PILLION STEP
Parts (8)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 28333-300-000 | SPRING, KICK STARTER STOPPER Price: $3.55 |
| 2 | 50638-K97-T00 | PIN Price: $2.98 |
| 3 | 50718-K1Z-J10 | PLATE, R. PILLION STEP CLICK Price: $0.47 |
| 4 | 50719-K1Z-J10 | PLATE, L. PILLION STEP CLICK Price: $0.45 |
| 5 | 50730-K1Y-DF0 | ARM, R. PILLION STEP Price: $6.82 |
| 6 | 50740-K1Y-DF0 | ARM, L. PILLION STEP Price: $6.82 |
| 7 | 94101-06800 | WASHER, PLAIN (6MM) This part replaces 94101-06000. Price: $0.68 |
| 8 | 94251-05000 | PIN, LOCK (5MM) Price: $1.08 |
