| Ref | Part Number | Description |
|---|
| 1 |
532183496 |
HANDLE This part replaces 532192518. Price: $11.99 |
| 1 |
76-2760 |
HOSE ASSEMBLY Price: $259.75 |
| 2 |
532175245 |
HANDLE.LOWER.21.FWGD.BLACK This part replaces 532153418. Price: $19.99 |
| 2 |
76-2750 |
HOSE ASSEMBLY Price: $277.12 |
| 3 |
237-58 |
O-RING Price: $2.18 |
| 3 |
532185578 |
BAIL.CONT.WIRE.DSTRT.FGD.ORANG Price: $12.99 |
| 4 |
340-142 |
FITTING-ELBOW-90 Price: $65.90 |
| 4 |
532183567 |
CABLE.ENGINE BRAKE.MZR This part replaces 532182755. Price: $14.99 |
| 5 |
237-81 |
O-RING Price: $2.76 |
| 5 |
532183724 |
KIT.KNOB.HANDLE.SERVICE This part replaces 532131959. Price: $9.99 |
| 6 |
532185577 |
HANDLE.KNOB.BLACK Price: $7.99 |
| 6 |
76-2770 |
HOSE ASM Price: $271.52 |
| 7 |
237-22 |
O-RING Price: $2.43 |
| 7 |
532051793 |
HAIRPIN COTTER Price: $5.99 |
| 8 |
532007192 |
WIRE TIE This part replaces 532066426. Price: $7.99 |
| 8 |
69-4320 |
FITTING-HYD, 90 DEG Price: $154.75 |
| 9 |
237-42 |
O-RING Price: $2.78 |
| 10 |
32128-21 |
NUT-HF Price: $0.39 |
| 10 |
532128415 |
RIVET BLIND Price: $3.99 |
| 11 |
532182538 |
SUPPORT BRACKET LH Price: $3.99 |
| 11 |
94-4907 |
MOTOR-HYD This part replaces 93-4363. Price: $1,685.80 |
| 12 |
3231-28 |
SCREW-CARR Price: $1.92 |
| 12 |
532421560 |
KIT.BRACKET.SUPPORT.RH.21.FWGD This part replaces 532182539. Price: $17.99 |
| 13 |
19-1470 |
SCREW-SHOULDER Price: $3.49 |
| 13 |
817060410 |
SCREW 14-20 X 5/8 Price: $3.99 |
| 14 |
532434513 |
BRACKET.ASM.HNDL.LT.21.FGD.HW This part replaces 532182543. Price: $11.99 |
| 14 |
69-6960 |
SPACER-IDLER Price: $22.57 |
| 15 |
140-5848 |
PULLEY-IDLER This part replaces 63-1540. Price: $62.48 |
| 15 |
532434512 |
BRACKET.ASM.HNDL.RT.21.FGD.HW This part replaces 532182545. Price: $11.99 |
| 16 |
325-7 |
SCREW-HH Price: $1.53 |
| 16 |
532180071 |
SPRING LH Price: $4.99 |
| 17 |
532180072 |
SPRING.REAR.DOOR.EZ.21 Price: $4.99 |
| 17 |
69-9290 |
PAD-BUMPER Price: $9.52 |
| 18 |
32108-103 |
SCREW-FH Price: $0.68 |
| 18 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 532132004. Price: $1.99 |
| 19 |
32128-20 |
NUT-HF Price: $0.99 |
| 19 |
586122501 |
KIT.ROPE.GUIDE.T-KNOB This part replaces 532179585. Price: $7.99 |
| 20 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 20 |
532413159 |
SKIRT.REAR.21 FWGD.BLACK This part replaces 532189005. Price: $14.99 |
| 21 |
32120-72 |
RING-SNAP Price: $2.09 |
| 21 |
532088652 |
HINGE SCREW Price: $3.99 |
| 22 |
256-188 |
BUSHING Price: $5.70 |
| 22 |
532184941 |
PULLEY.ENG.25MMM Price: $14.99 |
| 23 |
532187723 |
HI-PRO KEY Price: $3.99 |
| 23 |
69-6610-01 |
ARM-IDLER This part replaces 69-6610. Price: $84.61 |
| 24 |
325-8 |
SCREW-HH Price: $3.52 |
| 25 |
532150406 |
BOLT 3/8-16X1-1/8 Price: $4.99 |
| 25 |
69-5430-03 |
PULLEY-IDLER, FLAT This part replaces 69-5430. Price: $63.15 |
| 26 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532083923. Price: $3.99 |
| 26 |
69-6970 |
SPACER-IDLER, FLAT Price: $13.54 |
| 27 |
32105-1 |
SCREW-SHH Price: $3.19 |
| 27 |
532180552 |
WHEEL.14X2.PR.RADII.SILV.MAG.B This part replaces 532185572. Price: $64.99 |
| 28 |
256-117 |
BUSHING Price: $4.07 |
| 28 |
532160828 |
SHOULDER BOLT Price: $3.99 |
| 29 |
3269-25 |
