| Ref | Part Number | Description |
|---|
| 1 |
90119-089UT-00 |
BOLT, WITH WASHER Price: $7.99 |
| 2 |
90119-089UT-00 |
BOLT, WITH WASHER Price: $7.99 |
| 3 |
6CS-81845-11-00 |
PLATE Price: $88.49 |
| 4 |
6S5-81942-21-00 |
COVER Price: $88.49 |
| 5 |
60E-83627-00-00 |
LABEL, CAUTION 7 Price: $4.99 |
| 6 |
6ME-8591A-00-00 |
ENGINE CONTROL UNIT ASSY Price: $2,544.49 |
| 7 |
95814-06012-00 |
BOLT, FLANGE Price: $2.49 |
| 8 |
6EY-8591S-00-00 |
GROMMET, ECU Price: $24.99 |
| 9 |
6ET-81948-00-00 |
BRACKET Price: $27.49 |
| 10 |
6EX-82170-02-00 |
FUSE BOX ASSY Price: $266.49 |
| 11 |
67F-82151-30-00 |
FUSE (3A) Price: $5.49 |
| 12 |
67F-82151-40-00 |
FUSE (10A) Price: $7.10 |
| 13 |
5JJ-82151-20-00 |
FUSE (20A-BL) This part replaces 67F-82151-00-00. Price: $8.49 |
| 14 |
5JJ-82151-60-00 |
FUSE (30A-BL) This part replaces 67F-82151-10-00. Price: $8.49 |
| 15 |
6EX-82151-00-00 |
FUSE (50A) Price: $3.99 |
| 16 |
6EX-8195A-00-00 |
RELAY ASSY Price: $20.99 |
| 17 |
6EX-2812A-00-00 |
PULLER, FUSE Price: $1.49 |
| 18 |
90119-06311-00 |
BOLT, WITH WASHER Price: $1.99 |
| 19 |
6A0-82317-01-00 |
DAMPER, IGNITION C Price: $7.10 |
| 20 |
90387-06119-00 |
COLLAR Price: $4.80 |
| 21 |
6ET-82576-00-00 |
SENSOR, LEAN ANGLE Price: $67.49 |
| 22 |
97780-60025-00 |
SCREW, TAPPING Price: $5.99 |
| 23 |
90387-06M05-00 |
COLLAR Price: $8.70 |
| 24 |
6JP-82115-00-00 |
WIRE, PLUS LEAD Price: $47.99 |
| 25 |
6CS-82117-00-00 |
WIRE, LEAD Price: $72.99 |
| 26 |
1B7-81940-00-00 |
STARTER RELAY ASSY (2768102-A) Price: $137.99 |
| 27 |
97E95-06612-00 |
BOLT, HEXAGON W/W DE Price: $1.49 |
| 28 |
6CS-81953-00-00 |
STAY, RELAY Price: $5.99 |
| 29 |
95814-06012-00 |
BOLT, FLANGE Price: $2.49 |
| 30 |
6MD-8259L-02-00 |
WIRE HARNESS ASSY 1 Price: $1,038.49 |
| 31 |
6EM-82599-00-00 |
COVER, CONNECTER Price: $6.85 |
| 32 |
90465-14M66-00 |
CLAMP Price: $4.95 |
| 33 |
F4P-U828H-00-00 |
TRIM, 1 Price: $6.99 |
| 34 |
F1W-U828M-00-00 |
BASE, CLAMP Price: $5.99 |
| 35 |
90267-48802-00 |
RIVET, BLIND Price: $6.99 |
