| Ref | Part Number | Description |
|---|
| 1 |
2S3-W1217-00-00 |
CAMSHAFT SUB ASSY 1 Price: $274.99 |
| 2 |
2S3-12176-00-00 |
SPROCKET, CAM CHAIN Price: $120.99 |
| 3 |
2S3-11554-00-00 |
GEAR 3 Price: $139.99 |
| 4 |
90105-07006-00 |
BOLT, FLANGE Price: $9.49 |
| 5 |
2S3-W1217-00-00 |
CAMSHAFT SUB ASSY 1 Price: $274.99 |
| 6 |
2S3-12176-00-00 |
SPROCKET, CAM CHAIN Price: $120.99 |
| 7 |
2S3-11554-00-00 |
GEAR 3 Price: $139.99 |
| 8 |
90105-07006-00 |
BOLT, FLANGE Price: $9.49 |
| 9 |
2S3-12180-01-00 |
CAMSHAFT ASSY 2 Price: $914.99 |
| 10 |
2S3-12287-00-00 |
SPRING, DECOMPRESSION Price: $2.65 |
| 11 |
2S3-12180-11-00 |
CAMSHAFT ASSY 2 Price: $914.99 |
| 12 |
2S3-12287-00-00 |
SPRING, DECOMPRESSION Price: $2.65 |
| 13 |
94591-49134-00 |
CHAIN Price: $43.99 |
| 14 |
2S3-12251-00-00 |
DAMPER, CHAIN 1 Price: $31.99 |
| 15 |
2S3-12253-00-00 |
DAMPER, CHAIN 3 Price: $30.99 |
| 16 |
2S3-12250-00-00 |
CHAIN DAMPER ASSY Price: $580.99 |
| 17 |
91317-06025-00 |
BOLT This part replaces 91312-06025-00. Price: $2.65 |
| 18 |
99530-08012-00 |
PIN, DOWEL Price: $6.60 |
| 19 |
2S3-12210-01-00 |
TENSIONER ASSY, CAM CHAIN Price: $169.99 |
| 20 |
2S3-12213-00-00 |
GASKET, TENSIONER CASE Price: $7.49 |
| 21 |
91317-06016-00 |
BOLT (4MY) This part replaces 90110-06193-00. Price: $1.25 |
| 22 |
2S3-12231-00-00 |
GUIDE, STOPPER 1 Price: $36.99 |
