| Ref | Part Number | Description |
|---|
| 1 |
06430-131-405 |
SHOE SET, BRAKE This part replaces 06430-GZ9-003. Price: $18.59 |
| 2 |
42301-GEL-A80 |
AXLE, RR. WHEEL Price: $20.29 |
| 3 |
43410-GEL-700 |
ARM, RR. BRAKE (FR.) (FOR FR.) Price: $10.00 |
| 4 |
43411-GEL-700 |
COVER, RR. BRAKE ARM Price: $9.36 |
| 5 |
45100-181-831ZC |
PANEL, FR. BRAKE *NH146M* (ACCURATE SILVER METALLIC) (RR.) (FOR RR.) Price: $60.56 |
| 6 |
45133-044-000 |
SPRING, BRAKE SHOE Price: $2.76 |
| 7 |
45134-165-890 |
SEAL, BRAKE CAM Price: $1.80 |
| 8 |
45141-147-003 |
CAM, FR. BRAKE (RR.) (FOR RR.) Price: $15.07 |
| 9 |
45145-GW8-670 |
INDICATOR, BRAKE Price: $4.58 |
| 10 |
90112-GG2-900 |
BOLT, FLANGE (5X25) Price: $5.27 |
| 11 |
90302-KRS-830 |
NUT, SPECIAL (6MM) Price: $2.36 |
| 12 |
94001-05000-0S |
NUT, HEX. (5MM) Price: $2.78 |
| 13 |
94001-06200-0S |
NUT, HEX. (6MM) This part replaces 94001-06000-0S. Price: $1.37 |
| 14 |
95014-10010 |
ADJUSTER S, R. CHAIN This part replaces 40543-GEL-A80. Price: $5.67 |
