| Ref | Part Number | Description |
|---|
| 1 |
5GH-16611-10-00 |
CLUTCH HOUSING COMP. Price: $442.99 |
| 2 |
5GH-16620-01-00 |
CLUTCH CARRIER ASSY Price: $334.99 |
| 3 |
5GH-16626-00-00 |
SPRING, CLUTCH WEIGHT 1 Price: $15.49 |
| 4 |
5GH-16664-00-00 |
BEARING, ONE WAY Price: $161.99 |
| 5 |
93410-46079-00 |
CIRCLIP Price: $9.49 |
| 6 |
93315-21813-00 |
BEARING Price: $39.99 |
| 7 |
93450-24062-00 |
CIRCLIP, INNER Price: $4.10 |
| 8 |
90179-22005-00 |
NUT Price: $31.99 |
| 9 |
5GH-17606-01-00 |
PRIMARY SLIDING SHEAVE COMP. Price: $254.99 |
| 10 |
5GH-17620-01-00 |
PRIMARY SLIDING SHEAVE COMP. Price: $328.99 |
| 11 |
93101-31167-00 |
OIL SEAL Price: $19.49 |
| 12 |
5KM-17632-00-00 |
WEIGHT Price: $16.49 |
| 13 |
5GH-17623-00-00 |
CAM Price: $82.99 |
| 14 |
4WV-17653-00-00 |
SLIDER Price: $8.49 |
| 15 |
4WV-17654-01-00 |
SPACER 1 Price: $7.49 |
| 16 |
93211-52001-00 |
O-RING Price: $34.99 |
| 17 |
5GH-17639-00-00 |
STOPPER Price: $33.99 |
| 18 |
90157-04006-00 |
SCREW, PAN HEAD Price: $5.49 |
| 20 |
90387-1914K-00 |
COLLAR Price: $135.99 |
| 21 |
5GH-17641-11-00 |
V-BELT Price: $165.99 |
| 22 |
5UH-17611-00-00 |
SHEAVE, PRIMARY FIXED Price: $171.99 |
| 23 |
90201-190T7-00 |
WASHER, PLATE Price: $9.49 |
| 24 |
90179-16005-00 |
NUT Price: $12.49 |
| 25 |
5GH-17660-10-00 |
SECONDARY FIXED SHEAVE COMP. Price: $373.99 |
| 26 |
BB5-17670-00-00 |
SECONDARY SLIDING SHEAVE Price: $225.99 |
| 27 |
93104-41119-00 |
OIL SEAL Price: $18.49 |
| 28 |
93210-44545-00 |
O-RING Price: $14.49 |
| 29 |
4CW-17664-00-00 |
PIN, GUIDE Price: $8.49 |
| 30 |
90501-626L9-00 |
SPRING, COMPRESSION Price: $66.99 |
| 31 |
4WV-17684-00-00 |
SEAT, SECONDARY SPRING Price: $62.99 |
| 32 |
4WV-17644-00-00 |
SEAT, SPRING Price: $32.99 |
| 33 |
90170-36279-00 |
NUT Price: $18.49 |
