| Ref | Part Number | Description |
|---|
| 1 |
95-7522 |
AXLE Price: $377.20 |
| 2 |
503552201 |
CYLINDER PLUG Price: $6.99 |
| 2 |
99-7564 |
SEAL-OIL Price: $25.36 |
| 3 |
506412301 |
GASKET Price: $4.99 |
| 3 |
95-7544 |
CLIP Price: $4.04 |
| 4 |
588932501 |
GASKET K760 This part replaces 506376902. Price: $5.99 |
| 4 |
95-7523 |
SPACER Price: $26.89 |
| 5 |
506376702 |
CYLINDER BASE GASKET Price: $5.99 |
| 5 |
99-7555 |
SHIM 0.3 Price: $3.29 |
| 6 |
95-7525 |
GEAR-BEVEL, 27 TOOTH Price: $333.09 |
| 7 |
577572401 |
NEEDLE BEARING PISTON PIN 12X1 This part replaces 503255601. Price: $11.99 |
| 7 |
99-7534 |
BEARING-BALL Price: $65.44 |
| 8 |
522990101 |
PISTON RING This part replaces 503289047. Price: $19.99 |
| 8 |
95-7521 |
COVER-AXLE Price: $107.87 |
| 9 |
106-1071 |
O-RING This part replaces 99-7538. Price: $18.43 |
| 9 |
737431200 |
WRIST PIN CLIP Price: $3.99 |
| 10 |
505424501 |
SPRING HOLDER This part replaces 506389102. Price: $32.99 |
| 10 |
93-7775 |
BEARING-BALL This part replaces 99-7561. Price: $127.75 |
| 11 |
503215325 |
SCREW Price: $3.99 |
| 11 |
99-7539 |
CLIP Price: $11.07 |
| 12 |
104-2374 |
BOLT This part replaces 99-7596. Price: $6.33 |
| 12 |
503215316 |
SCREW Price: $3.99 |
| 13 |
506368801 |
BRACKET Price: $3.99 |
| 14 |
588915101 |
PLATE This part replaces 506375802. Price: $9.99 |
| 15 |
503215420 |
SCREW Price: $3.99 |
| 16 |
503715301 |
DECOMPRESSION VALVE Price: $29.99 |
| 18 |
587668702 |
MUFFLER KIT This part replaces 506364203. Price: $44.99 |
| 19 |
503215341 |
SCREW Price: $3.99 |
| 20 |
503215356 |
SCREW Price: $3.99 |
| 21 |
503215321 |
SCREW Price: $3.99 |
