| Ref | Part Number | Description |
|---|
| 1 |
52400-KSE-305 |
CUSHION ASSY., RR. (COO) This part replaces 52400-KSE-A71. Price: $994.11 |
| 2 |
52401-KSE-A31 |
SPRING, RR. SHOCK ABSORBER (49.0N/MM,5.0KGF/MM) (SHOWA) Price: $186.33 |
| 3 |
52410-KSE-305 |
DAMPER, RR. (COO) This part replaces 52410-KSE-A71. Price: $687.85 |
| 4 |
52421-KSE-A71 |
ROD, PISTON Price: $410.00 |
| 5 |
52422-MA0-003 |
ADJUSTER, SPRING Price: $44.84 |
| 6 |
52423-GBF-831 |
NUT, ADJUSTER Price: $24.51 |
| 7 |
52425-381-771 |
CAP, AIR VALVE Price: $6.35 |
| 8 |
52425-KSE-671 |
CASE, DAMPER Price: $385.35 |
| 9 |
52426-KSE-A71 |
ROD Price: $337.64 |
| 10 |
52427-GBF-831 |
RUBBER, STOPPER Price: $19.05 |
| 11 |
52428-KA4-741 |
CAP, CASE Price: $22.91 |
| 12 |
52429-KSE-A71 |
CASE, ROD GUIDE Price: $42.36 |
| 13 |
52431-MA0-771 |
RING, PISTON Price: $19.89 |
| 14 |
52432-GBF-831 |
O-RING (2.0X33.5) Price: $5.09 |
| 15 |
52434-KA3-681 |
O-RING (3.5X33.7) Price: $6.13 |
| 16 |
52435-MA0-771 |
RING, STOPPER Price: $5.67 |
| 17 |
52436-KSE-680 |
OIL SEAL SET Price: $15.22 |
| 18 |
52438-KA4-741 |
NUT, HEX. (12MM) Price: $3.62 |
| 19 |
52440-GBF-A01 |
ADJUSTER, COMPRESSION DAMPING FORCE Price: $57.42 |
| 20 |
52451-GBF-831 |
DIAPHRAGM Price: $18.53 |
| 21 |
52453-KSE-671 |
CAP, CHAMBER Price: $18.71 |
| 22 |
52455-GBF-831 |
STOPPER, SPRING SEAT Price: $6.33 |
| 23 |
52459-GBF-831 |
SEAT, SPRING Price: $25.53 |
| 24 |
52462-KSE-000 |
COLLAR D, CUSHION ARM Price: $8.85 |
| 25 |
52463-KSE-000 |
COLLAR B, CUSHION ARM Price: $9.96 |
| 26 |
52465-KSE-000 |
ARM SUB-ASSY., CUSHION Price: $266.91 |
| 27 |
52473-KSE-000 |
COLLAR A, CONNECTING ROD Price: $12.84 |
| 28 |
52473-KZ9-710 |
COLLAR, CUSHION CONNECTING ROD Price: $18.24 |
| 29 |
52479-KSE-000 |
ROD SUB-ASSY., CUSHION CONNECTING Price: $229.07 |
| 30 |
52486-GBF-830 |
COLLAR A, CUSHION (UPPER) Price: $9.09 |
| 31 |
52487-GBF-830 |
COLLAR B, CUSHION (UPPER) Price: $7.76 |
| 32 |
87516-KZ1-600 |
LABEL, RR. DAMPER WARNING Price: $7.70 |
| 34 |
90101-KK6-000 |
BOLT, FLANGE (10X85) Price: $8.31 |
| 35 |
90101-KSE-000 |
BOLT, FLANGE (10X105) Price: $8.82 |
| 36 |
90128-KSE-000 |
BOLT, FLANGE (10X67) Price: $9.60 |
| 37 |
90153-KSE-000 |
BOLT, LINK (10X73) Price: $7.47 |
| 38 |
90153-KZ4-710 |
BOLT, CUSHION (LOWER) (10X43.5) Price: $11.36 |
| 39 |
90304-GE8-003 |
NUT, U (10MM) NUT, SELF-LOCK (10MM) Price: $4.62 |
| 40 |
90306-KZ4-711 |
NUT, U (10MM) Price: $4.71 |
| 41 |
91071-KV3-005 |
BEARING, NEEDLE (KOYO) Price: $30.15 |
| 42 |
91072-KT7-003 |
BEARING, NEEDLE (17X24X20) (NTN) Price: $24.47 |
| 43 |
91074-KRN-711 |
BEARING, NEEDLE (19X26X13) Price: $10.31 |
| 44 |
91077-GS2-702 |
BEARING, NEEDLE (16X22X12) Price: $22.71 |
| 45 |
91262-KV3-831 |
DUST SEAL (17X24X5) (ARAI) Price: $7.78 |
| 46 |
91351-GS2-701 |
DUST SEAL, RR. CUSHION (UPPER) Price: $5.62 |
| 47 |
91351-KSE-003 |
DUST SEAL (19X26X3) Price: $3.65 |
