| Ref | Part Number | Description |
|---|
| 1 |
7070E |
KEY 1/4 X 2.5 Price: Call Us |
| 1 |
98-1880-03 |
KNUCKLE-PIVOT This part replaces 98-1880. Price: $350.23 |
| 2 |
99-5610 |
PIN Price: $40.16 |
| 3 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 3 |
7563R |
WASHER T Price: Call Us |
| 4 |
32151-36 |
RING-RETAINING Price: $1.73 |
| 5 |
73680600 |
SUB= 73690600 Price: Call Us |
| 5 |
93-2704-03 |
LINK-LEFT This part replaces 93-2704. Price: $23.18 |
| 6 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 6 |
76020412 |
COTTER PIN Price: Call Us |
| 7 |
140507 |
HUB WHEEL ASM Price: Call Us |
| 7 |
98-8823 |
LINK Price: $239.39 |
| 8 |
104-1450 |
BOLT-CARR Price: $0.25 |
| 9 |
140080 |
BOLT.HUB.WHL.REAR Price: Call Us |
| 9 |
67-1750 |
BUSHING Price: $0.92 |
| 10 |
100-1270 |
SWITCH-PROXIMITY Price: $96.57 |
| 11 |
32149-7 |
NUT-KEPS Price: $0.27 |
| 12 |
99-5621 |
GUIDE-HOSE Price: $34.45 |
| 13 |
33114-020 |
SCREW-HH Price: $0.28 |
| 14 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 15 |
19131316 |
WASHER Price: Call Us |
| 15 |
3334-945 |
TIE-CABLE Price: $0.43 |
| 16 |
33108-035 |
SCREW-HHF Price: $24.13 |
| 17 |
140921 |
SPRING ROD BRAKE Price: Call Us |
| 17 |
32128-33 |
NUT-HF Price: $0.25 |
| 18 |
93-2699 |
PIN Price: $48.15 |
| 19 |
33029-00 |
NUT-LOCK, NI Price: $2.92 |
| 20 |
73940800 |
SUB= 73360800 Price: Call Us |
| 20 |
98-8821 |
LINK-REAR Price: $30.71 |
| 21 |
3229-28 |
SCREW-CARR Price: $0.81 |
| 22 |
156103 |
ARM ASM SHIFT Price: Call Us |
| 23 |
121274X |
KNOB.DUCKHEAD.1/2 Price: Call Us |
| 23 |
138-6956 |
CYLINDER ASM-HYDRAULIC This part replaces 93-2631. Price: $692.61 |
| 24 |
93-2700 |
ROLLER-PLASTIC Price: $30.55 |
| 25 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 26 |
94-1449 |
FITTING-STR,ORIF Price: $112.90 |
| 27 |
105-3358 |
NO. 7 LIFT ARM ASM Price: $1,014.80 |
| 28 |
105-3357 |
NO. 6 LIFT ARM ASM Price: $1,014.17 |
| 28 |
73350600 |
NUT Price: Call Us |
| 29 |
140494 |
ROD BRAKE Price: Call Us |
| 29 |
340-78 |
NUT-LOCK Price: $1.63 |
| 30 |
104-3740 |
DISCONTINUED Price: Call Us |
| 30 |
19131616 |
WASHER HYT Price: Call Us |
| 31 |
104-3747 |
DISCONTINUED Price: Call Us |
| 32 |
94-1444 |
UNION-BULKHEAD Price: $33.59 |
| 33 |
12000053 |
E RING HYT Price: Call Us |
| 33 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 34 |
71673 |
PLUNGER CAP T Price: Call Us |
| 34 |
92-7643 |
HYD HOSE ASM Price: $118.39 |
| 35 |
137648 |
ROD BRAKE PART GT Price: Call Us |
| 35 |
147-6067 |
PIVOT PIN ASM This part replaces 98-8826. Price: $44.62 |
| 36 |
149412 |
SPRING.GRND.DRIVE Price: Call Us |
| 36 |
94-8946 |
WASHER-THRUST Price: $1.96 |
| 37 |
121749X |
WASHER Price: Call Us |
| 37 |
2412-93 |
CLAMP-R Price: $1.02 |
| 38 |
150035 |
BUSHING.NYLINER Price: Call Us |
| 38 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 39 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 39 |
74321016 |
SCREW Price: Call Us |
| 40 |
5304J |
