| Ref | Part Number | Description |
|---|
| 1 |
B4J-K8507-01-00 |
RR. DOOR COMP. LH Price: $154.99 |
| 2 |
2HC-F17N1-00-00 |
LEVER, LATCH 1 Price: $8.49 |
| 3 |
B4J-F8465-00-00 |
BRACKET, ROTOR 1 Price: $43.99 |
| 4 |
90249-05801-00 |
PIN Price: $2.55 |
| 5 |
99080-04600-00 |
CLIP This part replaces 99002-04600-00. Price: $1.99 |
| 6 |
90111-06181-00 |
BOLT,HEX. SOCKET BUT Price: $1.50 |
| 7 |
B4J-F7277-00-00 |
ROD 1 Price: $4.10 |
| 10 |
90149-08805-00 |
SCREW Price: $1.20 |
| 11 |
90381-08001-00 |
BUSH, SOLID Price: $6.49 |
| 12 |
B4J-F1797-02-00 |
HINGE This part replaces B4J-F1797-01-00. Price: $14.49 |
| 13 |
90109-068C9-00 |
BOLT Price: $1.15 |
| 14 |
95604-06200-00 |
NUT, U FLANGE This part replaces 95602-06200-00. Price: $2.95 |
| 15 |
95817-08016-00 |
BOLT,FLANGE (JN5) This part replaces 95812-08016-00. Price: $5.49 |
| 16 |
B4J-F17G0-20-00 |
SIDE COVER COMP. 3 Price: $238.99 |
| 17 |
90183-062A1-00 |
NUT, SPRING Price: $2.20 |
| 18 |
90119-06226-00 |
BOLT, WITH WASHER Price: $2.80 |
| 19 |
B4J-K8571-00-00 |
PNL, DOOR RR, LH Price: $70.99 |
| 20 |
90338-05009-00 |
PLUG Price: $3.45 |
| 21 |
90183-062A1-00 |
NUT, SPRING Price: $2.20 |
| 22 |
90269-05073-00 |
RIVET Price: $2.70 |
| 23 |
90110-06090-00 |
BOLT, HEXAGON SOCKET HEAD Price: $5.49 |
| 24 |
B4J-K8508-01-00 |
RR. DOOR COMP. RH Price: $143.99 |
| 25 |
2HC-F17N1-00-00 |
LEVER, LATCH 1 Price: $8.49 |
| 26 |
B4J-F8466-00-00 |
BRACKET, ROTOR 2 Price: $43.99 |
| 27 |
90249-05801-00 |
PIN Price: $2.55 |
| 28 |
99080-04600-00 |
CLIP This part replaces 99002-04600-00. Price: $1.99 |
| 29 |
90111-06181-00 |
BOLT,HEX. SOCKET BUT Price: $1.50 |
| 30 |
B4J-F7277-00-00 |
ROD 1 Price: $4.10 |
| 33 |
90149-08805-00 |
SCREW Price: $1.20 |
| 34 |
90381-08001-00 |
BUSH, SOLID Price: $6.49 |
| 35 |
B4J-F1797-02-00 |
HINGE This part replaces B4J-F1797-01-00. Price: $14.49 |
| 36 |
90109-068C9-00 |
BOLT Price: $1.15 |
| 37 |
95604-06200-00 |
NUT, U FLANGE This part replaces 95602-06200-00. Price: $2.95 |
| 38 |
95817-08016-00 |
BOLT,FLANGE (JN5) This part replaces 95812-08016-00. Price: $5.49 |
| 39 |
B4J-F17H0-20-00 |
SIDE COVER COMP. 4 Price: $222.99 |
| 40 |
90183-062A1-00 |
NUT, SPRING Price: $2.20 |
| 41 |
90119-06226-00 |
BOLT, WITH WASHER Price: $2.80 |
| 42 |
B4J-K8572-00-00 |
PNL. , DOOR RR. RH Price: $70.99 |
| 43 |
90338-05009-00 |
PLUG Price: $3.45 |
| 44 |
90183-062A1-00 |
NUT, SPRING Price: $2.20 |
| 45 |
90269-05073-00 |
RIVET Price: $2.70 |
| 46 |
90110-06090-00 |
BOLT, HEXAGON SOCKET HEAD Price: $5.49 |
| 47 |
B4J-F1333-00-00 |
HOOK, SIDE COVER 3 Price: $14.49 |
| 48 |
90338-10801-00 |
PLUG Price: $1.20 |
| 49 |
95D32-06014-00 |
BOLT, FLANGE DEEP RECESS Price: $0.40 |
| 50 |
B4J-F1334-00-00 |
HOOK, SIDE COVER 4 Price: $14.49 |
| 51 |
90338-10801-00 |
PLUG Price: $1.20 |
