| Ref | Part Number | Description |
|---|
| 1 |
6BA-24311-00-00 |
PIPE, FUEL 1 Price: $24.99 |
| 2 |
90464-36005-00 |
CLAMP Price: $0.99 |
| 3 |
90116-08M60-00 |
BOLT, STUD Price: $4.99 |
| 4 |
90179-08M15-00 |
NUT Price: $8.60 |
| 5 |
62T-13556-00-00 |
GASKET, MANIFOLD Price: $15.99 |
| 6 |
62T-13555-00-00 |
MANIFOLD, INTAKE Price: $133.49 |
| 7 |
62T-13624-00-00 |
PLATE, REED VALVE Price: $19.99 |
| 8 |
62T-13566-00-00 |
GASKET Price: $11.99 |
| 9 |
97014-06035-00 |
BOLT, HEXAGON This part replaces 97013-06035-00. Price: $2.65 |
| 10 |
92990-06600-00 |
WASHER, PLATE This part replaces 92903-06600-00. Price: $2.85 |
| 11 |
97013-06025-00 |
BOLT Price: $1.60 |
| 12 |
92990-06600-00 |
WASHER, PLATE This part replaces 92903-06600-00. Price: $2.85 |
| 13 |
62T-13610-00-00 |
REED VALVE ASSY Price: $163.99 |
| 14 |
62T-W0004-00-00 |
REED SET Price: $98.99 |
| 15 |
90111-05037-00 |
BOLT, HEX. SOCKET BUTTON Price: $7.49 |
| 16 |
62T-14243-01-00 |
PLATE Price: $18.49 |
| 17 |
61L-5169A-00-00 |
NIPPLE, GREASE Price: $9.99 |
| 18 |
663-45119-01-00 |
CAP, GREASE NIPPLE This part replaces 663-45119-00-00. Price: $2.40 |
| 19 |
62T-14527-02-00 |
PLATE Price: $18.49 |
| 20 |
97D95-06016-00 |
BOLT, HEXAGON DEEP R This part replaces 97013-06016-00. Price: $2.76 |
| 21 |
92990-06600-00 |
WASHER, PLATE This part replaces 92903-06600-00. Price: $2.85 |
| 22 |
62T-24314-01-00 |
PIPE 4 Price: $9.99 |
| 23 |
90464-36005-00 |
CLAMP Price: $0.99 |
| 24 |
62T-14284-10-8S |
COVER, CARBURETOR 2 Price: $118.99 |
| 25 |
97013-06020-00 |
BOLT Price: $1.55 |
| 26 |
92990-06600-00 |
WASHER, PLATE This part replaces 92903-06600-00. Price: $2.85 |
| 27 |
62T-13674-00-00 |
GASKET, AIR COOLER COVER 1 Price: $7.49 |
| 28 |
62T-14255-00-00 |
PLATE Price: $45.49 |
| 29 |
97013-06012-00 |
BOLT (661) Price: $6.49 |
| 30 |
92990-06600-00 |
WASHER, PLATE This part replaces 92903-06600-00. Price: $2.85 |
| 31 |
62T-14451-00-00 |
ELEMENT, AIR CLEANER Price: $38.49 |
| 32 |
62T-14283-01-00 |
COVER, CARBURETOR 1 Price: $50.99 |
| 33 |
62T-14419-00-00 |
PIPE Price: $78.99 |
| 34 |
90119-05M02-00 |
BOLT, WITH WASHER Price: $3.99 |
| 35 |
62T-14435-00-00 |
GROMMET Price: $4.99 |
