| Ref | Part Number | Description |
|---|
| 1 |
100-6571 |
HOOD ASM Price: $1,342.17 |
| 1 |
532401043 |
SEAT.XG150.BLK.KB/SLD.NO-LOGO This part replaces 532124186. Price: $219.99 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 2 |
65-5100 |
HANDLE-DOOR Price: $9.05 |
| 3 |
63-7030-03 |
SCREEN-HOOD REAR This part replaces 63-7030. Price: $141.98 |
| 4 |
321-3 |
SCREW-HH Price: $0.28 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 5 |
95-3024 |
DISCONTINUED Price: Call Us |
| 6 |
32128-33 |
NUT-HF Price: $0.25 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 7 |
93-3193 |
DISCONTINUED Price: Call Us |
| 8 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 8 |
66-8110 |
TRIM-HOOD Price: $4.91 |
| 9 |
3290-359 |
SCREW-HWH Price: $6.23 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532140552. Price: $17.99 |
| 10 |
63-6900-01 |
LH HOOD HINGE PLATE ASM This part replaces 63-6900. Price: $23.15 |
| 11 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT This part replaces 532120068. Price: $6.99 |
| 11 |
76-4790 |
PAD-RUBBER Price: $17.89 |
| 12 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $8.99 |
| 13 |
3274-32 |
SCREW-HSBH Price: $4.79 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 14 |
66-3040-03 |
COVER-BOX, TOOL This part replaces 66-3040. Price: $26.24 |
| 14 |
872050411 |
Bolt Rdhd Sht Nk 1/4-20x1-3/8 Price: $3.99 |
| 15 |
532121249 |
SPACER SPLIT Price: $4.99 |
| 15 |
66-3050 |
DISCONTINUED Price: Call Us |
| 16 |
27-7310 |
DECAL-REFUELING Price: $27.52 |
| 16 |
532123740 |
SPRING COMPRESSED Price: $3.99 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 17 |
92-8797 |
DECAL-WARNING Price: $33.38 |
| 18 |
532124238 |
CAP SPRING Price: $4.99 |
| 18 |
95-3008 |
DECAL Price: $76.84 |
| 19 |
92-6501 |
DISCONTINUED Price: Call Us |
| 20 |
63-7310 |
DISCONTINUED Price: Call Us |
| 21 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 21 |
532139888 |
BOLT.SHOULDER.5/16-18 Price: $3.99 |
| 22 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 24 |
3234-13 |
SCREW-HHF Price: $0.77 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 25 |
32128-20 |
NUT-HF Price: $0.99 |
| 25 |
532127018 |
BOLT,SHOULD Price: $4.99 |
| 26 |
46-6810 |
SCREW AND WASHER ASM Price: $3.49 |
| 27 |
596564001 |
Bolts This part replaces 817490608. Price: $2.99 |
| 27 |
93-7830 |
DECAL-TORQUE This part replaces 67-1720. Price: $23.91 |
| 28 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 29 |
66-3200 |
TREAD-FOOTREST, LH Price: $7.38 |
| 30 |
66-3210 |
TREAD-FOOTREST, LH Price: $30.94 |
| 31 |
92-5540 |
TREAD-FOOTREST, RH Price: $23.53 |
| 32 |
63-7320 |
DISCONTINUED Price: Call Us |
| 33 |
66-8760 |
DISCONTINUED Price: Call Us |
| 34 |
53-4430 |
DECAL-OIL Price: $8.99 |
| 35 |
95-6280 |
FRAME ASM Price: $2,743.35 |
| 36 |
92-5545-01 |
COVER-TOWER, FRONT This part replaces 92-5545. Price: $78.48 |
| 37 |
62-5550 |
DECAL Price: $9.32 |
| 38 |
92-5772 |
DISCONTINUED Price: Call Us |
| 39 |
63-7300 |
DISCONTINUED Price: Call Us |
| 40 |
63-8050 |
BOX-CONTROL Price: $106.29 |
| 41 |
100-6581 |
DECAL-PANEL, TOWER Price: $10.98 |
| 42 |
63-6890-01 |
RH HOOD HINGE PLATE ASM This part replaces 63-6890. Price: $12.36 |
| 43 |
46-8091 |
SCREW-HWH Price: $3.59 |
| 44 |
283-58 |
PIN-CLEVIS Price: $3.87 |
| 45 |
66-2870 |
CABLE-HOOD STOP Price: $27.51 |
| 46 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 47 |
59-9740 |
FLEX DRAW LATCH ASM Price: $36.89 |
| 48 |
3290-271 |
RIVET-POP Price: $0.25 |
| 49 |
3296-12 |
NUT-LOCK, NI Price: $1.29 |
| 51 |
82-8950 |
FOAM Price: $13.01 |
| 53 |
92-5548-01 |
SHIELD-STOP, PEDAL This part replaces 92-5548. Price: $31.35 |
| 54 |
321-4 |
SCREW-HH Price: $0.99 |
| 63 |
62-7400 |
DECAL Price: $24.54 |
| 64 |
98-9314 |
GROMMET Price: $15.98 |
