| Ref | Part Number | Description |
|---|
| 1 |
1XB-2580A-00-00 |
MASTER CYLINDER SUB ASSY 2 Price: $273.99 |
| 2 |
1WS-25807-00-00 |
CYLINDER KIT, MASTER Price: $34.99 |
| 3 |
5VS-25852-00-00 |
CAP, RESERVOIR Price: $30.99 |
| 4 |
5VS-25855-00-00 |
BUSH, DIAPHRAGM Price: $17.99 |
| 5 |
20S-25854-00-00 |
DIAPHRAGM, RESERVOIR Price: $31.99 |
| 6 |
5VS-2589H-00-00 |
SCREW Price: $4.45 |
| 7 |
5VS-2589F-00-00 |
BOLT, LEVER Price: $15.49 |
| 8 |
95617-06100-00 |
NUT, S/L Price: $2.90 |
| 9 |
5VS-83922-00-00 |
LEVER 2 Price: $92.99 |
| 10 |
5VS-26332-00-00 |
BOLT Price: $4.95 |
| 11 |
5VS-25867-00-00 |
BRACKET, MASTER CYLINDER Price: $39.99 |
| 12 |
B67-83980-02-00 |
FRONT STOP SWITCH AS This part replaces B67-83980-01-00. Price: $145.99 |
| 13 |
98517-04012-00 |
SCREW,PANHEAD This part replaces 98502-04012-00. Price: $4.20 |
| 14 |
92990-04100-00 |
WASHER, SPRING This part replaces 92902-04100-00. Price: $0.95 |
| 15 |
92990-04600-00 |
WASHER, PLATE This part replaces 92902-04600-00. Price: $0.99 |
| 16 |
B67-2584A-00-00 |
BRAKE HOSE ASSY Price: $215.99 |
| 17 |
90464-14003-00 |
CLAMP Price: $39.99 |
| 18 |
B67-2584B-00-00 |
HOSE, BRAKE Price: $260.99 |
| 19 |
90464-07014-00 |
CLAMP Price: $4.00 |
| 20 |
90401-10172-00 |
BOLT, UNION Price: $6.49 |
| 21 |
90401-10049-00 |
BOLT, UNION Price: $4.65 |
| 22 |
90430-10005-00 |
GASKET Price: $9.49 |
| 23 |
2CR-25875-00-00 |
HOLDER, BRAKE HOSE 1 Price: $14.49 |
| 24 |
2CR-25876-00-00 |
HOLDER, BRAKE HOSE 2 Price: $12.99 |
| 25 |
B67-2612E-00-00 |
BRACKET Price: $19.49 |
| 26 |
92017-06016-00 |
BOLT, HEX. SOCKET BUTTON Price: $9.49 |
| 27 |
95027-06014-00 |
BOLT, FLANGE Price: $0.95 |
| 28 |
2CR-2612K-00-00 |
BRACKET 2 Price: $8.49 |
| 29 |
2CR-2612L-00-00 |
BRACKET 3 Price: $5.99 |
| 30 |
B67-2612M-00-00 |
BRACKET 4 Price: $9.99 |
| 31 |
90269-08005-00 |
RIVET Price: $5.49 |
| 32 |
97D95-06016-00 |
BOLT, HEXAGON DEEP R This part replaces 97022-06016-00. Price: $2.76 |
| 33 |
95022-06030-00 |
BOLT, FLANGE Price: $1.80 |
| 34 |
5H0-8235Y-M0-00 |
DAMPER This part replaces 3YL-12232-00-00. Price: $7.49 |
| 35 |
2CR-2622F-00-00 |
DAMPER, LOCATING 1 Price: $1.60 |
| 36 |
90110-06219-00 |
BOLT, HEXAGON SOCKET HEAD This part replaces 90110-06218-00. Price: $8.49 |
| 37 |
B67-23377-00-00 |
BRACKET, HORN Price: $33.99 |
| 38 |
90461-08031-00 |
CLAMP This part replaces 90461-10132-00. Price: $9.49 |
| 39 |
92012-06012-00 |
BOLT, BUTTON HEAD Price: $4.70 |
