| Ref | Part Number | Description |
|---|
| 1 |
06911-HL4-A01 |
BRG SET,NEEDLE Price: $24.16 |
| 2 |
12361-300-000 |
CAP, VALVE ADJ. This part replaces 12361-035-000. Price: $12.40 |
| 3 |
35600-HN7-003 |
SWITCH ASSY., NEUTRAL Price: $23.76 |
| 4 |
38510-HL4-F41 |
SENSOR, R. RR. WHEEL SPEED Price: $215.15 |
| 5 |
38515-HL4-F41 |
SENSOR, L. RR. WHEEL SPEED Price: $215.15 |
| 6 |
41100-HL4-A01 |
DIFFERENTIAL ASSY., RR. Price: $784.51 |
| 7 |
41111-HL4-A01 |
CASE, RR. DIFFERENTIAL Price: $116.40 |
| 8 |
41112-HL4-A01 |
CAP, RR. DIFFERENTIAL CASE Price: $48.16 |
| 9 |
41131-HL4-A01 |
CAM, FACE (68) (A) Price: $26.80 |
| 10 |
41132-HL4-A01 |
CAM, FACE (68) (B) Price: $29.96 |
| 11 |
41140-HL4-A01 |
FOLLOWER SET, CAM Price: $63.13 |
| 12 |
41151-HL4-A01 |
SHIM A (1.3) Price: $4.00 |
| 12 |
41152-HL4-A01 |
SHIM B (1.4) Price: $4.00 |
| 12 |
41153-HL4-A01 |
SHIM C (1.5) Price: $4.00 |
| 12 |
41154-HL4-A01 |
SHIM D (1.6) Price: $4.00 |
| 12 |
41155-HL4-A01 |
SHIM E (1.7) Price: $4.00 |
| 13 |
41161-HL4-A01 |
SPRING, DIFFERENTIAL SIDE CONED Price: $4.84 |
| 14 |
41300-HL4-AQ1 |
GEAR, RR. FINAL Price: $1,279.29 |
| 15 |
41305-HL4-A00 |
RING, STOPPER Price: $1.76 |
| 16 |
41311-HL4-AQ1 |
CASE SUB-ASSY., RR. Price: $126.49 |
| 17 |
41312-HL4-AQ1 |
COVER SUB-ASSY., RR. Price: $145.09 |
| 18 |
41330-HL4-A00 |
JOINT, RR. PINION Price: $38.78 |
| 19 |
41421-HL4-A00 |
GEAR, RR. PINION (16T) Price: $261.96 |
| 20 |
41431-HL4-A00 |
GEAR, RR. RING (54T) Price: $349.64 |
| 21 |
41447-HL4-A00 |
SHIM A, FINAL GEAR (0.64) Price: $3.02 |
| 21 |
41448-HL4-A00 |
SHIM B, FINAL GEAR (0.70) Price: $3.02 |
| 21 |
41449-HL4-A00 |
SHIM C, FINAL GEAR (0.76) Price: $3.02 |
| 21 |
41450-HL4-A00 |
SHIM D, FINAL GEAR (0.82) Price: $3.02 |
| 21 |
41451-HL4-A00 |
SHIM E, FINAL GEAR (0.88) Price: $3.02 |
| 21 |
41452-HL4-A00 |
SHIM F, FINAL GEAR (0.94) Price: $3.02 |
| 21 |
41453-HL4-A00 |
SHIM G, FINAL GEAR (1.00) Price: $3.02 |
| 21 |
41454-HL4-A00 |
SHIM H, FINAL GEAR (1.06) Price: $3.02 |
| 21 |
41455-HL4-A00 |
SHIM I, FINAL GEAR (1.12) Price: $3.02 |
| 21 |
41456-HL4-A00 |
SHIM J, FINAL GEAR (1.18) Price: $3.02 |
| 21 |
41457-HL4-A00 |
SHIM K, FINAL GEAR (1.24) Price: $3.02 |
| 21 |
41458-HL4-A00 |
SHIM L, FINAL GEAR (1.30) Price: $3.02 |
| 21 |
41459-HL4-A00 |
SHIM M, FINAL GEAR (1.36) Price: $3.02 |
| 21 |
41460-HL4-A00 |
SHIM N, FINAL GEAR (1.42) Price: $3.02 |
| 21 |
41461-HL4-A00 |
SHIM O, FINAL GEAR (1.48) Price: $3.02 |
| 21 |
41462-HL4-A00 |
SHIM P, FINAL GEAR (1.54) Price: $3.02 |
| 21 |
41463-HL4-A00 |
SHIM Q, FINAL GEAR (1.60) Price: $3.02 |
| 22 |
41450-MG9-000 |
SHIM A, PINION GEAR (1.32) Price: $8.20 |
| 22 |
41451-MG9-000 |
SHIM B, PINION GEAR (1.38) Price: $8.20 |
| 22 |
41452-MG9-000 |
SHIM C, PINION GEAR (1.44) Price: $8.20 |
| 22 |
