| Ref | Part Number | Description |
|---|
| 1 |
30510-KZZ-901 |
COIL, IGNITION Price: $42.87 |
| 2 |
30520-GFM-900 |
SPACER, IGNITION COIL Price: $2.98 |
| 3 |
30700-KZZ-901 |
CAP ASSY., NOISE SUPPRESSOR Price: $46.58 |
| 4 |
31600-KZZ-J01 |
RECTIFIER ASSY., REGULATOR Price: $120.20 |
| 5 |
31700-MM8-610 |
RECTIFIER, SILICON Price: $28.55 |
| 6 |
31730-MAS-601 |
DIODE ASSY., THREE WAY (SUMITOMO) Price: $13.09 |
| 7 |
32100-KZZ-J90 |
WIRE HARNESS Price: $788.67 |
| 8 |
32103-KZZ-J80 |
SUB-HARNESS, FR. Price: $72.34 |
| 9 |
32161-404-000 |
BAND B1, CABLE BAND A1, CABLE Price: $2.67 |
| 11 |
32606-GEV-761 |
CAP, DUMMY (4P) (RED) (Honda Code 7679160) Price: $5.16 |
| 12 |
35160-KVS-751 |
SENSOR ASSY., BANK ANGLE (M6) Price: $123.91 |
| 13 |
35161-KZZ-900 |
STAY, BANK ANGLE SENSOR Price: $2.95 |
| 14 |
37244-MM4-000 |
RUBBER, SPEEDOMETER MOUNTING Price: $6.42 |
| 15 |
38110-KYJ-901 |
HORN (HIGH) Price: $31.67 |
| 16 |
38301-KYJ-641 |
RELAY, TURN SIGNAL (MITSUBA) Price: $85.85 |
| 17 |
38501-KWN-901 |
RELAY, POWER (MICRO ISO 4P) (OMRON) Price: $7.69 |
| 18 |
38506-KZZ-900 |
COVER, RELAY (2P) Price: $4.13 |
| 19 |
38770-KZZ-J11 |
PGM-FI UNIT Price: $204.62 |
| 20 |
38771-KTY-D30 |
CUSHION, PGM-FI UNIT Price: $1.73 |
| 21 |
77302-473-000 |
COLLAR, PILLION SEAT Price: $4.93 |
| 22 |
90650-KW3-000 |
BAND, WIRE Price: $5.62 |
| 23 |
90651-KV6-003 |
BAND, WIRE (165MM) (BLACK) Price: $3.65 |
| 24 |
90651-MA6-720 |
BAND, WIRE HARNESS Price: $4.68 |
| 25 |
90679-SG9-E01 |
BAND, SUCTION HOSE (BLACK) (Honda Code 3522752) Price: $4.68 |
| 26 |
91533-S5A-003 |
CLIP, CONNECTOR (NATURAL) Price: $11.45 |
| 27 |
91534-SWA-003 |
CLIP, CONNECTOR (DARK GRAY) Price: $10.00 |
| 28 |
91565-S0X-003 |
CLIP, CONNECTOR (DARK GREEN) Price: $3.80 |
| 29 |
92101-06020-4J |
BOLT, HEX. (6X20) Price: $1.58 |
| 30 |
94050-06000 |
NUT, FLANGE (6MM) Price: $0.68 |
| 31 |
94102-08000 |
WASHER, PLAIN (8MM) Price: $0.98 |
| 32 |
95701-06012-00 |
BOLT, FLANGE (6X12) BOLT, SPECIAL (6X12) Price: $1.70 |
| 33 |
95701-06022-00 |
BOLT, FLANGE (6X22) Price: $1.88 |
| 34 |
95701-06030-00 |
BOLT, FLANGE (6X30) Price: $1.97 |
| 35 |
95701-08014-00 |
BOLT, FLANGE (8X14) Price: $1.37 |
| 36 |
98200-41000 |
FUSE, MINI (10A) Price: $1.38 |
| 37 |
98200-42000 |
FUSE, MINI (20A) Price: $1.27 |
| 39 |
32406-MFF-D00 |
COVER, STARTER MAGNETIC TERMINAL Price: $35.33 |
| 40 |
32414-GAG-000 |
COVER, BATTERY TERMINAL Price: $4.47 |
| 41 |
91533-S5A-003 |
CLIP, CONNECTOR (NATURAL) Price: $11.45 |
| 42 |
98200-41000 |
FUSE, MINI (10A) Price: $1.38 |
| 43 |
98200-43000 |
FUSE, MINI (30A) (Honda Code 5359666) Price: $1.83 |
