| Ref | Part Number | Description |
|---|
| 1 |
35340-MGS-D31 |
SWITCH ASSY., FR. STOP Price: $22.42 |
| 2 |
45125-KYJ-D21 |
HOSE, FR. BRAKE Price: $27.82 |
| 3 |
45155-KYJ-900 |
CLAMP, FR. BRAKE HOSE Price: $2.11 |
| 4 |
45156-KYJ-900 |
STAY, BRAKE HOSE CLAMP Price: $17.78 |
| 5 |
45157-KYJ-900 |
CLAMP B, FR. BRAKE HOSE Price: $2.11 |
| 6 |
45504-410-003 |
BOOT Price: $14.75 |
| 8 |
45512-MA6-006 |
PROTECTOR Price: $5.38 |
| 9 |
45513-HR0-305 |
CAP, MASTER CYLINDER (COO) Price: $5.22 |
| 10 |
45517-166-006 |
HOLDER, MASTER CYLINDER Price: $16.42 |
| 11 |
45520-GE2-006 |
DIAPHRAGM Price: $11.27 |
| 12 |
45521-K21-901 |
PLATE, DIAPHRAGM Price: $2.60 |
| 14 |
53174-116-670 |
PLUG, HANDLE LEVER BRACKET Price: $2.84 |
| 15 |
53175-K26-305 |
LEVER, R. HANDLEBAR (COO) Price: $19.98 |
| 16 |
90114-166-006 |
BOLT, HANDLE LEVER PIVOT Price: $8.16 |
| 17 |
90145-MS9-612 |
BOLT, OIL (10X22) (SAGA) Price: $9.20 |
| 18 |
90545-300-000 |
WASHER, OIL BOLT Price: $5.02 |
| 20 |
93600-04012-0G |
SCREW, FLAT (4X12) Price: $0.95 |
| 21 |
93893-04012-07 |
SCREW-WASHER (4X12) Price: $1.40 |
| 22 |
94050-06000 |
NUT, FLANGE (6MM) Price: $0.68 |
| 23 |
96001-06012-07 |
BOLT, FLANGE (6X12) (L. SIDE ONLY) Price: $1.88 |
