| Ref | Part Number | Description |
|---|
| 1 |
2BG-11400-10-00 |
CRANKSHAFT ASSY This part replaces 2BG-11400-00-00. Price: $684.99 |
| 2 |
3B4-11401-09-00 |
CRANK SUB ASSY 1 Price: $334.99 |
| 3 |
3B4-11402-09-00 |
CRANK SUB ASSY 2 Price: $271.99 |
| 4 |
5VK-11681-01-00 |
PIN, CRANK 1 Price: $105.99 |
| 5 |
93310-84037-00 |
BEARING Price: $90.99 |
| 6 |
2BG-11651-00-00 |
ROD, CONNECTING Price: $158.99 |
| 7 |
1HP-11536-00-00 |
GEAR, DRIVE (44T) Price: $161.99 |
| 8 |
5KM-11565-00-00 |
WASHER, BEARING COVER Price: $15.49 |
| 9 |
90501-220A1-00 |
SPRING, COMPRESSION Price: $8.49 |
| 10 |
93606-09002-00 |
PIN, DOWEL Price: $4.45 |
| 11 |
93410-35M10-00 |
CIRCLIP (6U2) This part replaces 99009-35400-00. Price: $8.49 |
| 12 |
90280-05001-00 |
KEY, WOODRUFF Price: $13.49 |
| 13 |
90201-16013-00 |
WASHER, PLATE Price: $15.49 |
| 14 |
90179-16004-00 |
NUT Price: $17.49 |
| 15 |
93306-30810-00 |
BEARING Price: $82.99 |
| 16 |
2BG-11631-00-00 |
PISTON (STD) Price: $172.99 |
| 17 |
1S3-11603-10-00 |
PISTON RING SET (STD) Price: $66.99 |
| 18 |
5VK-11633-00-00 |
PIN, PISTON Price: $45.99 |
| 19 |
93450-24154-00 |
CIRCLIP Price: $3.40 |
| 20 |
3B4-16181-00-00 |
SPACER 1 Price: $111.99 |
| 21 |
2BG-11447-01-00 |
SEAL, CRANK This part replaces 2BG-11447-00-00. Price: $18.99 |
| 22 |
2BG-11454-00-00 |
WEIGHT 1 Price: $131.99 |
| 23 |
1HP-11531-10-00 |
GEAR, BALANCE WEIGHT Price: $140.99 |
| 24 |
1HP-13354-00-00 |
SPROCKET, DRIVE Price: $65.99 |
| 25 |
90282-05065-00 |
KEY, STRAIGHT This part replaces 90282-05013-00. Price: $10.49 |
| 26 |
90387-24001-00 |
COLLAR Price: $32.99 |
| 27 |
90170-18003-00 |
NUT Price: $16.49 |
| 28 |
90215-18001-00 |
WASHER, LOCK Price: $13.49 |
| 29 |
93306-30560-00 |
BEARING This part replaces 93306-30534-00. Price: $85.99 |
