| Ref | Part Number | Description |
|---|
| 2 |
30561-ZB4-000 |
CLIP, WIRE Price: $6.60 |
| 3 |
31400-ZC2-631H |
BOX ASSY., CONTROL *R8* (EMS-A) (BRIGHT RED) Price: Call Us |
| 4 |
31404-ZC2-631 |
WIRE HARNESS ASSY. (EMS-A) Price: Call Us |
| 5 |
31406-ZB4-630 |
MARK, SWITCH PANEL (EMS-A) Price: $31.06 |
| 7 |
31408-880-000 |
SEE PART DETAILS - PRI; TERMINAL, D.C. OUT (+) Price: $46.94 |
| 8 |
31409-880-000 |
SEE PART DETAILS - PRI; TERMINAL, D.C. OUTPUT (-) Price: $46.94 |
| 9 |
31420-ZB4-621ZB |
PANEL, CONTROL *R280* (POWER RED) Price: $265.44 |
| 10 |
31425-ZB4-010ZD |
SEE PART DETAILS - PRI; CASE, CONTROL *R280* (POWER RED) This part replaces 31425-ZB4-010ZA. Price: $127.54 |
| 13 |
31430-ZC2-630 |
BREAKER, CIRCUIT (19A) Price: $318.78 |
| 14 |
31462-ZB4-000 |
RUBBER, CONTROL Price: $20.72 |
| 15 |
31481-ZB4-003 |
GROMMET, A.C. WIRE Price: $14.46 |
| 16 |
31482-ZB4-003 |
GROMMET, MAIN WIRE Price: $17.44 |
| 17 |
31483-ZB4-003 |
SEE PART DETAILS - PRI; GROMMET, SWITCH WIRE Price: $12.16 |
| 18 |
31710-ZB4-003 |
DIODE ASSY. Price: $118.50 |
| 20 |
32130-ZB4-000 |
CONNECTOR ASSY. Price: $21.50 |
| 21 |
32330-899-631 |
RECEPTACLE (20A/125V) (MATSUSHITA) Price: $70.88 |
| 22 |
32332-ZB4-630 |
SEE PART DETAILS - SUP; RECEPTACLE (30A/125V) Price: $47.26 |
| 23 |
32334-ZA0-631 |
SEE PART DETAILS - PRI; RECEPTACLE (30A/125-250V) Price: $31.90 |
| 24 |
34908-GE0-701 |
BULB, WEDGE BASE (12V/2W) Use from Frame SN 1001725. Price: $3.62 |
| 25 |
35100-ZB4-023 |
SEE PART DETAILS - PRI; SWITCH ASSY., COMBINATION Price: $142.02 |
| 26 |
35111-880-013 |
SEE PART DETAILS - PRI; KEY This part replaces 35111-880-003. Price: $11.50 |
| 27 |
36135-ZV1-003 |
VALVE, DASHPOT CHECK Price: $33.34 |
| 28 |
36170-ZB4-013 |
SEE PART DETAILS - PRI; VALVE ASSY., SOLENOID Price: $88.48 |
| 29 |
36210-ZB4-014 |
SEE PART DETAILS - PRI; THROTTLE UNIT, AUTO (SAWAFUJI) Price: $252.82 |
| 30 |
36214-ZB4-023 |
SWITCH, AUTO THROTTLE This part replaces 36214-ZB4-013. Price: $41.28 |
| 31 |
36221-899-630 |
SWITCH ASSY., VOLT CHANGE Price: $222.32 |
| 32 |
37450-ZB4-651 |
METER ASSY., VOLT (300V) Price: $306.96 |
| 33 |
37451-ZB4-003 |
LENS, METER Price: $20.28 |
| 34 |
37560-ZA0-801 |
SOCKET ASSY., LAMP (GREEN) Use from Frame SN 1001725. Price: $45.96 |
| 35 |
38240-898-000 |
PROTECTOR, CIRCUIT (D.C.) Price: $37.06 |
| 36 |
38250-ZA8-701 |
LENS ASSY., PROTECTOR (Honda Code 1888676). Price: $19.96 |
| 37 |
38253-898-000 |
SPRING, COIL Price: $1.92 |
| 38 |
87501-ZB4-630 |
MARK, ENGINE SWITCH (EMS-A) Price: $9.02 |
| 39 |
87524-ZB4-630 |
MARK, D.C. OUT (NOT AVAILABLE) Price: Call Us |
| 40 |
87534-892-640 |
SEE PART DETAILS - PRI; MARK, GROUND Price: $2.48 |
| 48 |
90672-ZB4-003 |
TIE, CABLE (NATURAL 225X5.0) Price: $5.94 |
| 49 |
91406-ZB4-000 |
TUBE, CORD Price: $11.92 |
| 50 |
91601-ZB4-003 |
GROMMET, TUBE Price: $4.04 |
| 51 |
93500-03006-0H |
SEE PART DETAILS - PRI; SCREW, PAN (3X6) (Honda Code 0561654). Price: $1.04 |
| 52 |
93500-03012-0H |
SEE PART DETAILS - PRI; SCREW, PAN (3X12) (Honda Code 0665521). Price: $1.04 |
| 53 |
93500-04006-0H |
SEE PART DETAILS - PRI; SCREW, PAN (4X6) (Honda Code 0285627). Price: $1.14 |
| 54 |
93892-05012-08 |
SEE PART DETAILS - PRI; SCREW-WASHER (5X12) (Honda Code 0368621). Price: $1.44 |
| 55 |
93893-04010-08 |
SEE PART DETAILS - PRI; SCREW-WASHER (4X10) Price: $1.68 |
| 56 |
93893-04012-08 |
SEE PART DETAILS - PRI; SCREW-WASHER (4X12) Use up to Engine SN 2056819. Price: $1.68 |
| 59 |
94050-04000 |
NUT, FLANGE (4MM) Price: $1.54 |
| 63 |
95002-02070 |
CLIP, TUBE (B7) (Honda Code 0250639). Price: $2.20 |
| 64 |
95002-40800-08 |
SEE PART DETAILS - PRI; CLIP, TUBE (D8) (Honda Code 0660811). Price: $2.82 |
| 65 |
95005-35008-10M |
SEE PART DETAILS - PRI; BULK HOSE, VACUUM (3.5X8000) (3.5X130) Price: $153.88 |
| 68 |
95701-06040-08 |
SEE PART DETAILS - PRI; BOLT, FLANGE (6X40) (Honda Code 2105872). Price: $2.30 |
