| Ref | Part Number | Description |
|---|
| 1 |
06410-MBH-000 |
DAMPER SET, WHEEL Price: $66.18 |
| 2 |
06420-MEG-H10 |
SPOKE SET, R. RR. (INNER) Price: $7.89 |
| 3 |
06421-MEG-H10 |
SPOKE SET, R. RR. (OUTER) Price: $7.89 |
| 4 |
06422-MEG-H10 |
SPOKE SET, L. RR. (INNER) Price: $7.89 |
| 5 |
06423-MEG-H10 |
SPOKE SET, L. RR. (OUTER) Price: $7.89 |
| 6 |
42313-MEG-H10 |
COLLAR, R. RR. WHEEL SIDE Price: $23.85 |
| 7 |
42515-MJA-CU0 |
RING, PULSER Price: $56.82 |
| 8 |
42516-MJA-CU0 |
SPACER, BRK DISK Price: $75.04 |
| 9 |
42616-MT3-000 |
WASHER, THRUST Price: $8.58 |
| 10 |
42617-MT8-000 |
HOLDER, DAMPER Price: $49.09 |
| 11 |
42630-MAH-305 |
FLANGE SET, FINAL DRIVEN Price: $219.47 |
| 12 |
42635-MJA-CS0 |
HUB SUB-ASSY., RR. Price: $567.22 |
| 13 |
42650-MJA-CS0 |
WHEEL SUB-ASSY., RR. Price: $878.67 |
| 14 |
42701-MJA-CP1 |
RIM, RR. WHEEL Price: $221.58 |
| 15 |
42704-MEG-003 |
WEIGHT, BALANCE (15G) Price: $10.15 |
| 15 |
42705-MEG-003 |
WEIGHT, BALANCE (20G) Price: $10.15 |
| 16 |
42711-MCL-023 |
TIRE, RR. (160/80-15) (M/C 74S) (BS) Price: $293.97 |
| 16 |
42711-MCL-043 |
TIRE, RR. Price: $225.54 |
| 16 |
42711-MEG-034 |
TIRE (160/80-15) Price: $234.10 |
| 17 |
42712-MEG-901 |
TUBE, TIRE (BS) Price: $50.22 |
| 17 |
42712-MEG-902 |
TUBE, TIRE (DUNLOP) Price: $45.49 |
| 18 |
42713-MR1-671 |
FLAP, TIRE (BS) This part replaces 42713-MEG-007. Price: $9.20 |
| 18 |
42713-MR1-672 |
FLAP, TIRE (45-15) (DUNLOP) Price: $9.20 |
| 19 |
43251-MJA-CU1 |
DISK, RR. BRAKE Price: $321.80 |
| 20 |
44620-MT3-000 |
COLLAR, FR. AXLE DISTANCE (RR.) Price: $20.85 |
| 21 |
90106-MJM-D30 |
BOLT (6X17) Price: $3.04 |
| 22 |
90106-MJA-CS0 |
BOLT, RR. (8X33.5) Price: $5.89 |
| 23 |
91053-MKY-D51 |
BEARING, RADIAL BALL (6204UU) (NSK) Price: $18.38 |
| 24 |
91053-MN5-003 |
BEARING, RADIAL BALL (20X47X20.6) (TOYO) Price: $90.78 |
| 25 |
91253-443-762 |
DUST SEAL (30X47X8) (NOK) This part replaces 91253-443-761. Price: $14.69 |
| 26 |
91302-MA6-003 |
O-RING (61X2) Price: $6.49 |
