| Ref | Part Number | Description |
|---|
| 1 |
06440-KZ4-J40 |
SPOKE SET, FR. (240MM) Price: $5.64 |
| 2 |
38517-MGE-003 |
CLAMP, ABS WIRE (D12) Price: $3.11 |
| 3 |
38520-MKE-A51 |
SENSOR, FR. WHEEL SPEED Price: $215.29 |
| 4 |
38525-MKE-A51 |
CLIP, WIRE Price: $4.76 |
| 5 |
42714-KA3-710 |
CAP, VALVE Price: $12.67 |
| 6 |
42717-329-000 |
CAP, RIM HOLE Price: $5.27 |
| 7 |
44301-MEN-000 |
AXLE, FR. WHEEL Price: $61.95 |
| 8 |
44311-MKE-A60 |
COLLAR, L. FR. WHEEL Price: $21.16 |
| 9 |
44312-KRN-A30 |
COLLAR, R. FR. WHEEL Price: $23.29 |
| 10 |
44515-MKE-A50 |
RING, FR. PULSER Price: $33.09 |
| 11 |
44620-MAC-680 |
COLLAR, FR. DISTANCE Price: $25.25 |
| 12 |
44635-MAC-680 |
HUB SUB-ASSY., FR. WHEEL Price: $201.13 |
| 13 |
44650-MKE-A50 |
WHEEL SUB-ASSY., FR. Price: $945.33 |
| 14 |
44701-MKE-A51 |
RIM, FR. WHEEL (21X1.60) Price: $311.75 |
| 15 |
44711-MKE-A52 |
TIRE, FR. (80/100-21M/C 51P) (IRC) This part replaces 44711-MKE-A51. Price: $136.95 |
| 16 |
44712-KAE-025 |
TUBE, TIRE (3.00-21) This part replaces 44712-KAE-015. Price: $47.84 |
| 17 |
44713-KZZ-901 |
FLAP, TIRE (IRC) Price: $3.69 |
| 18 |
45351-MKE-A50 |
DISK, FR. BRAKE Price: $315.56 |
| 19 |
51614-MKE-A50ZA |
COVER, FR. DISK *NH1* (BLACK) Price: $37.33 |
| 20 |
90105-MAC-680 |
BOLT, DISK (6X19) Price: $6.27 |
| 21 |
90114-MAC-780 |
BOLT, FR. DISK COVER (FOR RR.) Price: $3.89 |
| 22 |
90117-MJP-G60 |
BOLT, FLANGE (6X14) Price: $2.53 |
| 23 |
90131-MGE-000 |
BOLT, TORX (5X8) Price: $3.55 |
| 24 |
90301-473-003 |
NUT, U (6MM) NUT, FLANGE (6MM) Price: $5.11 |
| 25 |
90301-KZ4-J40 |
NUT, FR. AXLE Price: $20.42 |
| 26 |
90650-KZZ-J80 |
BAND, RUBBER (35MM) Price: $3.67 |
| 27 |
91062-MAC-681 |
BEARING, RADIAL BALL (6904) Price: $29.75 |