RIVET-POP Price: $0.27 |
| 30 |
532175574 |
ARM.ASM.AXLE.HW.RR. This part replaces 532182541. Price: $6.99 |
| 30 |
69-6780 |
DISCONTINUED Price: Call Us |
| 31 |
532185575 |
SELECTOR KNOB Price: $2.99 |
| 31 |
69-6870 |
PLATE-MAGNET Price: $4.91 |
| 32 |
532175053 |
SPRING.SELECTOR.21.FWG This part replaces 532182537. Price: $3.99 |
| 32 |
69-6260 |
MAGNET Price: $58.32 |
| 33 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 33 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 34 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 34 |
532175575 |
ARM ASM.AXLE.H/W.LR.BZP This part replaces 532182542. Price: $6.99 |
| 35 |
32128-23 |
NUT-HF Price: $1.51 |
| 36 |
532184193 |
BOLT Price: $4.99 |
| 36 |
76-1670-03 |
SPRING-EXTENSION This part replaces 76-1670. Price: $24.92 |
| 37 |
3217-9 |
NUT-HH Price: $0.37 |
| 37 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 532150078. Price: $4.99 |
| 38 |
532183901 |
SPACER.34X1.38X.22 Price: $5.99 |
| 38 |
69-6550 |
TENSIONER WA Price: $72.13 |
| 39 |
95-0833 |
DECAL-BELT ROUTING,CENTER This part replaces 82-2560. Price: $20.90 |
| 40 |
43-8480 |
DECAL-DANGER Price: $6.49 |
| 41 |
13-4969 |
FRONT DECK W/DECALS Price: $3,199.64 |
| 41 |
532192325 |
SCREW.HEX.WSH Price: $4.99 |
| 42 |
3233-27 |
SCREW-CARR Price: $2.17 |
| 43 |
585472601 |
KIT.SHIELD.DEBRIS.22FD/21RD This part replaces 532175083. Price: $25.99 |
| 43 |
98-0755-03 |
PLATE - TENSIONER,ASM This part replaces 69-6490. Price: $74.44 |
| 44 |
77-2830 |
SPRING ROD Price: $85.37 |
| 45 |
3272-7 |
PIN-COTTER Price: $0.25 |
| 45 |
581579101 |
DECAL.CUTFINGER.CE.02 This part replaces 532107339. Price: $3.99 |
| 46 |
532418373 |
ADAPTER.BLADE.W/KEY.25MM.CE This part replaces 532184590. Price: $9.99 |
| 47 |
532189028 |
BLADE.21.PUSH/RWGD/FWG Price: $19.99 |
| 47 |
69-6890 |
DISCONTINUED Price: Call Us |
| 48 |
532851074 |
WASHER,HARDEN Price: $3.99 |
| 48 |
86-7480 |
COMPRESSION SPRING Price: $35.91 |
| 49 |
596238701 |
Washers This part replaces 532850263. Price: $3.99 |
| 50 |
23-1640 |
BUSHING-TAPERLOCK Price: $68.50 |
| 50 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.50 |
| 51 |
63-0660 |
GEARBOX PULLEY WA Price: $80.31 |
| 52 |
69-6390 |
DISCONTINUED Price: Call Us |
| 53 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 54 |
69-6790 |
RH CENTER COVER Price: $140.29 |
| 56 |
95-0845 |
DECAL-HOC This part replaces 71-4260. Price: $11.75 |
| 57 |
95-0817 |
DECAL-HOC This part replaces 69-0820. Price: $10.90 |
| 58 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 59 |
3233-30 |
SCREW-CARR Price: $3.26 |
| 59 |
532175071 |
DISCHARGE DEFLECTOR This part replaces 532185582. Price: $17.99 |
| 60 |
532175735 |
BRACKET.ASM.HINGE.21.FWGD. Price: $4.99 |
| 60 |
66-1340 |
DECAL-DANGER, THROWN OBJECT Price: $9.07 |
| 61 |
532193000 |
SPRING.TORSION This part replaces 532175285. Price: $5.99 |
| 61 |
93-9324 |
IDLER PIVOT WA Price: $54.15 |
| 62 |
532175650 |
ROD.HINGE.21 Price: $4.99 |
| 63 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 64 |
532185576 |
DOOR.MULCH.21.REAR.FWGD Price: $11.99 |
| 65 |
532197480 |
O-RING..070X.487.NEOPRENE This part replaces 532188152. Price: $3.99 |
| 66 |
532088348 |
WASHER.FLAT.1/2 Price: $3.99 |
