| Ref | Part Number | Description |
|---|
| 1 |
40-8970 |
DISCONTINUED This part replaces 5-1447. Price: Call Us |
| 1 |
532442897 |
Price: Call Us |
| 2 |
40-8930 |
DISCONTINUE This part replaces 10-8330. Price: Call Us |
| 2 |
587253301 |
MANDREL.NONGREASEABLE.TALL This part replaces 532192870. Price: $32.99 |
| 3 |
11-8880 |
Engine Price: Call Us |
| 3 |
532442907 |
Price: Call Us |
| 4 |
3290-199 |
NUT-SPEED Price: $4.09 |
| 4 |
532444237 |
Price: Call Us |
| 5 |
321-8 |
SCREW-HH Price: $0.34 |
| 5 |
532442912 |
Price: Call Us |
| 6 |
532444236 |
Price: Call Us |
| 7 |
3296-42 |
NUT-LOCK, NI This part replaces 32146-17. Price: $0.28 |
| 7 |
532429395 |
LIFT.ASM.DECK.LRV Price: $54.99 |
| 8 |
32149-7 |
NUT-KEPS Price: $0.27 |
| 8 |
532429195 |
LINK, DECK LIFT Price: $5.99 |
| 9 |
2412-21 |
DISCONTINUED Price: Call Us |
| 9 |
532429397 |
LINK.ASM.LIFT.ADJUSTABLE Price: $17.99 |
| 10 |
3290-237 |
SLOT HD SCREW Price: $0.25 |
| 10 |
532192572 |
SHIELD.DEFLECTOR.MOWER.38" This part replaces 532193968. Price: $49.99 |
| 12 |
3290-163 |
Locknut Price: Call Us |
| 12 |
532131491 |
ROD.HINGE Price: $1.99 |
| 13 |
532197026 |
SPRING.TORSION.DEFLECT Price: $5.99 |
| 13 |
8-2120 |
DISCONTINUED Price: Call Us |
| 14 |
5-1287 |
DISCONTINUED Price: Call Us |
| 14 |
532195185 |
ARM.SUSPENSION.MOWER Price: $11.99 |
| 15 |
2212-10 |
MUFFLER Price: $159.52 |
| 16 |
3-7232 |
DISCONTINUED Price: Call Us |
| 17 |
819191912 |
WASHER.CLEAR.ZINC Price: $3.99 |
| 17 |
98-3206 |
DECAL This part replaces 12-9140. Price: $1.99 |
| 18 |
5-1280 |
DISCONTINUED Price: Call Us |
| 18 |
532194209 |
PIN.COTTER.7/16.BOW TI. Price: $1.99 |
| 19 |
3217-16 |
NUT-HEX Price: $0.25 |
| 19 |
532196539 |
BOLT.SHOULDER Price: $4.99 |
| 20 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 20 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $1.99 |
| 21 |
68-8860 |
CHAIN GUARD WA *R This part replaces 22-8240. Price: $53.73 |
| 21 |
819171912 |
WASHER Price: $3.99 |
| 22 |
532441598 |
SUBASM.LINK.DECK.TOP.LRVB Price: $22.99 |
| 23 |
25-9900 |
DISCONTINUED Price: Call Us |
| 23 |
532400130 |
BRAKE.ARM.LH.38"TEX.COATED This part replaces 532199470. Price: $11.99 |
| 24 |
321-6 |
SCREW-HH This part replaces 322-22. Price: $0.25 |
| 24 |
532401872 |
SPRING RETURN Price: $2.99 |
| 25 |
32122-14 |
SCREW-PPH Price: $1.02 |
| 26 |
5-1315 |
DISCONTINUED Price: Call Us |
| 26 |
532187690 |
WASHER.SPACER.MANDREL Price: $1.99 |
| 27 |
3-7934 |
DISCONTINUED Price: Call Us |
| 27 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $1.99 |
| 28 |
3-7935 |
DISCONTINUED Price: Call Us |
| 28 |
532400234 |
NUT.FLANGE.LOCK.TOP Price: $3.99 |
| 29 |
3273-29 |
SCREW-HSFH Price: $20.62 |
| 29 |
532442911 |
Price: Call Us |
| 30 |
3-8388 |
WASHER Price: $24.32 |
| 30 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $5.99 |
| 31 |
5-1336 |
KEY-SQUARE Price: $8.92 |
| 31 |
532177968 |
PULLEY.IDLER.FLAT This part replaces 532193197. Price: $14.99 |
| 32 |
25-9920 |
DISCONTINUED Price: Call Us |
| 32 |
532436858 |
GUARD.TUV.IDLER.42 Price: $2.99 |
| 33 |
532442906 |
Price: Call Us |
| 34 |
323-4 |
SCREW-HH Price: $1.02 |
| 34 |
872110612 |
BOLT.3/8-16X1.50 Price: $3.99 |
| 35 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 35 |
532442905 |
Price: Call Us |
| 36 |
224-173 |
DISCONTINUED Price: Call Us |
| 36 |
532137729 |
SCREW.1/4-20X5/8 Price: $2.99 |
| 37 |
289-26 |
DISCONTINUED Price: Call Us |
| 37 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $2.99 |
| 38 |
304-73 |
FITTING-STRAIGHT Price: $12.59 |
| 38 |
532442903 |
Price: Call Us |
| 39 |
10-4650 |
DISCONTINUED Price: Call Us |
| 40 |
10-8350 |
DISCONTINUED Price: Call Us |
| 40 |
819171616 |
Washer 17/32 x 1-1/6 x 13 Gauge (AYP part number) Price: $5.99 |
| 41 |
32128-20 |
NUT-HF Price: $0.99 |
| 41 |
532105304 |
CAP-SLEEVE LT Price: $2.99 |
| 42 |
532110452 |
NUT PUSH M Price: $1.99 |
| 49 |
532199092 |
SPACER.RETAINER Price: $3.99 |
| 50 |
817000616 |
SCREW 3/8-16X1 Price: $3.99 |
| 52 |
817600406 |
SCREW 1/4X20 Price: $2.99 |
| 53 |
532193216 |
SPRING.BRAKE.RETURN.38" Price: $3.99 |
| 54 |
532415598 |
PORT.WASHOUT Price: $5.99 |
| 56 |
532401663 |
Price: Call Us |
| 57 |
734117201 |
WASHER This part replaces 819131312. Price: $1.99 |
| 66 |
532197250 |
BRKT.CLUTCH.CABLE Price: $2.99 |
| 67 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $3.99 |
| 68 |
532442902 |
Price: Call Us |
| 69 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 70 |
532193406 |
BOLT.SHOULDER.3/8-16X3-5/8. Price: $1.99 |
| 71 |
532174873 |
WHEEL. GUAGE RALLY Price: $7.99 |
| 72 |
819132012 |
WASHER Price: $2.99 |
| 74 |
532400095 |
BAFFLE.VORTEX.FRONT.38" Price: $12.99 |
