| Ref | Part Number | Description |
|---|
| 1 |
42-7400 |
TAPER PLUG MS 661123 Price: $8.53 |
| 2 |
42-7320 |
DISCONTINUED Price: Call Us |
| 3 |
42-7310 |
DISCONTINUED Price: Call Us |
| 4 |
93-3689 |
GEAR CASE MM 408230 Price: $464.80 |
| 5 |
112-8429 |
GASKET-CASE This part replaces 42-7340. Price: $45.56 |
| 6 |
62-3740 |
PLATE-FRONT Price: $112.46 |
| 7 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 8 |
67-2340 |
BOLT W/WASHER Price: $2.19 |
| 9 |
42-7150 |
PLT GASKET Price: $29.07 |
| 10 |
42-7700 |
GEAR Price: $256.37 |
| 11 |
42-7110 |
IDLER SHAFT Price: $92.89 |
| 12 |
67-2390 |
PLUG Price: $5.06 |
| 13 |
56-0220 |
DISCONTINUED Price: Call Us |
| 14 |
42-9250 |
BOLT Price: $1.63 |
| 15 |
107-4803 |
CAP-SEALING This part replaces 42-7080. Price: $14.47 |
| 16 |
93-1351 |
VALVE - INTAKE Price: $66.11 |
| 17 |
93-1352 |
VALVE - EXHAUST Price: $63.26 |
| 18 |
92-1961 |
VALVE SEAL Price: $14.93 |
| 19 |
42-7880 |
VALVE SPRG MM 402381 Price: $26.36 |
| 20 |
42-7850 |
SPRING RET MD 016482 Price: $23.84 |
| 21 |
42-7860 |
RET LOCK MD 016483 Price: $8.42 |
| 22 |
42-7940 |
ROCKER ARM Price: $124.42 |
| 23 |
42-7970 |
ROCKER STAY MM 314770 Price: $52.89 |
| 24 |
42-7950 |
DISCONTINUED Price: Call Us |
| 25 |
48-9590 |
WASHER-LOCK Price: $0.25 |
| 26 |
42-9360 |
BOLT Price: $24.32 |
| 27 |
42-9350 |
DISCONTINUED Price: Call Us |
| 28 |
43-5930 |
WASHER-LOCK, SPRING Price: $0.75 |
| 29 |
42-9620 |
JAM NUT Price: $7.10 |
| 30 |
42-7980 |
ADJ SCREW K 7231220 Price: $13.05 |
| 31 |
93-3688 |
SHIPPING CAP(TACHOMETER) Price: $5.36 |
| 32 |
42-7920 |
ROD - PUSH Price: $27.14 |
| 33 |
42-7890 |
TAPPET Price: $74.76 |
| 34 |
42-9010 |
O-RING MF 520012 Price: $7.40 |
| 35 |
42-8970 |
SPRING PIN Price: $4.09 |
| 36 |
42-8980 |
GEAR SLEEVE Price: $69.23 |
| 37 |
42-8990 |
O-RING MD 701788 Price: $6.18 |
| 39 |
42-9440 |
BOLT/WASHER Price: $4.52 |
| 40 |
42-7960 |
ROCKER SHFT MM 408935 Price: $118.11 |
| 41 |
42-7930 |
DISCONTINUED Price: Call Us |
| 42 |
42-9370 |
SCREW-HH Price: $2.42 |
| 43 |
42-7990 |
RING-SNAP Price: $2.80 |
| 44 |
72-4200 |
STD RING SET Price: $215.25 |
| 48 |
120-5723 |
PISTON AND PIN SET This part replaces 72-4240. Price: $470.54 |
| 49 |
42-7650 |
CONNECTING ROD Price: $566.96 |
| 50 |
67-2860 |
BOLT Price: $10.69 |
| 52 |
54-8670 |
BOLT Price: $6.00 |
| 53 |
43-1800 |
DISCONTINUED Price: Call Us |
| 54 |
43-1810 |
GEAR RING Price: $269.80 |
| 55 |
106-8099 |
KIT - OIL SEAL This part replaces 42-7060. Price: $200.99 |
| 56 |
42-9220 |
DISCONTINUED Price: Call Us |
| 57 |
42-7120 |
DISCONTINUED Price: Call Us |
| 58 |
42-7130 |
SEAL GASKET Price: $16.28 |
| 59 |
42-7710 |
CRANKSHAFT MM 408811 Price: $3,435.71 |
| 60 |
42-7660 |
BRG SET Price: $113.00 |
| 61 |
42-9590 |
CONN ROD NUT Price: $10.19 |
| 62 |
42-7730 |
DISCONTINUED Price: Call Us |
| 63 |
42-9020 |
