Price: $4.18 |
| 22 |
90515-ZW9-000 |
PLATE, WATER TUBE SETTING Price: $4.60 |
| 23 |
90752-ZW9-A30 |
KEY, WOODRUFF Price: $3.14 |
| 24 |
91052-ZV4-003 |
BEARING, NEEDLE (15X21X12) Price: $15.30 |
| 25 |
91251-ZW9-003 |
SEAL, WATER (15X24X5) Price: $6.54 |
| 26 |
91253-ZW9-003 |
SEAL, WATER (6MM) Price: $11.66 |
| 27 |
91301-ZG3-000 |
O-RING (42.2X2.4) (Honda Code 3621125). Price: $3.10 |
| 28 |
91351-ZW9-000 |
O-RING, WATER PUMP HOUSING Price: $9.68 |
| 29 |
94001-06490-0S |
SEE PART DETAILS - PRI; NUT, HEX. (6MM) Price: $2.82 |
| 30 |
94540-08018 |
E-RING (8MM) Price: $5.42 |
| 31 |
91151-VD6-851 |
ROLLER (2.5X11.8) Price: $1.78 |
| 31 |
96220-25118 |
ROLLER (2.5X11.8) Price: $0.84 |