ACT-SWITCH T Price: Call Us |
| 40 |
98-7974 |
WASHER-THRUST Price: $37.96 |
| 41 |
73631000 |
SUB= 69180 Price: Call Us |
| 41 |
98-7993 |
SCREW-HHF Price: $3.05 |
| 42 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 42 |
8883R |
PEDAL COVER T Price: Call Us |
| 43 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 44 |
76-2980 |
WASHER-THRUST Price: $5.08 |
| 45 |
283-71 |
PIN-LYNCH Price: $2.73 |
| 46 |
105-3342-03 |
NO. 7 SUPPORT ARM ASM Price: $1,187.34 |
| 46 |
145170 |
RETAINER.SPRING Price: Call Us |
| 47 |
105-3341-03 |
NO. 6 SUPPORT ARM ASM Price: $1,033.97 |
| 47 |
138228 |
ROD.CLUTCH Price: Call Us |
| 48 |
105-3343 |
BRACKET-SWITCH Price: $32.88 |
| 48 |
72110612 |
BOLT.3/8-16X1.50 Price: Call Us |
| 50 |
131494 |
FLAT IDLER PULLEY Price: Call Us |
| 51 |
73680600 |
SUB= 73690600 Price: Call Us |
| 52 |
139123 |
PULLEY.IDLER.V.GR Price: Call Us |
| 52 |
150586 |
BRACKET.MTG.FAN Price: Call Us |
| 53 |
207J |
WASHER T Price: Call Us |
| 54 |
156563 |
ARM ASM CLUTCH Price: Call Us |
| 56 |
140218 |
BELT-V 84.5 Price: Call Us |
| 58 |
74760724 |
BOLT Price: Call Us |
| 61 |
140488 |
PULLEY TRANSAXLE Price: Call Us |
| 64 |
154752 |
SHAFT-BRAKE/CLUTC Price: Call Us |
| 65 |
67609 |
AXLE BOLT Price: Call Us |
| 66 |
140296 |
WASHER.HARD.BLADE Price: Call Us |
| 67 |
19131312 |
WASHER Price: Call Us |
| 68 |
5142H |
ROLL PIN STD Price: Call Us |
| 69 |
123800X |
WASHER Price: Call Us |
| 70 |
151146 |
SUB= 164892 Price: Call Us |
| 72 |
73680500 |
SUB= 73690500 Price: Call Us |
| 73 |
74780548 |
BOLT FIN HEX 5/16 Price: Call Us |
| 74 |
142432 |
SCREW HEXWSH H-L Price: Call Us |
| 76 |
140481 |
BRACKET TRAN VGTH Price: Call Us |
| 77 |
74760716 |
BOLT Price: Call Us |
| 78 |
19111212 |
WASHER Price: Call Us |
| 79 |
72110505 |
BOLT Price: Call Us |
| 80 |
140484 |
BRACKET TORQUE RH Price: Call Us |
| 81 |
17490612 |
SCREW Price: Call Us |
| 83 |
140479 |
STRAP TORQUE MID Price: Call Us |
| 84 |
140490 |
SPACER Price: Call Us |
| 85 |
17541020 |
SCREW YTV Price: Call Us |
| 87 |
140491 |
ADAPTER FAN Price: Call Us |
| 88 |
140492 |
SUB= 161592 Price: Call Us |
| 89 |
73680700 |
NUT GTV Price: Call Us |
| 90 |
140489 |
KEEPER BELT Price: Call Us |
| 91 |
17490644 |
SCREW.HXWSH.3/8 Price: Call Us |
| 92 |
74760520 |
BOLT Price: Call Us |
| 93 |
140502 |
LINK ASM SHIFT Price: Call Us |
| 94 |
133835 |
XMAS TREE FASTNER Price: Call Us |
| 96 |
141103 |
WASHER NICKEL PLT Price: Call Us |
| 98 |
141004 |
BRACKET SHIFT Price: Call Us |
| 99 |
17490624 |
SCREW LT Price: Call Us |
| 100 |
126881X |
WASHER COMPRESSIN Price: Call Us |
| 101 |
156106 |
WASHER-BELLVILLE Price: Call Us |
| 104 |
140480 |
BRACKET IDLER Price: Call Us |
| 105 |
17580408 |
SCREW CRT Price: Call Us |
| 106 |
142918 |
O-RING.ASM.70110 Price: Call Us |
| 108 |
142917 |
CAP.VENT.70109 Price: Call Us |
| 109 |
140929 |
SPRING BRAKE Price: Call Us |
| 113 |
73220700 |
NUT Price: Call Us |
| 117 |
73900600 |
SUB= 83923 Price: Call Us |
