| Ref | Part Number | Description |
|---|
| 1 |
120-5118 |
SHAFT-ADJUSTER Price: $44.64 |
| 1 |
532424543 |
WHEEL.STEERING.HARD.RIM.BLAC Price: $27.99 |
| 1 |
631984 |
THROTLE SHAFT Price: Call Us |
| 2 |
120-5116 |
WASHER-WAVE Price: $9.17 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $99.99 |
| 2 |
631036 |
SHUTTER Price: $1.20 |
| 3 |
106-5344 |
BUSHING-FLANGE, KEYED Price: $2.37 |
| 3 |
650506 |
SCREW Price: $0.87 |
| 4 |
108-0015 |
WASHER-FLAT Price: $0.39 |
| 4 |
532403087 |
SPINDLE.WELDED.LH.15"TEX Price: $22.99 |
| 4 |
630955 |
RETAINER--NLA Price: Call Us |
| 5 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 5 |
532403088 |
SPINDLE.WELDED.RH.15"T Price: $22.99 |
| 5 |
650545 |
SCREW Price: $1.20 |
| 6 |
137-6130 |
SCREW-ADJUSTER, BEDBAR This part replaces 115-7039. Price: $25.42 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $5.99 |
| 6 |
650782 |
SCREW Price: $1.20 |
| 7 |
119-4155 |
WASHER-HARDENED Price: $4.16 |
| 7 |
532121748 |
WASHER Price: $1.99 |
| 7 |
630898 |
ADJ SCREW Price: $1.69 |
| 8 |
120-5120 |
SPRING-COMPRESSION Price: $2.89 |
| 8 |
812000029 |
RING CLIP Price: $1.99 |
| 8A |
631192 |
SPRING Price: Call Us |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $1.99 |
| 9A |
631191 |
WASHER Price: $1.20 |
| 10 |
630740 |
O RING Price: $1.49 |
| 10A |
631190 |
O RING Price: Call Us |
| 11 |
631189 |
ADJ SCREW Price: Call Us |
| 12 |
630748 |
WELCH PLUG Price: $1.17 |
| 13 |
532121749 |
WASHER Price: $1.99 |
| 13 |
632554 |
WELCH PLUG This part replaces 630746. Price: $1.17 |
| 14 |
539990118 |
SLW 3/8 STD This part replaces 810040600. Price: $1.99 |
| 15 |
630932A |
INLET NEEDLE Price: $4.39 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $1.99 |
| 16 |
532429373 |
SHAFT.STEER.3/4.PLATED.TEX This part replaces 532429374. Price: $44.99 |
| 16 |
631049 |
SPRING Price: $1.20 |
| 17 |
630742 |
GASKET Price: $1.25 |
| 18 |
630978 |
DIAPHRAGM Price: $4.49 |
| 19 |
532194729 |
PLATE.STEER.DDL.NLT/NG Price: $12.99 |
| 19 |
630750A |
GASKET This part replaces 630750. Price: $3.00 |
| 20 |
532411291 |
BOOT STEERING BLACK Price: $4.99 |
| 20 |
630751 |
COVER Price: $8.60 |
| 21 |
532437747 |
STEERING.WHEEL.ADAPTER This part replaces 532186737. Price: $19.99 |
| 21 |
650545 |
SCREW Price: $1.20 |
| 22 |
532420537 |
STEERING.SUPT.LOWER. Price: $4.99 |
| 22 |
630953 |
PUMP ELEMENT Price: $6.03 |
| 26 |
532424691 |
INSERT, WHEEL STEERING Price: $4.99 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $2.99 |
| 29 |
631201 |
CHECK VALVE Price: $15.40 |
| 30A |
631202 |
FUEL FITTING Price: $9.70 |
| 33 |
810040500 |
LOCKWASHER Price: $2.99 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $19.99 |
| 45 |
819113812 |
WASHER.11/32 Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $2.99 |
| 57 |
532407465 |
BRACKET.UPSTOP.TEX Price: $2.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $4.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $3.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
532194740 |
DRAGLINK.LH.BALLSTUD.D Price: $44.99 |
| 62 |
532194741 |
DRAGLINK.RH.BALLSTUD.D Price: $44.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $2.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $2.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $2.99 |
| 67 |
532194737 |
BUSHING.PM.FRONT AXLE Price: $3.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $2.99 |
| 70 |
585338801 |
BRACKET.FRT.DECK.SUSP.RR.MT431 This part replaces 532196197. Price: $5.99 |
| 71 |
532190752 |
SHAFT.EXTEN.STRG.SPLINE Price: $9.99 |
| 72 |
532428982 |
BOLT 5/16-18 X 4 W/PATCH Price: $2.99 |
