| Ref | Part Number | Description |
|---|
| 1 |
61X-14711-02-00 |
MUFFLER 1 Price: $485.99 |
| 2 |
6K8-51129-00-00 |
NIPPLE Price: $12.99 |
| 3 |
6M6-14718-01-8S |
PROTECTOR, MUFFLER 1 Price: $56.99 |
| 4 |
97013-06025-00 |
BOLT Price: $1.60 |
| 5 |
92990-06600-00 |
WASHER, PLATE This part replaces 92903-06600-00. Price: $2.85 |
| 6 |
6M6-14739-A2-00 |
GASKET, MUFFLER DAMPER 1 Price: $12.49 |
| 7 |
61X-14613-A1-00 |
GASKET, EXHAUST PIPE Price: $27.49 |
| 8 |
97013-08035-00 |
BOLT Price: $6.49 |
| 9 |
92990-08600-00 |
WASHER, PLATE This part replaces 92903-08600-00. Price: $2.70 |
| 10 |
61L-14712-00-00 |
RING,JOINT Price: $372.99 |
| 11 |
6K8-51129-00-00 |
NIPPLE Price: $12.99 |
| 12 |
90340-08002-00 |
PLUG, STRAIGHT SCREW Price: $12.75 |
| 13 |
90430-08003-00 |
GASKET Price: $1.55 |
| 14 |
97513-08590-00 |
BOLT, WITH WASHER This part replaces 97013-08090-00. Price: $5.55 |
| 15 |
92990-08600-00 |
WASHER, PLATE This part replaces 92903-08600-00. Price: $2.70 |
| 16 |
97013-08025-00 |
BOLT, KICK CRANK Price: $9.49 |
| 17 |
92990-08600-00 |
WASHER, PLATE This part replaces 92903-08600-00. Price: $2.70 |
| 18 |
6R7-14749-A1-00 |
GASKET, MUFFLER DAMPER 2 Price: $14.49 |
| 19 |
90445-14M11-00 |
HOSE This part replaces 90445-14M29-00. Price: $17.99 |
| 20 |
6E5-24378-00-00 |
PIPE, JOINT 3 Price: $21.15 |
| 21 |
90445-14M11-00 |
HOSE This part replaces 90445-14M29-00. Price: $17.99 |
| 22 |
90445-14M22-00 |
HOSE (L1300) This part replaces 90445-14M33-00. Price: $53.99 |
| 23 |
90465-10098-00 |
CLAMP This part replaces 90465-11M10-00. Price: $2.70 |
| 24 |
90445-14M03-00 |
HOSE This part replaces 90445-14M06-00. Price: $32.99 |
| 25 |
90450-14M05-00 |
HOSE CLAMP ASSY Price: $19.49 |
| 26 |
6R7-14721-00-8S |
MUFFLER 2 Price: $368.49 |
| 27 |
6R7-14485-00-00 |
PIPE, JOINT Price: $11.99 |
| 28 |
6R7-14753-00-8S |
SILENCER, EXHAUST Price: $204.99 |
| 29 |
6R7-15761-00-00 |
SEAL, RUBBER 1 Price: $27.49 |
| 30 |
97013-06020-00 |
BOLT Price: $1.55 |
| 31 |
92990-06600-00 |
WASHER, PLATE This part replaces 92903-06600-00. Price: $2.85 |
| 32 |
6R7-14785-00-8S |
DIFFUSER Price: $105.99 |
| 33 |
6R7-14755-A0-00 |
GASKET, SILENCER Price: $18.49 |
| 34 |
6R7-41113-00-8S |
OUTER COVER, EXHAUST Price: $109.99 |
| 35 |
6R7-41114-A0-00 |
GASKET, EXHAUST OUTER COVER Price: $22.49 |
| 36 |
97D95-06016-00 |
BOLT, HEXAGON DEEP R This part replaces 97095-06016-00. Price: $2.76 |
| 37 |
92990-06600-00 |
WASHER, PLATE This part replaces 92995-06600-00. Price: $2.85 |
| 38 |
97513-06530-00 |
BOLT W/WASHER (63M) This part replaces 90119-06MA1-00. Price: $4.49 |
| 39 |
61L-14615-00-00 |
JOINT, EXHAUST 1 Price: $100.49 |
| 40 |
61L-14625-00-00 |
JOINT, EXHAUST 2 This part replaces 61L-14625-A0-00. Price: $76.99 |
| 41 |
90460-90M11-00 |
CLAMP, HOSE Price: $57.49 |
| 42 |
90460-70M16-00 |
CLAMP, HOSE Price: $43.99 |
| 43 |
6M6-14771-00-00 |
STAY, MUFFLER 1 This part replaces 6M6-14771-00-94. Price: $98.99 |
| 44 |
90105-10M49-00 |
BOLT, FLANGE Price: $13.49 |
| 45 |
90105-10M88-00 |
BOLT, FLANGE Price: $3.99 |
| 46 |
90119-10M17-00 |
BOLT, WITH WASHER Price: $9.99 |
| 47 |
6BA-6413S-01-00 |
LABEL, COMPETITION This part replaces 6BA-6413S-00-00. Price: $9.99 |
| 48 |
64V-14752-00-00 |
PIPE, OUTLET Price: $181.49 |
| 49 |
90460-64M15-00 |
CLAMP, HOSE Price: $31.99 |
