| Ref | Part Number | Description |
|---|
| 1 |
114-3988 |
FAN DRIVE ASM This part replaces 74-5520. Price: $342.27 |
| 2 |
121259X |
SUB= 144725 Price: Call Us |
| 2 |
75-3780 |
FAN-ENGINE Price: $367.12 |
| 3 |
75-6380 |
SHAFT-FAN Price: $141.82 |
| 3 |
8417J |
SUB= 128772 Price: Call Us |
| 4 |
104-9312 |
PIN-GROOVED Price: $1.63 |
| 4 |
73680600 |
SUB= 73690600 Price: Call Us |
| 5 |
98-9743 |
PULLEY-DRIVE, FAN Price: $104.17 |
| 6 |
104-9259 |
WASHER-THRUST Price: $21.05 |
| 7 |
105896X |
SUB= 137607 Price: Call Us |
| 7 |
251-318 |
BEARING-BALL Price: $16.40 |
| 8 |
104-0001 |
SPACER Price: $25.45 |
| 8 |
110452X |
NUT PUSH M Price: Call Us |
| 9 |
106734X |
SUB= 123713X Price: Call Us |
| 9 |
75-4450 |
HUB Price: $205.03 |
| 10 |
106735X |
ROD-HINGE T Price: Call Us |
| 10 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 11 |
106736X |
DEFLECTOR-SHLD T Price: Call Us |
| 11 |
67-1630 |
SPACER Price: $28.84 |
| 12 |
105814X |
DECAL.LT Price: Call Us |
| 12 |
323-6 |
SCREW-HH Price: $0.66 |
| 13 |
105304X |
CAP-SLEEVE LT Price: Call Us |
| 13 |
3230-2 |
BOLT-CARR Price: $0.47 |
| 14 |
105662X |
LINK.PARALLEL Price: Call Us |
| 14 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 15 |
98-4530-03 |
SUPPORT-FAN Price: $349.24 |
| 16 |
4921H |
SPRING.RETAINER Price: Call Us |
| 16 |
98-4575-03 |
LEVER-IDLER, FAN Price: $43.57 |
| 17 |
105872X |
LINK STOP Price: Call Us |
| 17 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 18 |
109835X |
HINGE PIN T Price: Call Us |
| 18 |
98-9744 |
BELT-FAN Price: $35.29 |
| 19 |
323-8 |
SCREW-HH Price: $1.20 |
| 20 |
63-8140 |
PULLEY-IDLER Price: $47.94 |
| 21 |
109598X |
BRACKET RH LT Price: Call Us |
| 21 |
98-9740 |
BRACKET-FAN, SUPPORT Price: $42.56 |
| 22 |
109597X |
BRACKET LH T Price: Call Us |
| 22 |
322-2 |
SCREW-HH Price: $0.69 |
| 23 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 24 |
109820X |
DECAL YT Price: Call Us |
| 24 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 25 |
109503X |
SUPPORT ARM T Price: Call Us |
| 25 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 26 |
109504X |
STOP T Price: Call Us |
| 26 |
98-9741 |
BRACKET-MOUNT, FAN Price: $44.53 |
| 27 |
98-4561-03 |
SHIELD-ALTERNATOR Price: $56.98 |
| 28 |
121317X |
SUB= 126756X Price: Call Us |
| 28 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 29 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 29 |
74760632 |
SUB= 74930632 Price: Call Us |
| 30 |
108832X |
SUB= 127163X Price: Call Us |
| 30 |
80-6990 |
WASHER-HARDENED Price: $3.06 |
| 31 |
106902X |
SPACER RETAINER Price: Call Us |
| 31 |
33114-016 |
SCREW-HH Price: $0.27 |
| 32 |
121316X |
PULLEY IDLER Price: Call Us |
| 32 |
322-4 |
SCREW-HH Price: $0.35 |
| 33 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 34 |
102669X |
BELT KEEPER LT Price: Call Us |
| 36 |
100668L |
SUPPORT PLATE LT Price: Call Us |
| 40 |
19132012 |
WASHER Price: Call Us |
| 41 |
10030600 |
SUB= 10040600 Price: Call Us |
| 42 |
74610624 |
BOLT.3/8-24X1-1/2 Price: Call Us |
| 43 |
108250X |
SPRING LT Price: Call Us |
| 44 |
108235X |
ROD LT Price: Call Us |
| 45 |
4921H |
SPRING.RETAINER Price: Call Us |
| 46 |
76020312 |
SUB= 3145 Price: Call Us |
| 47 |
109892X |
ROCKSHAFT T Price: Call Us |
| 48 |
76020616 |
SUB= 76020624 Price: Call Us |
| 49 |
108247X |
ROD BRAKE LT Price: Call Us |
| 52 |
108243X |
BRACKET LT Price: Call Us |
| 53 |
108241X |
BRACKET LT Price: Call Us |
| 56 |
106578X |
BRAKE LT Price: Call Us |
| 58 |
108249X |
ROD BRAKE LT Price: Call Us |
| 60 |
100672K |
SPACER BRAKE LTV Price: Call Us |
| 61 |
100673L |
BRACKET SUPT LTV Price: Call Us |
| 65 |
7631J |
RUNNER-LH M Price: Call Us |
| 66 |
19131614 |
WASHER Price: Call Us |
| 68 |
121349X |
DECAL WARNING Price: Call Us |
| 70 |
122314X |
SPACER Price: Call Us |
| 75 |
76020308 |
SUB= 3145 Price: Call Us |
| 80 |
110445X |
SUPPORT T Price: Call Us |
| 81 |
19131316 |
WASHER Price: Call Us |
