| Ref | Part Number | Description |
| 1 |
0662-609 |
Engine, AB80L4 - w/o EFI Components Price: $4,625.95 |
| 2 |
0636-363 |
Handle, Recoil Price: $15.71 |
| 3 |
0606-885 |
Cap, Recoil Handle Price: $1.45 |
| 5 |
0608-630 |
Mount, Engine Price: $46.95 |
| 6 |
0608-633 |
Bushing Price: $0.71 |
| 7 |
8409-026 |
Screw, Cap Price: $1.70 |
| 8 |
4606-425 |
Foil, Protective Price: $16.92 |
| 9 |
1619-131 |
Conduit, Flexible Price: $4.11 |
| 10 |
0123-788 |
Tie, Cable - 8 in Price: $0.23 |
| 11 |
0623-373 |
Clamp, Hose Price: $3.08 |
| 12 |
0610-923 |
Hose, Coolant - MAG/Throttle Body Price: $26.95 |
| 13 |
0619-776 |
Conduit, Flexible - 5 ft Price: $15.71 |
| 14 |
0610-878 |
Hose, Coolant Price: $20.16 |
| 15 |
0708-602 |
Plate, Engine Mounting - Lower Rear Price: $20.95 |
| 16 |
8409-036 |
Screw, Cap Price: $2.05 |
| 17 |
0608-496 |
Mount, Engine Price: $53.95 |
| 18 |
1623-944 |
Screw, Shoulder Price: $2.05 |
| 19 |
8409-017 |
Screw, Cap Price: $2.05 |
| 20 |
1623-080 |
Clamp, Routing Price: $1.77 |
| 21 |
0708-600 |
Plate, Engine Mounting - Lower Front Price: $22.95 |
| 22 |
8409-021 |
SCREW,CAP-HFH M10X1.25X20 CL10.9 W/2353 Price: $1.92 |
| 23 |
0708-587 |
Mount, Engine - Lower Price: $58.95 |
| 24 |
8427-002 |
Nut, Lock Price: $1.08 |
| 25 |
8468-617 |
Screw, Machine Not Available Price: |
| 26 |
8050-242 |
Washer Price: $2.26 |
| 27 |
1623-932 |
Screw, Cap Price: $4.39 |
| 28 |
0623-987 |
Washer, Spring Price: $2.42 |
| 29 |
0708-622 |
Plate, Engine Mounting - PTO Price: $185.95 |
| 30 |
1623-937 |
Screw, Cap Price: $1.45 |
| 31 |
0645-410 |
Ring, Damper Price: $87.95 |
| 32 |
1623-821 |
Screw, Machine Price: $9.64 |
| 33 |
0746-862 |
Clutch, Drive - Uncalibrated Price: $640.95 |
| 34 |
0627-084 |
Belt, Drive Price: $239.95 |
| 35 |
1623-649 |
Washer, Clutch Bolt Price: $6.29 |
