| Ref | Part Number | Description |
|---|
| 1 |
530015880 |
Screw Price: $1.99 |
| 1 |
66-6370 |
LIFT ARM ASM This part replaces 21-3100. Price: $430.43 |
| 2 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 2 |
530058982 |
Bolt-Muffler Price: $1.99 |
| 3 |
32136-2 |
NUT-SHH Price: $3.55 |
| 4 |
21-3020-01 |
MOUNT-BALLJOINT, RH This part replaces 21-3020. Price: $178.87 |
| 4 |
530015953 |
Screw-Cylinder Price: $1.99 |
| 5 |
21-1830 |
SPRING-EXTENSION Price: $34.62 |
| 5 |
952030249 |
Spark Plug (RCJ 6Y) Price: $3.99 |
| 6 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 6 |
530012541 |
Cylinder Price: $11.99 |
| 7 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 7 |
530071750 |
Seal-Cylinder (kit) Price: $8.99 |
| 8 |
3217-8 |
NUT-HEX Price: $1.34 |
| 8 |
545154001 |
RING PISTON This part replaces 530055120. Price: $1.99 |
| 9 |
530015162 |
Retainer-Piston Pin Price: $1.99 |
| 9 |
66-7150 |
ARM-PUSH, RH This part replaces 21-2910. Price: $536.26 |
| 10 |
3272-24 |
PIN-COTTER Price: $0.54 |
| 11 |
24-9510 |
PIN Price: $77.49 |
| 11 |
530012555 |
Assy-Crankshaft Price: $17.99 |
| 12 |
5-1754 |
WASHER-FLAT Price: $2.17 |
| 13 |
256-126 |
BUSHING Price: $9.36 |
| 13 |
530071750 |
Seal-Cyl/Carb.(kit) Price: $8.99 |
| 14 |
3272-33 |
PIN-COTTER Price: $0.54 |
| 14 |
530057547 |
Adapter-Carb. Price: $7.99 |
| 15 |
23-1950-01 |
SUPPORT-REINFORCEMENT This part replaces 23-1950. Price: $69.64 |
| 15 |
530016309 |
Screw Price: $1.99 |
| 16 |
324-5 |
SCREW-HH Price: $0.54 |
| 16 |
530071750 |
Gasket-Carb. (kit) Price: $8.99 |
| 17 |
3-7292 |
PIN-CLEVIS Price: $44.11 |
| 17 |
530071822 |
KIT CARB ASSY # C1U-W24 This part replaces 530071752. Price: $29.99 |
| 18 |
5-3126 |
PIN-LYNCH Price: $0.73 |
| 18 |
530057544 |
Air Box Price: $6.99 |
| 19 |
3241-7 |
SCREW-SQH This part replaces 324-12. Price: $3.39 |
| 19 |
530016429 |
Screw Price: $1.99 |
| 20 |
21-3750 |
SUPPORT PLT Price: $14.42 |
| 20 |
530036575 |
Foam-Air Filter Price: $1.99 |
| 21 |
21-2860-01 |
PUSH ARM BRACKET ASM This part replaces 21-2860. Price: $154.46 |
| 21 |
530058740 |
Cover-Air Box Price: $5.99 |
| 22 |
32121-84 |
PIN-SPIRAL Price: $1.29 |
| 22 |
545081826 |
Kit - Ignition Module This part replaces 530039234. Price: $32.99 |
| 23 |
21-2990 |
SHAFT-PIVOT Price: $227.21 |
| 23 |
530027953 |
Coupling-Drive Price: $1.99 |
| 24 |
3296-48 |
NUT-LOCK, NI Price: $0.37 |
| 24 |
530016357 |
Screw Price: $1.99 |
| 25 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 25 |
530014663 |
Assy-Leadwire Price: $5.99 |
| 26 |
21-2960 |
ARM-PUSH, LH Price: $519.38 |
| 26 |
581425901 |
SWITCH, GROUND WIRE This part replaces 530014662. Price: $1.99 |
| 27 |
21-2900-01 |
SPRING-TORSION, LH This part replaces 21-2900. Price: $566.83 |
| 27 |
530016391 |
Screw Price: $1.99 |
| 28 |
21-2890-01 |
SPRING-TORSION, RH This part replaces 21-2890. Price: $566.83 |
| 28 |
530071969 |
Assy.-Fan Hsg Price: $27.99 |
| 29 |
324-6 |
SCREW-HH Price: $0.81 |
| 29 |
530071356 |
Kit-Switch Price: $4.99 |
| 30 |
21-3050-01 |
LH BALL JOUNT MOUNT ASM This part replaces 21-3050. Price: $153.41 |
| 30 |
530058742 |
Handle-Starter Price: $2.99 |
| 31 |
530071798 |
Kit - Rope Price: $3.99 |
| 31 |
86-8100-01 |
BALL JOINT ASM This part replaces 21-0160. Price: $137.53 |
| 32 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 32 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 33 |
21-3000-01 |
NUT-JAM, PUSH ARM This part replaces 21-3000. Price: $37.02 |
| 33 |
545008011 |
KIT STARTER SPRING This part replaces 530042086. Price: $5.99 |
| 34 |
545081852 |
Kit - Starter Pulley This part replaces 530071797. Price: $9.99 |
| 34 |
61-3610 |
WARNING DECAL This part replaces 21-3970. Price: $16.67 |
| 35 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 35 |
530057548 |
Baffle Price: $6.99 |
| 36 |
5-2942 |
SHACKLE Price: $16.99 |
| 36 |
530015880 |
Screw Price: $1.99 |
| 37 |
530015828 |
Washer-Flat Price: $1.99 |
| 38 |
545221701 |
FLYWHEEL ASSY This part replaces 530054115. Price: $8.99 |
| 40 |
530015941 |
Retain. Ring-C'shaft Price: $1.99 |
| 41 |
530055728 |
Outer Bearing Price: $6.99 |
| 42 |
530019264 |
Seal Price: $2.99 |
| 43 |
530032125 |
Inner Bearing Price: $11.99 |
| 45 |
530049817 |
CONNECTING ROD ASSY This part replaces 530069945. Price: $6.99 |
| 46 |
530071750 |
O-Ring-C'case (kit) Price: $8.99 |
| 48 |
530016386 |
Screw Price: $5.99 |
| 49 |
530058737 |
Shroud-Rear Price: $7.99 |
| 50 |
530016445 |
Retainer-Tank Price: $1.99 |
| 52 |
530058743 |
Assy-Fuel Cap Price: $7.99 |
| 53 |
530069247 |
Kit-Fuel Line (Small) Price: $3.99 |
| 54 |
530069216 |
Kit-Fuel Line (Large) Price: $3.99 |
| 55 |
530095646 |
Assy-Fuel Pickup Price: $2.99 |
