| Ref | Part Number | Description |
|---|
| 1 |
98-7993 |
SCREW-HHF Price: $3.05 |
| 3 |
138457 |
BRKT.ASM.SW.44/50 Price: Call Us |
| 3 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 4 |
110-0009 |
JOINT ARM ASM Price: $199.32 |
| 5 |
104-9319 |
PIN-GROOVED Price: $6.58 |
| 5 |
4939M |
SUB= 85902 Price: Call Us |
| 6 |
130832 |
SUB= 130833 Price: Call Us |
| 6 |
282-4 |
SHACKLE Price: $32.98 |
| 7 |
104-0028 |
GUIDE-HOSE Price: $46.21 |
| 8 |
850857 |
BLADE BOLT Price: Call Us |
| 9 |
10030600 |
SUB= 10040600 Price: Call Us |
| 9 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 10 |
105-7512 |
PIN-TIE, BOW Price: $4.27 |
| 10 |
140296 |
WASHER.HARD.BLADE Price: Call Us |
| 11 |
157353 |
SUB= 159705 Price: Call Us |
| 11 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 12 |
129895 |
BEARING.BALL Price: Call Us |
| 12 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 13 |
137553 |
SHAFT.ASM.W/BRNG Price: Call Us |
| 14 |
137152 |
HOUSING.MAND.44.V Price: Call Us |
| 15 |
110485X |
BEARING Price: Call Us |
| 15 |
93-0142 |
BUSHING-STRAIGHT Price: $3.21 |
| 16 |
140329 |
STRIPPER RND MWR Price: Call Us |
| 16 |
94-4919-03 |
BRACKET-CLAMP, HOSE Price: $19.76 |
| 17 |
322-13 |
SCREW-HH Price: $2.73 |
| 18 |
72140505 |
BOLT Price: Call Us |
| 18 |
75-4520 |
SPRING-TORSION, RH Price: $25.31 |
| 19 |
132827 |
BOLT SHD 5/16-18 Price: Call Us |
| 19 |
75-4530 |
SPRING-TORSION, LH Price: $25.31 |
| 20 |
145055 |
BAFFFLE.VORTEX.46 Price: Call Us |
| 21 |
73680500 |
SUB= 73690500 Price: Call Us |
| 22 |
134753 |
STIFFENER BRKT Price: Call Us |
| 22 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 23 |
100-3828 |
DISCONTINUED Price: Call Us |
| 23 |
131267 |
DEFLECTOR BRKT Price: Call Us |
| 24 |
100-3827 |
LH REAR LIFT ARM ASM Price: $720.05 |
| 24 |
105304X |
CAP-SLEEVE LT Price: Call Us |
| 25 |
123713X |
SPRING TORSION Price: Call Us |
| 25 |
256-115 |
WASHER-THRUST Price: $1.90 |
| 26 |
110452X |
NUT PUSH M Price: Call Us |
| 26 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 27 |
157788 |
SHIELD DEFLECTOR Price: Call Us |
| 27 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 28 |
19111016 |
WASHER Price: Call Us |
| 28 |
32136-4 |
NUT-HEX,SLOTTED This part replaces 322-12. Price: $1.56 |
| 29 |
131491 |
HINGE ROD Price: Call Us |
| 29 |
84-2451 |
CHAIN-STRAIGHT, 5 LINK Price: $9.25 |
| 30 |
100-3834-03 |
ROD-PIVOT Price: $69.13 |
| 30 |
138776 |
SUB= 157722 Price: Call Us |
| 31 |
129963 |
WASHER Price: Call Us |
| 32 |
153531 |
PULLEY.MAND.36/46 Price: Call Us |
| 33 |
137266 |
SUB= 139729 Price: Call Us |
| 34 |
144945 |
ANCHOR.SPRING.46 Price: Call Us |
| 35 |
17490628 |
SCREW LT Price: Call Us |
| 36 |
19131316 |
WASHER Price: Call Us |
| 37 |
131494 |
FLAT IDLER PULLEY Price: Call Us |
| 39 |
144917 |
PULLEY.DRV.DCK.46 Price: Call Us |
| 41 |
17490620 |
SCREW Price: Call Us |
| 42 |
122052X |
SPACER RETAINER Price: Call Us |
| 43 |
144949 |
ARM.IDLER.DECK.46 Price: Call Us |
| 44 |
133943 |
HARDENED WASHER Price: Call Us |
| 45 |
145059 |
COVER.MANDREL.46 Price: Call Us |
| 46 |
137729 |
SCREW.1/4-20X5/8 Price: Call Us |
| 47 |
144959 |
BELT-V.SEC.46.KEL Price: Call Us |
| 48 |
139573 |
BELT V PRIM 50 Price: Call Us |
| 49 |
73680600 |
SUB= 73690600 Price: Call Us |
| 50 |
72110612 |
BOLT.3/8-16X1.50 Price: Call Us |
| 51 |
153390 |
WASHER.FELT. Price: Call Us |
| 72 |
19131616 |
WASHER HYT Price: Call Us |
| 90 |
74760616 |
BOLT Price: Call Us |
| 91 |
132274 |
SUB= 532132274 Price: Call Us |
| 92 |
73800600 |
NUT Price: Call Us |
| 93 |
19171416 |
WASHER Price: Call Us |
| 94 |
132264 |
SUB= 532132264 Price: Call Us |
| 95 |
132273 |
SUB= 532132273 Price: Call Us |
| 116 |
4898H |
BOLT M Price: Call Us |
| 117 |
105455X |
WHEEL.GAGE.BLK.PL Price: Call Us |
| 118 |
73930600 |
LOCKNUT Price: Call Us |
| 119 |
19121414 |
WASHER Price: Call Us |
| 120 |
19171512 |
WASHER Price: Call Us |
| 126 |
144948 |
ARM.IDLER.PRIM.46 Price: Call Us |
| 127 |
146763 |
PULLEY.IDLER.4.25 Price: Call Us |
| 143651 |
MANDREL |
SERV ASM Price: Call Us 143651 |