DISCONTINUED Price: Call Us |
| 64 |
93-3387 |
BRG SET STD Price: $282.00 |
| 65 |
42-7040 |
SEAL-SIDE Price: $12.31 |
| 67 |
42-9210 |
BOLT-BRG CAP Price: $11.29 |
| 76 |
48-2010 |
OIL SCREEN Price: $100.69 |
| 77 |
48-1990 |
NUT Price: $4.69 |
| 78 |
48-1980 |
GASKET Price: $1.38 |
| 79 |
42-7100 |
CAMSHFT BSHG Price: $29.75 |
| 80 |
601002163 |
FRAME, ASSY Price: $84.62 |
| 81 |
33114-016 |
SCREW-HH This part replaces 42-9230. Price: $0.27 |
| 82 |
42-7390 |
OIL SEAL Price: $31.54 |
| 83 |
42-7720 |
PULLEY Price: $191.04 |
| 84 |
43-6470 |
HEXNUT HNX 480180 Price: $18.18 |
| 85 |
42-9860 |
DISCONTINUED Price: Call Us |
| 86 |
42-9810 |
WASHER Price: $5.44 |
| 87 |
33114-045 |
SCREW-HH This part replaces 42-9500. Price: $0.68 |
| 88 |
601000519 |
SCREW, 5/16-18X .50 WAHHT Price: $1.99 |
| 88 |
82-2590 |
PLUG - THRUST Price: $38.60 |
| 90 |
601001739 |
COVER, BOTTOM Price: $19.89 |
| 91 |
601001445 |
SCREW Price: $4.99 |
| 100 |
601002347 |
PLATE, CLUTCH ARM Price: Call Us |
| 103 |
601002406 |
BRACKET, IDLER Price: $4.63 |
| 104 |
601002349 |
BOLT, HHSH 3/8-16 Price: Call Us |
| 105 |
601002407 |
NUT 3/8-16 Price: $3.99 |
| 106 |
601002027 |
CLIP, CABLE TINN Price: $3.99 |
| 108 |
601002473 |
CABLE This part replaces 601002421. Price: $99.99 |
| 109 |
601002030 |
SHIELD, CABLE GROUND Price: $24.99 |
| 110 |
601001598 |
CARR. BOLT, 3/8-16X1.25 Price: $3.99 |
| 111 |
601000671 |
WASHER, FLAT .506X .75X. Price: $3.99 |
| 112 |
601001454 |
IDLER PULLEY Price: $40.99 |
| 115 |
601001335 |
NUT Price: $3.99 |
| 116 |
601001602 |
BOLT. BRAKE ARM 9/16-18 Price: $15.16 |
| 117 |
601001601 |
NUT, 9/16-18 HEX Price: $2.77 |
| 118 |
601001604 |
BOLT-BRAKE ARM ADJ. Price: $41.99 |
| 119 |
601001451 |
PIN Price: $1.58 |
| 120 |
601001459 |
PAD Price: $3.37 |
| 121 |
601002468 |
BRACKET PUCK Price: $13.04 |
| 122 |
601001603 |
NUT, 1/2-20 JAM Price: $3.23 |
| 123 |
601002407 |
NUT 3/8-16 This part replaces 601000060. Price: $3.99 |
| 124 |
601002409 |
STUD, BRAKE ARM Price: Call Us |
| 125 |
601000015 |
WASHER, REGSPTLK.393X.68X Price: $1.66 |
| 126 |
601002318 |
RP NUT Price: $9.99 |
| 127 |
601000560 |
PULLEY, ALUMINUM Price: $11.99 |
| 128 |
601002059 |
BOLT, SH 1/4-20 Price: $1.62 |
| 129 |
601000017 |
WASHER, FLAT .250X .56X. Price: $1.58 |
| 133 |
601002060 |
SPRING, IDLER Price: $37.99 |
| 140 |
601001461 |
LEVER Price: $57.63 |
| 141 |
601000073 |
SCREW, 5/16-18X .75 HHC Price: $2.99 |
| 142 |
601001462 |
WASHER Price: $1.53 |
| 143 |
601001463 |
BUSHING Price: $6.38 |
| 144 |
601001464 |
NUT Price: $1.99 |
| 145 |
601001089 |
SPRING Price: $3.48 |
| 146 |
601001740 |
SCREW, 3/8-16X1.25 Price: $1.29 |
| 148 |
601001454 |
IDLER PULLEY Price: $40.99 |
| 149 |
601001335 |
NUT Price: $3.99 |
| 160 |
601001465 |
COVER, BELT Price: $10.80 |
| 161 |
601001445 |
SCREW Price: $4.99 |
