| Ref | Part Number | Description |
|---|
| 1 |
12216-ZE2-300 |
CLIP, VALVE GUIDE (Honda Code 2089597). Price: $2.36 |
| 2 |
15332-ZW9-000 |
GUIDE, OIL (S,L) Price: $11.06 |
| 3 |
19210-ZW9-013 |
SEE PART DETAILS - PRI; IMPELLER, PUMP (S,L) Price: $27.48 |
| 4 |
19215-ZW9-020 |
SEE PART DETAILS - PRI; HOUSING ASSY., IMPELLER Price: $66.52 |
| 5 |
19231-ZW9-000 |
COVER, IMPELLER Price: $11.60 |
| 6 |
19232-ZW9-000 |
GASKET, IMPELLER Price: $2.94 |
| 7 |
19240-ZW9-C00 |
SEE PART DETAILS - PRI; HOUSING, WATER PUMP (S,L) Price: $93.20 |
| 8 |
19243-ZW9-000 |
GROMMET, WATER PUMP HOUSING Price: $8.86 |
| 9 |
19251-ZW9-630 |
TUBE, WATER (L) Price: $56.86 |
| 10 |
19253-ZW9-000 |
RING, WATER TUBE SEAL Price: $5.24 |
| 11 |
24311-ZY1-C10 |
ROD B, SHIFT (L) Price: $31.76 |
| 12 |
24312-ZV7-000 |
JOINT, SHIFT ROD Price: $19.72 |
| 13 |
24320-ZW9-630 |
ROD A, SHIFT (L) Price: $34.92 |
| 14 |
24341-ZY1-C00 |
SEE PART DETAILS - PRI; ROD, PUSH Price: $27.12 |
| 15 |
41112-ZW9-C10 |
SEE PART DETAILS - PRI; SHAFT, VERTICAL (L) Price: $276.30 |
| 16 |
41116-ZW9-000 |
SLINGER, OIL (S,L) Price: $13.20 |
| 17 |
41131-ZW9-000 |
GEAR, PINION Price: $67.88 |
| 18 |
41135-ZW9-000 |
WASHER A, THRUST BEARING Price: $9.40 |
| 19 |
41136-ZW9-000 |
WASHER B, THRUST BEARING Price: $9.40 |
| 19 |
41137-ZW9-000 |
WASHER C, THRUST BEARING Price: $9.40 |
| 20 |
90102-ZW9-000 |
BOLT, FLANGE (6X12) Use from Frame SN 1005249. Price: $2.90 |
| 21 |
90105-ZW9-000 |
BOLT, FLANGE (6X20) (ENGINE NO.) Price: $3.94 |
| 22 |
90121-ZW9-000 |
BOLT-WASHER (6X50) Price: $4.18 |
| 23 |
90515-ZW9-000 |
PLATE, WATER TUBE SETTING Price: $4.60 |
| 24 |
90752-ZW9-000 |
KEY, WOODRUFF Price: $4.16 |
| 25 |
91252-ZV1-003 |
SEE PART DETAILS - PRI; SEAL, WATER (13MM) (ARAI) Price: $10.94 |
| 26 |
91253-ZW9-003 |
SEAL, WATER (6MM) Price: $11.66 |
| 27 |
91301-ZG3-000 |
O-RING (42.2X2.4) (Honda Code 3621125). Price: $3.10 |
| 28 |
91351-ZW9-000 |
O-RING, WATER PUMP HOUSING Price: $9.68 |
| 29 |
94001-06490-0S |
SEE PART DETAILS - PRI; NUT, HEX. (6MM) Price: $2.82 |
| 30 |
94540-08018 |
E-RING (8MM) Price: $5.42 |
| 31 |
96220-25118 |
ROLLER (2.5X11.8) Price: $0.84 |
