| Ref | Part Number | Description |
|---|
| 1 |
35340-MGS-D31 |
SWITCH ASSY., FR. STOP Price: $22.42 |
| 2 |
38526-KZZ-J80 |
STAY, FR. SPEED SENSOR WIRE Price: $7.95 |
| 3 |
45124-KZZ-J81 |
HOSE A, FR. BRAKE Price: $49.20 |
| 4 |
45127-KZZ-J81 |
HOSE D, FR. BRAKE Price: $109.25 |
| 5 |
45181-KZZ-J80 |
CLAMP, FR. BRAKE HOSE Price: $7.75 |
| 6 |
45182-KZZ-J80 |
CLAMP B, FR. BRAKE HOSE Price: $8.45 |
| 7 |
45504-410-003 |
BOOT Price: $14.75 |
| 8 |
45510-KZZ-305 |
MASTER CYLINDER SUB-ASSY., FR. BRAKE (COO) (NISSIN) Price: $90.20 |
| 9 |
45513-HA2-006 |
CAP, MASTER CYLINDER Price: $33.38 |
| 10 |
45517-166-006 |
HOLDER, MASTER CYLINDER Price: $16.42 |
| 11 |
45518-MEN-J01 |
SEPARATOR Price: $8.20 |
| 12 |
45520-MG7-006 |
DIAPHRAGM Price: $12.84 |
| 13 |
45521-HA2-006 |
PLATE, DIAPHRAGM Price: $13.15 |
| 14 |
45523-KA3-731 |
RING Price: $3.35 |
| 15 |
45530-471-831 |
MASTER CYLINDER SET Price: $48.07 |
| 16 |
53175-KZZ-305 |
LEVER, R. HANDLEBAR (COO) Price: $13.04 |
| 18 |
90013-GHB-610 |
BOLT, FLANGE (6X12) (L. SIDE ONLY) Price: $2.65 |
| 19 |
90013-GHB-660 |
BOLT, FLANGE (6X22) Price: $2.65 |
| 20 |
90013-GHB-670 |
BOLT, FLANGE (6X25) Price: $2.65 |
| 22 |
90114-KZZ-J01 |
BOLT, LEVER PIVOT Price: $12.93 |
| 23 |
90145-MS9-612 |
BOLT, OIL (10X22) (SAGA) Price: $9.20 |
| 24 |
90545-300-000 |
WASHER, OIL BOLT Price: $5.02 |
| 25 |
90651-MA5-671 |
CIRCLIP Price: $3.35 |
| 26 |
93600-04012-0G |
SCREW, FLAT (4X12) Price: $0.95 |
| 27 |
93893-04012-07 |
SCREW-WASHER (4X12) Price: $1.40 |
| 28 |
94050-06000 |
NUT, FLANGE (6MM) Price: $0.68 |
| 29 |
96001-06018-07 |
BOLT, FLANGE (6X18) Price: $1.44 |
