| Ref | Part Number | Description |
|---|
| 1 |
17270-KZZ-900 |
STAY, OIL CUP Price: $10.36 |
| 2 |
43310-KZZ-901 |
HOSE, RR. BRAKE Price: $40.80 |
| 3 |
43468-KZZ-J00 |
GUIDE, BRAKE HOSE Price: $2.82 |
| 4 |
43503-KS6-701 |
CONNECTOR, MASTER CYLINDER Price: $12.07 |
| 5 |
43504-MB2-006 |
BOOT Price: $12.16 |
| 6 |
43510-KZZ-305 |
MASTER CYLINDER SUB-ASSY., RR. BRAKE (COO) (NISSIN) Price: $71.53 |
| 7 |
43511-KW7-881 |
CUP, OIL (NISSIN) Price: $20.71 |
| 8 |
43512-KZZ-901 |
HOSE, RR. BRAKE MASTER CYLINDER Price: $10.56 |
| 9 |
43513-KTY-C01 |
CAP, MASTER CYLINDER Price: $6.85 |
| 10 |
43514-KS6-701 |
CLAMP, MASTER CYLINDER OIL HOSE Price: $15.89 |
| 11 |
43517-KS6-701 |
CIRCLIP, RR. MASTER CYLINDER (FOR FR.) Price: $4.80 |
| 12 |
43520-MJ6-315 |
PISTON SET, MASTER CYLINDER (NISSIN) Price: $54.98 |
| 13 |
43530-KZZ-901 |
ROD, PUSH Price: $12.96 |
| 14 |
45520-GW0-911 |
DIAPHRAGM Price: $9.15 |
| 15 |
45521-GW0-911 |
PLATE, DIAPHRAGM Price: $7.20 |
| 16 |
46182-MEL-D21 |
CIRCLIP Price: $2.22 |
| 17 |
46504-KV6-702 |
JOINT, BRAKE ROD Price: $9.85 |
| 18 |
90106-KGH-600 |
BOLT, BRAKE DISK (6X17) Price: $3.64 |
| 19 |
90140-KZZ-901 |
SCREW, FLAT (4X45) Price: $7.65 |
| 20 |
90145-MS9-612 |
BOLT, OIL (10X22) (SAGA) Price: $9.20 |
| 21 |
90545-300-000 |
WASHER, OIL BOLT Price: $5.02 |
| 22 |
91212-422-006 |
O-RING (14.8X2.4) Price: $2.93 |
| 23 |
93500-05016-0G |
SCREW, PAN (5X16) SCREW, PAN (4X20) Price: $0.95 |
| 24 |
93903-26380 |
SCREW, TAPPING (6X20) Price: $1.32 |
| 25 |
94002-080000S |
NUT,HEX 8MM Price: $1.37 |
| 26 |
94201-20120 |
PIN, COTTER (2.0X12) Price: $1.08 |
| 27 |
95015-54000 |
PIN D, JOINT Price: $5.33 |
