| Ref | Part Number | Description |
|---|
| 1 |
8JP-G7417-00-00 |
BRACKET 3 Price: $89.99 |
| 2 |
8JP-RAL01-00-00 |
NIPPLE, GREASE 1 Price: $2.85 |
| 3 |
8JP-G7488-10-00 |
SHAFT 6 Price: $25.99 |
| 4 |
8JP-RA199-00-00 |
BOLT, FLANGE M10X1.25X30 Price: $3.85 |
| 5 |
8JP-RA1A1-00-00 |
BOLT, FLANGE M10X1.25X40 Price: $4.30 |
| 6 |
8JP-G7332-00-00 |
ARM, PIVOT 2 Price: $216.99 |
| 7 |
8JP-RAL01-00-00 |
NIPPLE, GREASE 1 Price: $2.85 |
| 8 |
8JP-RA808-00-00 |
BUSH, 0.628 Price: $10.49 |
| 9 |
8JP-G7487-00-00 |
SHAFT 5 Price: $35.99 |
| 10 |
8JM-G7448-00-00 |
HOOK 3 Price: $19.49 |
| 11 |
8JM-G7447-00-00 |
HOOK 2 Price: $26.99 |
| 12 |
8JM-RA315-00-00 |
NUT Price: $0.90 |
| 13 |
8JP-G7445-00-00 |
PROTECTOR Price: $4.80 |
| 14 |
8JX-G7474-00-00 |
SPRING, REAR 2 Price: $115.99 |
| 15 |
8JX-G7473-00-00 |
SPRING, REAR 1 Price: $110.99 |
| 16 |
8JP-G7312-00-00 |
WHEEL, SUSPENSION 2 Price: $71.99 |
| 17 |
8JP-RAG03-00-00 |
BEARING, 2 Price: $46.99 |
| 18 |
8JP-RAH04-00-00 |
CIRCLIP, 2 Price: $8.49 |
| 19 |
8JP-RA727-00-00 |
COLLAR, 12.81 Price: $1.95 |
| 20 |
8JP-G7368-00-00 |
NUT Price: $4.90 |
| 21 |
8JP-RA436-00-00 |
WASHER, 0.035 Price: $1.20 |
| 22 |
8LJ-G7361-00-00 |
ARM, REAR PIVOT 1 Price: $80.99 |
| 23 |
8JM-RA301-00-00 |
NUT, SELF-LOCKING M8-1.25 Price: $1.15 |
| 24 |
8JP-RA191-00-00 |
BOLT, FLANGE M8X1.25X60 Price: $5.49 |
| 25 |
8JP-RA813-00-00 |
BUSH, 12FDU12 Price: $5.49 |
| 26 |
8ND-RA112-00-00 |
BOLT, FLANGE Price: $16.49 |
| 27 |
8JP-RA1B4-00-00 |
BOLT, FLANGE Price: $4.95 |
| 28 |
8JP-RA735-00-00 |
COLLAR, 19 Price: $3.55 |
| 29 |
8JX-G7494-00-00 |
ROD, RELAY Price: $51.99 |
| 30 |
8JP-RA724-00-00 |
COLLAR, 12 Price: $6.49 |
| 31 |
8JP-RA378-01-00 |
NUT, LOCK Price: $1.35 |
| 32 |
8MY-G7480-40-00 |
SHOCK ABSORBER Price: $1,029.99 |
| 33 |
8KN-RA459-20-00 |
WASHER, SEAT 1 Price: $19.49 |
| 34 |
8JW-RA732-10-00 |
COLLAR, 15 Price: $35.99 |
| 35 |
8KN-RA819-30-00 |
BUSH, SHOCK Price: $44.99 |
| 36 |
8JP-RA732-00-00 |
COLLAR, 15 Price: $46.99 |
| 37 |
8JP-RA817-00-00 |
BUSH, 8 Price: $22.99 |
| 38 |
8MY-G7716-00-00 |
COVER Price: $15.49 |
| 39 |
8KP-F151J-10-00 |
LABEL 6 Price: $23.99 |
| 40 |
8MY-RA277-00-00 |
SCREW, TAPPING Price: $0.35 |
| 41 |
8JP-RAB25-00-00 |
CLAMP, 23 Price: $1.75 |
| 42 |
8MY-G8176-00-00 |
GROMMET Price: $2.25 |
| 43 |
8JP-RA1A2-10-00 |
BOLT, FLANGE Price: $10.49 |
| 44 |
8JP-RA378-01-00 |
NUT, LOCK Price: $1.35 |
| 45 |
8MY-RAC00-00-00 |
CLIP, 1 Price: $3.15 |
| 46 |
8MY-H2589-00-00 |
PROTECTER, WIRE HA Price: $18.49 |
| 47 |
8JP-RA520-00-00 |
RIVET, 11 Price: $0.75 |
| 48 |
8KC-RA290-00-00 |
SCREW Price: $2.25 |
| 49 |
8JP-RA251-00-00 |
SCREW, M5X1.0X16 Price: $0.55 |