41453-MG9-000 |
SHIM D, PINION GEAR (1.50) Price: $8.20 |
| 22 |
41454-MG9-000 |
SHIM E, PINION GEAR (1.56) Price: $8.20 |
| 22 |
41455-MG9-000 |
SHIM F, PINION GEAR (1.62) Price: $8.20 |
| 22 |
41456-MG9-000 |
SHIM G, PINION GEAR (1.68) Price: $8.20 |
| 23 |
41607-HL4-AK0 |
COLR, RR. DIFF LOCK Price: $32.20 |
| 24 |
41630-HL4-AK0 |
SHAFT COMP, RR. Price: $57.44 |
| 25 |
41710-HL4-AK0 |
STAY COMP, RR. Price: $22.78 |
| 26 |
41725-HL4-AQ0 |
COVER Price: $36.35 |
| 27 |
41726-HL4-AQ0 |
COVER Price: $36.35 |
| 28 |
41727-HL4-AK0 |
COVER RR. Price: $26.29 |
| 29 |
41803-HL4-AK0 |
SPG A, RR. DIFF LOCK Price: $1.04 |
| 30 |
41804-HL4-AK0 |
SPG B, RR. DIFF LOCK Price: $1.31 |
| 31 |
41805-HL4-AK0 |
STPR, RR. Price: $38.35 |
| 32 |
41827-HL4-A00 |
SLEEVE, RR. DIFFERENTIAL LOCK Price: $15.51 |
| 33 |
41850-HL4-AK0 |
SWINGARM COMP Price: $68.00 |
| 34 |
90010-ML0-720 |
BOLT, FLANGE (6X20) Price: $3.62 |
| 35 |
90104-HL4-A00 |
BOLT, FLANGE (10X23) Price: $30.08 |
| 36 |
90106-MM9-000 |
BOLT, FR. FENDER FIXING Price: $3.73 |
| 37 |
90109-371-000 |
BOLT, SEALING (8MM) Price: $3.09 |
| 38 |
90133-HP5-600 |
BOLT, FLANGE (8X27) Price: $3.05 |
| 39 |
90134-HP5-600 |
BOLT, FLANGE (10X35) Price: $4.40 |
| 40 |
90151-HL4-AK0 |
BOLT, FLG (10X188) Price: $4.04 |
| 41 |
90152-HL4-AK0 |
BOLT, FLG (10X200) Price: $4.27 |
| 42 |
90242-HL1-A00 |
NUT, LOCK (72MM) Price: $25.15 |
| 43 |
90305-HC0-770 |
NUT, SELF-LOCK (10MM) Price: $3.76 |
| 44 |
90443-KR0-000 |
WASHER, NEUTRAL SWITCH Price: $1.53 |
| 45 |
90471-580-000 |
WASHER (8MM) Price: $3.40 |
| 46 |
90601-ZG3-000 |
CLIP, PISTON PIN Price: $2.36 |
| 47 |
90652-HF7-003 |
JOINT, BREATHER TUBE Price: $11.53 |
| 48 |
90653-HC4-900 |
CLIP, SPLASH GUARD (Honda Code 3795994) Price: $0.67 |
| 49 |
90683-SA0-003 |
CLIP, WIRE HARNESS (25MM) Price: $10.40 |
| 50 |
91051-HL3-A01 |
BEARING, RADIAL BALL (63/28) Price: $89.42 |
| 50 |
91064-HL4-A01 |
BEARING, RADIAL BALL (63/28) Price: $37.85 |
| 51 |
91056-HL4-A01 |
BEARING, RADIAL BALL (6208) Price: $13.22 |
| 52 |
91057-HL4-A01 |
BEARING, RADIAL BALL (6008) Price: $11.16 |
| 53 |
91251-HL3-A01 |
OIL SEAL (36X75X8) Price: $7.96 |
| 54 |
91252-HL4-A01 |
OIL SEAL (24X32X5) Price: $5.69 |
| 55 |
91254-HL4-F43 |
OIL SEAL,53X70X7 Price: $8.62 |
| 56 |
91302-001-020 |
O-RING (30.8MM) (Honda Code 0001065) Price: $4.70 |
| 57 |
91306-MG3-000 |
O-RING (1.5X9.5) Price: $2.43 |
| 58 |
91312-KM9-003 |
O-RING (24X3) Price: $4.60 |
| 59 |
91352-GAZ-930 |
O-RING (8.5X1.5) (L. SIDE ONLY) Price: $2.65 |
| 60 |
91565-S3Y-003 |
CLIP, CONNECTOR Price: $7.23 |
| 61 |
95002-35000 |
CLIP, TUBE (C6.5) Price: $0.78 |
| 62 |
95005-35001-30M |
BULK HOSE, VACUUM (3.5X1000) (3.5X860) (BULK HOSE: 95005-35001-30M) Price: $10.45 |
| 63 |
95701-06016-08 |
BOLT, FLANGE (6X16) Price: $1.52 |
