| Ref | Part Number | Description |
|---|
| 1 |
105-7414 |
CENTER CASTOR ARM ASM Price: $677.95 |
| 1 |
532186093 |
WHEEL.STEERING.LEGND2.GRY This part replaces 532193943. Price: $89.99 |
| 2 |
531171101 |
SERVICE KIT AXLE HALF ASM This part replaces 532195673. Price: $59.99 |
| 2 |
92-9727 |
HOC CAP ASM Price: $78.05 |
| 3 |
596873901 |
KIT SPINDLE ASM.PNT.LH.15 This part replaces 532169840. Price: $14.99 |
| 3 |
69-1510 |
SPACER Price: $4.48 |
| 4 |
596873801 |
KIT SPINDLE ASM.PNT.RH.15" This part replaces 532169839. Price: $27.99 |
| 4 |
69-6860 |
WASHER-THRUST Price: $3.15 |
| 5 |
105-7429 |
SIDE CASTOR ARM ASM Price: $576.30 |
| 6 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 7 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 7 |
819272016 |
WASHER Price: $3.99 |
| 8 |
323-15 |
SCREW-HH Price: $1.53 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
140-6302-01 |
FORK-CASTOR This part replaces 92-7750-01. Price: $168.99 |
| 9 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $3.99 |
| 10 |
3296-53 |
NUT-LOCK, NI Price: $1.47 |
| 10 |
532175121 |
DRAGLINK.15".TIRES.2001 Price: $59.99 |
| 11 |
327-24 |
SCREW-HH Price: $7.99 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 12 |
93-9938 |
WHEEL ASM Price: $144.61 |
| 13 |
120-5587 |
PIN-CLEVIS Price: $10.38 |
| 13 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 14 |
3290-343 |
PIN-HAIR Price: $0.76 |
| 15 |
3233-4 |
SCREW-CARR Price: $1.90 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 16 |
105-7457-01 |
FORK-REAR Price: $79.33 |
| 17 |
104-7524 |
SHIM Price: $5.30 |
| 17 |
532190753 |
SHAFT STEERING SPLINE Price: $37.99 |
| 18 |
104-7529-01 |
BRACKET-CASTOR Price: $225.46 |
| 19 |
3296-45 |
NUT-HEX Price: $3.79 |
| 20 |
100-5623 |
DECAL-HOC Price: $20.17 |
| 20 |
104-3579 |
DECAL-HOC Price: $23.95 |
| 21 |
106-2047 |
ROD-TENSION Price: $9.83 |
| 22 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 23 |
107-0183 |
GUIDE-HOSE, LH Price: $130.70 |
| 24 |
3231-2 |
BOLT-CARR Price: $0.81 |
| 29 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 32 |
532171888 |
TIE ROD Price: $59.99 |
| 33 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 34 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 35 |
873540500 |
NUT, CROWNLOCK Price: $3.99 |
| 36 |
532155106 |
KIT.BUSHING.STEERING This part replaces 532155099. Price: $8.99 |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 38 |
532193652 |
INSERT.CAP.STRG.WH.GRAY Price: $11.99 |
| 39 |
596040001 |
Washers This part replaces 819113812. Price: $6.99 |
| 40 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 41 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 42 |
532145054 |
STEERING BOOT, GRAY This part replaces 532169634. Price: $11.99 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 44 |
532190752 |
SHAFT.EXTEN.STRG.SPLINE Price: $11.99 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 47 |
532183226 |
FITTING.GREASE.TAPERED Price: $4.99 |
| 65 |
532414736 |
SPACER.BRACE.AXLE This part replaces 532160367. Price: $5.99 |
| 67 |
872110618 |
BOLT CARRIAGE Price: $4.99 |
| 68 |
531167401 |
SERVICE KIT BRACE.AXLE.1 This part replaces 532169827. Price: $19.99 |
| 71 |
531167801 |
SERVICE KIT STEERING ASM This part replaces 532175146. Price: $139.99 |
| 82 |
531170201 |
SERVICE.KIT BRACKET This part replaces 532199978. Price: $19.99 |
| 88 |
532175118 |
BOLT, SHOULDER 7/16-20 Price: $4.99 |
| 91 |
532175553 |
CLIP.STEERING Price: $9.99 |
| 95 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 97 |
874780564 |
BOLT Price: $4.99 |
