| Ref | Part Number | Description |
|---|
| 3 |
371-27114-00-00 |
STOPPER, MAIN STAND Price: $8.49 |
| 4 |
278-27114-00-00 |
STOPPER, MAIN STAND Price: $9.49 |
| 5 |
B5C-24741-00-00 |
PAD, SEAT Price: $4.25 |
| 6 |
B5U-24217-00-00 |
COVER Price: $35.99 |
| 7 |
3P6-24780-00-00 |
SEAT LOCK ASSY Price: $42.99 |
| 8 |
95702-06500-00 |
NUT, WITH WASHER Price: $2.60 |
| 9 |
B5U-24708-00-00 |
SEAT BRACKET ASSY Price: $46.99 |
| 10 |
2PP-24723-00-00 |
DAMPER, SEAT Price: $8.49 |
| 13 |
4GL-27114-00-00 |
STOPPER, MAIN STAND Price: $17.99 |
| 14 |
2PP-2478X-01-00 |
BRACKET, SEAT LOCK Price: $78.99 |
| 15 |
90111-06053-00 |
BOLT,HEX. SOCKET BUT Price: $6.49 |
| 16 |
B5C-24797-00-00 |
BRACKET, SEAT BACK Price: $15.49 |
| 17 |
B5C-2479L-00-00 |
BRACKET, SEAT BACK 2 Price: $15.49 |
| 18 |
B5U-24780-00-00 |
SEAT LOCK ASSY Price: $24.99 |
| 19 |
95702-06500-00 |
NUT, WITH WASHER Price: $2.60 |
| 20 |
B5U-2479D-00-00 |
WIRE, SEAT LOCK 2 Price: $8.99 |
| 21 |
B5U-2471P-00-00 |
PLATE, COVER Price: $16.49 |
| 22 |
3CK-W2470-00-00 |
SEAT LOCK ASSY This part replaces 2TV-W2470-00-00. Price: $91.99 |
| 23 |
B5U-2479K-00-00 |
PLATE, LOCK Price: $12.49 |
| 24 |
92012-06010-00 |
BOLT, BUTTON HEAD Price: $4.65 |
| 25 |
92012-05010-00 |
BOLT, BUTTON HEAD Price: $9.49 |
| 26 |
2PP-2475H-00-00 |
BRACKET, SEAT LEVER 1 Price: $15.49 |
| 27 |
95817-06010-00 |
BOLT,FLANGE This part replaces 90105-06057-00. Price: $5.49 |
| 28 |
2PP-2475J-00-00 |
BRACKET, SEAT LEVER 2 Price: $5.49 |
| 29 |
92012-06012-00 |
BOLT, BUTTON HEAD This part replaces 90111-06065-00. Price: $4.70 |
| 30 |
BAP-28100-00-00 |
TOOL KIT Price: $17.49 |
| 31 |
2H7-28151-00-00 |
GRIP, DRIVER Price: $7.49 |
| 32 |
2GV-28152-00-00 |
DRIVER Price: $5.99 |
| 33 |
23P-28164-00-00 |
WRENCH, HEXAGON 8 Price: $3.65 |
