| Ref | Part Number | Description |
|---|
| 1 |
653676 |
ACCEL PEDAL,SUSPENDED-ASSY Not Available This part replaces 626804. Price: |
| 2 |
626140 |
ACCELERATOR PEDAL BRACKET Not Available Price: |
| 3 |
600019 |
ROTARY POSITION SENSOR Not Available Price: |
| 4 |
600543 |
BUTTON HEAD TORX BOLT, M4-0.75X12 Price: $0.99 |
| 6 |
612889 |
PEDAL SWITCH, MOLEX Price: $33.99 |
| 7 |
620030 |
SOCKET HEAD SCREW, M5-0.8 X 10 Price: $1.99 |
| 9 |
600683 |
SPIROLL PIN, 4MMX26MM, HEAVY DUTY Not Available Price: |
| 10 |
626142 |
ACCELERATOR PIVOT SHAFT Not Available Price: |
| 11 |
653205 |
TORSION SPRING, 4.5MM DIA This part replaces 613098. Price: $9.99 |
| 12 |
625731 |
FLANGED BUSHING, 16MM X 12MM Price: $12.99 |
| 13 |
604097 |
REBOUND BUMPER Price: $3.99 |
| 15 |
627846 |
SUSPENDED ACCELERATOR PEDAL Price: Call Us |
| 16 |
610529 |
ACCELERATOR PEDAL COVER Price: $14.99 |
| 18 |
N/S |
NON-SERVICEABLE PART Price: Call Us |
| 19 |
01110G01 |
FLAT WASHER, 1/4" Price: $0.99 |
| 20 |
14390G4 |
LOCK NUT,1/4"-20 Price: $1.99 |
| 22 |
626608 |
SPRING,ACCEL PEDAL,HELPER Price: $24.99 |
| 23 |
626714 |
CABLE,ACCEL PEDAL Price: $75.39 |
| 24 |
10386G2 |
CLEVIS PIN, 0.375 O.D X I.D 0.25 X 0.76 Price: $1.99 |
| 25 |
31539G1 |
NYLON CLAMP, 15.5" LG Price: $1.99 |
| 33 |
00415G2 |
HEX HEAD BOLT, 1/4-20 X 1 1/4 Price: $2.99 |
| 34 |
00559G7 |
FLAT WASHER, 1/4" Price: $0.99 |
| 35 |
75679G01 |
LEVER, CHOKE PIVOT* Price: $27.36 |
| 36 |
15944G1 |
BALL-BALL JOINT Not Available Price: |
| 37 |
00734G5 |
LOCK NUT, #10-32 Price: $0.99 |
| 38 |
75677G01 |
BUSHING, CHOKE LEVER Price: $10.57 |
| 39 |
23577G1 |
TORSION SPRING Price: $15.99 |
| 40 |
23726G7 |
SPACER, 0.298" Price: $0.99 |
| 41 |
14390G4 |
LOCK NUT,1/4"-20 Price: $1.99 |
| 43 |
75651G01 |
BRACKET, CABLE GOVR / CHOKE Price: $63.56 |
| 44 |
00566G2 |
LOCK WASHER (SPRING TYPE), 7/16 Price: $0.99 |
| 45 |
00462G7 |
HEX HEAD BOLT, 7/16-14 X 7/8 Price: $3.16 |
| 47 |
75650G01 |
LINK CHOKE Price: $18.99 |
| 49 |
75712G01 |
CHOKE CABLE* Price: $57.99 |
| 50 |
75675G01 |
CABLE, GOVERNOR Price: $46.79 |
| 52 |
75682G01 |
GOVERNOR LEVER ASSEMBLY Price: $257.04 |
| 53 |
75681G01 |
WELDMENT GOV. LEVER Price: $42.81 |
| 54 |
15944G1 |
BALL-BALL JOINT Not Available Price: |
| 55 |
00734G5 |
LOCK NUT, #10-32 Price: $0.99 |
| 56 |
14390G4 |
LOCK NUT,1/4"-20 Price: $1.99 |
| 57 |
22751G2 |
GOVERNOR BRACKET ASSY Price: $133.89 |
| 58 |
22752G1 |
GOVERNOR BRACKET Not Available Price: |
| 59 |
25274G1 |
GOVERNOR ROD Price: $71.99 |
| 60 |
22754G2 |
BUSHING FLIP LOK Not Available Price: |
| 62 |
23578G1 |
COMPRESSION SPRING, 9 LBS. / INCH Price: $1.99 |
| 63 |
22754G2 |
BUSHING FLIP LOK Not Available Price: |
| 64 |
23859G1 |
GOVERNOR ADJUSTER Price: $49.99 |
| 65 |
00526G4 |
HEX NUT, #10-32 Price: $1.99 |
| 66 |
71215G01 |
SET SCREW WITH PATCH LOCK, 1/4"-20X1/2 Price: $0.99 |
| 68 |
11845G5 |
CABLE CLIP, INSULATED Not Available Price: |
| 69 |
12064G3 |
PUSH NUT, 3/16 Price: $0.99 |
| 71 |
25653G01 |
BRKT ACCEL CABLE DIFF Price: $23.32 |
| 75 |
75832G01 |
RETAINER, WIRE AND TUBE, .375 Not Available Price: |
