| Ref | Part Number | Description |
|---|
| 1 |
21100-40822 |
GEAR Price: $790.31 |
| 2 |
09103-14010 |
BOLT (14X28) Price: $18.39 |
| 3 |
21200-40891 |
GEAR Price: $590.62 |
| 4 |
09160-25074 |
WASHER (25X52X2.5) Price: $9.67 |
| 5 |
09263-35013 |
BEARING (35X40X39.8) Price: $43.30 |
| 6 |
21411-06J10 |
HUB Price: $173.72 |
| 7 |
21471-24F00 |
SEAT,WAVE WASHER Price: $17.62 |
| 9 |
21441-31J00 |
PLATE,CLUTCH DRIVE NO.1 (T:3. Price: $30.68 |
| 10 |
21442-31J00 |
PLATE,CLUTCH DRIVE NO.2 (T:3. Price: $30.68 |
| 11 |
21452-31J00 |
PLATE,CLUTCH DRIVEN NO.2 (T:2 Price: $15.93 |
| 12 |
21451-24F00 |
PLATE,CLUTCH DRIVEN NO.1 (T:2 Price: $14.32 |
| 13 |
21462-31J10 |
DISC,CLUTCH PRESSURE Price: $106.83 |
| 14 |
21414-31J00 |
PLATE,STOPPER Price: $20.99 |
| 15 |
09160-25056 |
WASHER (25X50X2.5) Price: $14.34 |
| 16 |
09159-24010 |
NUT Price: $16.09 |
| 17 |
09164-24008 |
WASHER (24.2X35X2.7) Price: $4.83 |
| 18 |
21413-06J10 |
SPRING Price: $6.79 |
| 19 |
09181-25223 |
SHIM (25X38X1) Price: $3.91 |
| 20 |
21412-31J00 |
BOLT,CLUTCH SPRING Price: $4.45 |
| 21 |
23110-24F00 |
ROD,CLUTCH (L:195.5) Price: $28.24 |
| 22 |
23111-40H00 |
ROD Price: $22.20 |
| 23 |
23121-41G00 |
PIECE,CLUTCH PUSH Price: $52.95 |
| 24 |
23120-41810 |
CAMSHAFT SET Price: $224.80 |
| 25 |
09280-21008 |
O RING (D:2.5,ID:21) Price: $2.30 |
| 26 |
09282-10012 |
SEAL,OIL (10X20X6) Price: $9.72 |
| 27 |
09285-10004 |
SEAL,OIL (10X17X5) Price: $4.10 |
| 28 |
23125-48G00 |
SPRING,CLUTCH RELEASE RETURN Price: $4.28 |
| 29 |
23271-48G10 |
ARM Price: $98.42 |
| 30 |
24741-20A00 |
RETAINER, SHIFT CAM BEARING Price: $3.29 |
| 31 |
09126-06011 |
SCREW (6X12) Price: $2.45 |
| 32 |
09134-06015 |
SCREW (6X73) Price: $8.39 |
| 33 |
09160-10020 |
WASHER (10.5X24X1.0) Price: $2.18 |
| 34 |
09160-15045 |
WASHER (15.5X28X1) Price: $4.75 |
| 35 |
09263-15003 |
BEARING (15X28X2) Price: $10.10 |
| 36 |
09283-06005 |
OIL SEAL (6X18X5) Price: $11.86 |
| 37 |
01547-0620A |
BOLT Price: $2.45 |
| 38 |
08310-0006A |
NUT Price: $2.22 |
