| Ref | Part Number | Description |
|---|
| 1 |
1DK-F7481-01-00 |
BOARD, FOOTREST Price: $37.99 |
| 2 |
90119-06821-00 |
BOLT, WITH WASHER Price: $1.80 |
| 3 |
90183-05827-00 |
NUT, SPRING This part replaces 90183-05816-00. Price: $1.65 |
| 4 |
97707-50016-00 |
SCREW, TRUSS HEAD TAPPING Price: $1.85 |
| 5 |
90111-06831-00 |
BOLT, HEX. SOCKET BUTTON Price: $1.35 |
| 6 |
5HK-F7475-00-00 |
CAP 1 Price: $0.80 |
| 7 |
1DK-XF711-01-00 |
STAND, MAIN This part replaces 1DK-XF711-00-00. Price: $114.99 |
| 8 |
5S9-F7114-01-00 |
STOPPER, MAIN STAND Price: $1.85 |
| 9 |
1DK-F7114-00-00 |
STOPPER, MAIN STAND Price: $2.70 |
| 10 |
52S-F7112-00-00 |
SHAFT, MAIN STAND Price: $14.49 |
| 11 |
99001-12600-00 |
CIRCLIP Price: $6.20 |
| 12 |
90506-28804-00 |
SPRING, TENSION Price: $3.75 |
| 13 |
90506-36800-00 |
SPRING, TENSION Price: $5.49 |
| 14 |
90445-21808-00 |
HOSE Price: $2.35 |
| 15 |
52S-F7254-00-00 |
HOOK Price: $3.50 |
| 16 |
2LD-F7311-00-33 |
STAND, SIDE This part replaces 2LD-F7311-00-00. Price: $34.99 |
| 17 |
90109-10005-00 |
BOLT Price: $3.20 |
| 18 |
90185-10120-00 |
NUT, SELF-LOCKING This part replaces 90185-10110-00. Price: $6.49 |
| 19 |
90506-23811-00 |
SPRING, TENSION Price: $3.60 |
| 20 |
90506-16806-00 |
SPRING, TENSION Price: $2.05 |
| 21 |
5CA-F7114-00-00 |
STOPPER, MAIN STAND Price: $1.30 |
| 22 |
1DK-F7431-10-00 |
FOOTREST, REAR 1 This part replaces 1DK-F7431-03-00. Price: $29.99 |
| 23 |
1DK-F7441-10-00 |
FOOTREST, This part replaces 1DK-F7441-03-00. Price: $34.99 |
| 24 |
92012-08020-00 |
BOLT, BUTTON HEAD Price: $2.80 |
| 25 |
1DK-F7453-00-00 |
COVER 1 Price: $3.35 |
