| Ref | Part Number | Description |
|---|
| 1 |
625575 |
HARNESS,MAIN-AMBUSH Price: $737.45 |
| 2 |
35211G01 |
FUSE BLOCK (6 POSITION) Price: $59.63 |
| 3 |
00379G2 |
PAN HEAD PHILLIPS SCREW, #10-24 X 1 1/4 Price: $0.99 |
| 4 |
00559G5 |
FLAT WASHER, #10 Price: $2.99 |
| 5 |
14390G10 |
LOCK NUT, #10-24 Price: $1.99 |
| 6 |
631022 |
CONTROLLER,PARALLEL HYBRID-ASSY Price: Call Us |
| 7 |
624223 |
CONTROLLER,BOBBY BOX This part replaces 631020. Price: $1,397.36 |
| 8 |
631240 |
CONTROLLER LABEL Price: Call Us |
| 9 |
631238 |
CONTROLLER SOFTWARE (NOT ILLUSTRATED) Price: Call Us |
| 10 |
00559G5 |
FLAT WASHER, #10 Price: $2.99 |
| 11 |
14390G10 |
LOCK NUT, #10-24 Price: $1.99 |
| 12 |
N/S |
NON-SERVICEABLE PART Price: Call Us |
| 13 |
625720 |
BRKT,BOBBY BOX Price: $7.45 |
| 14 |
13437G9 |
FLANGED HEX HEAD BOLT, 1/4-20X3/4 Price: $1.99 |
| 15 |
01110G01 |
FLAT WASHER, 1/4" Price: $0.99 |
| 16 |
14390G4 |
LOCK NUT,1/4"-20 Price: $1.99 |
| 18 |
672554 |
SVC,48V PWRS,W/ HW This part replaces 612711. Price: $54.99 |
| 19 |
13437G9 |
FLANGED HEX HEAD BOLT, 1/4-20X3/4 Price: $1.99 |
| 20 |
01110G01 |
FLAT WASHER, 1/4" Price: $0.99 |
| 21 |
14390G4 |
LOCK NUT,1/4"-20 Price: $1.99 |
| 23 |
624626 |
BRKT,CON-SOL-RES BB Not Available Price: |
| 24 |
N/S |
NON-SERVICEABLE PART Price: Call Us |
| 25 |
00439G4 |
HEX HEAD BOLT, 5/16-18 X 1 1/2 Price: $2.99 |
| 26 |
00642G8 |
FLAT WASHER, 5/16" Price: $2.99 |
| 27 |
01109G01 |
LOCK NUT, 5/16-18 Price: $0.99 |
| 29 |
629619 |
SHIELD ELECTRONICS Price: $132.08 |
| 31 |
00559G5 |
FLAT WASHER, #10 Price: $2.99 |
| 32 |
14390G10 |
LOCK NUT, #10-24 Price: $1.99 |
| 34 |
628113 |
FUSE HOLDER,BIG,SLOW BLOW Price: $121.04 |
| 35 |
00379G2 |
PAN HEAD PHILLIPS SCREW, #10-24 X 1 1/4 Price: $0.99 |
| 36 |
00559G5 |
FLAT WASHER, #10 Price: $2.99 |
| 37 |
14390G10 |
LOCK NUT, #10-24 Price: $1.99 |
| 38 |
626864 |
FUSE,BIG,SLOW BLOW Price: $14.09 |
| 41 |
626606 |
OBS-DC/DC CONVERTER 20A Price: $258.70 |
| 42 |
N/S |
NON-SERVICEABLE PART Price: Call Us |
| 43 |
00559G5 |
FLAT WASHER, #10 Price: $2.99 |
| 44 |
14390G10 |
LOCK NUT, #10-24 Price: $1.99 |
| 46 |
71078G01 |
POWER OUTLET (12V) Price: $27.99 |
| 47 |
600543 |
BUTTON HEAD TORX BOLT, M4-0.75X12 Price: $0.99 |
| 48 |
602053 |
LOCK NUT, M4- 0.7 Price: $3.99 |
| 50 |
31539G1 |
NYLON CLAMP, 15.5" LG Price: $1.99 |
| 59 |
625106 |
PLATE,48V GAS,PWRTRN,ELEC,MOUNT Not Available Price: |
| 64 |
672554 |
SVC,48V PWRS,W/ HW This part replaces 612711. Price: $54.99 |
| 65 |
N/S |
NON-SERVICEABLE PART Price: Call Us |
| 66 |
11027G2 |
FLANGED LOCK NUT, 1/4"-20 Price: $0.99 |
| 67 |
12914G2 |
TERMINAL-FASTON-3/8 X 13/32 Not Available Price: |
| 68 |
00650G7 |
FLAT WASHER, 1/4 Price: Call Us |
| 69 |
00565G7 |
OBS-WASHER-LK-SP #1/4 Price: Call Us |
| 70 |
00532G1 |
HEX NUT,1/4-20 Price: $1.99 |
| 72 |
27739G01 |
VOLTAGE REGULATOR Price: $91.99 |
| 73 |
00415G2 |
HEX HEAD BOLT, 1/4-20 X 1 1/4 Price: $2.99 |
| 74 |
11027G2 |
FLANGED LOCK NUT, 1/4"-20 Price: $0.99 |
| 76 |
628792 |
FUSE,AUTOMOTIVE,ATO,58V,15A Not Available Price: |
| 77 |
629104 |
FUSE,AUTOMOTIVE,ATO,58V,4A Not Available Price: |
| 78 |
672657 |
FUSE, AUTO, ATO, 58V, 10A This part replaces 628840. Price: $5.99 |
| 79 |
628081 |
FUSE,AUTOMOTIVE,ATO,58V,5A Price: $20.99 |
