| Ref | Part Number | Description |
|---|
| 1 |
1SM-16111-10-00 |
GEAR, PRIMARY DRIVE Price: $51.99 |
| 2 |
90387-19008-00 |
COLLAR Price: $11.49 |
| 3 |
90208-16019-00 |
WASHER, CONICAL SPRING Price: $9.49 |
| 4 |
90170-16003-00 |
NUT Price: $3.85 |
| 5 |
1SM-16150-00-00 |
PRIMARY DRIVEN GEAR COMP. Price: $453.99 |
| 6 |
1SM-16154-00-00 |
PLATE, THRUST 1 Price: $7.49 |
| 7 |
2GB-16371-00-00 |
BOSS, CLUTCH Price: $143.99 |
| 10 |
1SM-16351-00-00 |
PLATE, PRESSURE 1 Price: $74.99 |
| 12 |
90159-06029-00 |
SCREW, WITH WASHER Price: $9.49 |
| 13 |
1SM-16383-00-00 |
SPRING, CUSHION Price: $15.49 |
| 15 |
93310-225N0-00 |
BEARING Price: $49.99 |
| 16 |
1SM-16181-00-00 |
SPACER 1 Price: $37.99 |
| 17 |
90201-204K8-00 |
WASHER, PLATE This part replaces 90201-20611-00. Price: $11.49 |
| 18 |
90215-16289-00 |
WASHER, LOCK Price: $7.99 |
| 19 |
90170-16326-00 |
NUT Price: $14.49 |
| 20 |
1SM-16356-00-00 |
ROD, PUSH 1 Price: $52.99 |
| 21 |
93340-21008-00 |
BEARING Price: $32.99 |
| 22 |
90201-080H1-00 |
WASHER, PLATE Price: $5.49 |
| 23 |
93440-07182-00 |
CIRCLIP Price: $4.10 |
| 24 |
93511-32027-00 |
BALL Price: $9.49 |
| 25 |
1SM-16357-00-00 |
ROD, PUSH 2 Price: $49.99 |
| 26 |
B29-16381-00-00 |
PUSH LEVER COMP. Price: $93.99 |
| 27 |
93317-11096-00 |
BEARING Price: $25.99 |
| 28 |
93102-10008-00 |
OIL SEAL Price: $6.49 |
| 29 |
99009-18500-00 |
CIRCLIP Price: $0.65 |
