| Ref | Part Number | Description |
|---|
| 1 |
8HX-23870-00-00 |
STEERING GATE COMP. Price: $1,294.99 |
| 2 |
8HG-23376-00-00 |
STOPPER Price: $12.49 |
| 3 |
8FA-24768-00-00 |
STOPPER Price: $7.49 |
| 4 |
8HV-23858-00-00 |
SPACER Price: $4.25 |
| 5 |
90201-10032-00 |
WASHER, PLATE Price: $1.25 |
| 6 |
8HG-238B6-01-00 |
COVER, MOTOR Price: $30.99 |
| 7 |
90102-08007-00 |
BOLT, WITH HOLE This part replaces 90102-08006-00. Price: $7.49 |
| 8 |
90109-063F1-00 |
BOLT Price: $3.10 |
| 9 |
JT1-83614-00-00 |
BRACKET Price: $28.99 |
| 10 |
98980-06016-00 |
SCREW, BIND This part replaces 98902-06016-00. Price: $9.49 |
| 11 |
90201-087H6-00 |
WASHER,PLATE Price: $2.60 |
| 12 |
95702-08500-00 |
NUT, WITH WASHER Price: $1.05 |
| 13 |
90105-08236-00 |
BOLT, FLANGE Price: $5.00 |
| 14 |
90201-08326-00 |
WASHER, PLATE Price: $9.49 |
| 15 |
90105-08239-00 |
BOLT, FLANGE Price: $2.70 |
| 16 |
8FA-2389E-00-00 |
LATCH Price: $14.49 |
| 17 |
95602-08200-00 |
NUT, SELF-LOCKING Price: $3.20 |
| 18 |
90462-10022-00 |
CLAMP Price: $6.49 |
| 19 |
90462-10035-00 |
CLAMP Price: $7.49 |
