AIR INTAKE PIPE (GSX-R1000A)
Parts (16)
| Ref | Part Number | Description |
|---|---|---|
| 2 | 63115-37H00 | CUSHION (10X10X1) Price: $4.62 |
| 4 | 94430-17K00 | PIPE,AIR INTAKE,L Price: $77.87 |
| 5 | 63115-37H00 | CUSHION (10X10X1) Price: $4.62 |
| 7 | 09148-05052 | NUT (M5) Price: $4.10 |
| 8 | 09320-08028 | CUSHION (8X26X7) Price: $3.70 |
| 9 | 09111-06106 | BOLT (6X12) Price: $2.58 |
| 13 | 73415-70A00 | PAD (8X20X2) Price: $1.75 |
| 16 | 73415-70A00 | PAD (8X20X2) Price: $1.75 |
| 17 | 94414-17K00 | COVER,INTAKE UPPER,R Price: $10.11 |
| 18 | 94415-17K00 | COVER,INTAKE UPPER,L Price: $10.11 |
| 19 | 09132-05050 | SCREW (5X12) Price: $2.15 |
| 20 | 36930-82010 | COVER (30X100X2) Price: $3.88 |
| 22 | 94633-31J00 | CUSHION (16X30X3.5) Price: $2.84 |
| 23 | 09321-06036 | CUSHION Price: $1.84 |
| 24 | 09409-06314-5PK | CLIP This part replaces 09409-06314. Price: $3.23 |
| 25 | 03541-0412B | SCREW Price: $1.50 |
