| Ref | Part Number | Description |
|---|
| 1 |
27-7200 |
AIR CLEANER HOSE Price: $90.31 |
| 1 |
532125122 |
Rim Assembly, Rear Price: $109.99 |
| 2 |
2412-42 |
CLAMP-HOSE Price: $2.65 |
| 2 |
532420531 |
TIRE.18X9.5-8 TURF SAVER This part replaces 532106268. Price: $74.99 |
| 3 |
27-7180 |
CAP Price: $70.51 |
| 3 |
532007152 |
TUBE - UNIVERSAL FOR 8" RIM This part replaces 532124926. Price: $44.99 |
| 4 |
27-7100 |
AIR CLEANER ASM Price: $323.10 |
| 4 |
532109502 |
Spacer, Split (AYP part number) Price: $3.99 |
| 5 |
27-7160 |
DECAL-INSTALLATION Price: $19.89 |
| 5 |
532123583 |
Key, Square (AYP part number) Price: $2.99 |
| 6 |
32107-11 |
NUT-SQUARE Price: $0.22 |
| 6 |
532120898 |
Transaxle, Foote, Model No. 4360-7, 6-Speed (AYP part number) Price: $668.54 |
| 7 |
3258-19 |
SCREW Price: $0.42 |
| 7 |
810040400 |
Washer, Lock 1/4 (AYP part number) Price: $3.99 |
| 8 |
3217-6 |
NUT-HEX Price: $1.19 |
| 8 |
531003379 |
WASHER This part replaces 819091210. Price: $2.99 |
| 9 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 9 |
532121274 |
Knob, Control (AYP part number) Price: $5.99 |
| 10 |
27-7170 |
MOUNTING BAND ASM Price: $48.11 |
| 10 |
876020412 |
Pin, Cotter 1/8 x 3/4 (AYP part number) Price: $3.99 |
| 11 |
108-3833 |
FILTER-AIR This part replaces 27-7110. Price: $26.73 |
| 11 |
532106919 |
Plate, Rod, Shift (AYP part number) Price: $11.90 |
| 12 |
27-7120 |
NUT AND GASKET ASM Price: $15.55 |
| 12 |
532124461 |
Rod, Shifter (AYP part number) Price: $8.59 |
| 13 |
27-7150 |
A/C CUP ASM Price: $82.89 |
| 13 |
532105700 |
Spring, Torsion (AYP part number) Price: $4.60 |
| 14 |
27-7130 |
CLAMP ASM Price: $49.80 |
| 14 |
819151216 |
Washer 15/32 x 3/4 x 16 Ga. (AYP part number) Price: Call Us |
| 15 |
27-7140 |
SKIRT-BAFFLE Price: $85.92 |
| 15 |
876020416 |
Pin, Cotter 1/8 x 1 (AYP part number) Price: $3.99 |
| 16 |
3290-360 |
SCREW-HH Price: $4.34 |
| 16 |
532105701 |
Washer, Shift Plate (AYP part number) Price: $3.99 |
| 17 |
22-7810 |
SPACER Price: $16.90 |
| 17 |
871040412 |
Bolt, Hex 14-28 x 3/4 Gr. 8 (AYP part number) Price: $3.99 |
| 18 |
322-3 |
SCREW-HH Price: $0.79 |
| 18 |
532151332 |
SPRING, BRAKE ROD This part replaces 532106888. Price: $2.99 |
| 19 |
532110437 |
Rod, Brake (AYP part number) Price: $29.99 |
| 20 |
819131316 |
Washer 13/32 x 13/16 x 16 Ga. (AYP part number) Price: $2.99 |
| 21 |
532121520 |
Strap, Torque (AYP part number) Price: $3.99 |
| 22 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $3.99 |
| 23 |
532109167 |
Bracket, Transaxle (AYP part number) Price: $2.86 |
| 24 |
812000028 |
Ring, Retainer (AYP part number) Price: $4.99 |
| 25 |
532121749 |
Washer 25/32 x 1-1/4 x 16 Ga. (AYP part number) Price: $1.99 |
| 26 |
532125096 |
Key, Woodruff # 9 3/16 x 3/4 (AYP part number) Price: $3.99 |
| 27 |
532123666 |
Pulley, Input, Transaxle (AYP part number) Price: $22.99 |
| 28 |
532059192 |
Cap, Valve (AYP part number) Price: $3.99 |
| 29 |
532065139 |
Stem, Valve (AYP part number) Price: $5.99 |
| 30 |
812000001 |
E-Ring (AYP part number) Price: $2.99 |
| 31 |
874760644 |
Bolt, Hex 3/8-16 x 2-3/4 (AYP part number) Price: $3.99 |
| 32 |
873680600 |
Nut 3/8-16 Price: $1.99 |
| 33 |
874760612 |
Bolt, Hex 3/8-16 x 3/4 (AYP part number) Price: $1.99 |
| 34 |
539976934 |
HCS 5/16C X 3/4 This part replaces 817490512. Price: $1.99 |
| 35 |
532104757 |
Cap, Axle (AYP part number) Price: $1.99 |
| 36 |
532121748 |
Washer 25/32 x 1-5/8 x 16 Ga. (AYP part number) Price: $1.99 |
| 37 |
532146682 |
SPRING,BRAKE RETURN This part replaces 532110422. Price: $4.99 |
| 38 |
532002751 |
Clip, Insulated (AYP part number) This part replaces 532124996. Price: $2.42 |
| 40 |
819111214 |
Washer 11/32 x 3/4 x 14 Ga. (AYP part number) Price: Call Us |
