| Ref | Part Number | Description |
|---|
| 1 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 2 |
59-5560 |
CAP-DUST Price: $27.70 |
| 3 |
13-7749 |
HOUSING AND BEARING ASM This part replaces 59-5550. Price: $281.00 |
| 4 |
59-6140 |
BEARING Price: $92.24 |
| 5 |
93-1414 |
SEAL-GREASE This part replaces 253-145. Price: $7.54 |
| 6 |
48-8880 |
PIN-DOWEL Price: $1.70 |
| 7 |
59-5830-01 |
COVER-FRAME This part replaces 59-5830. Price: $35.24 |
| 8 |
49-2040 |
SCREW-HWHTF This part replaces 11-9760. Price: $1.99 |
| 9 |
14-0829 |
REEL FRAME ASM This part replaces 12-4679. Price: $887.17 |
| 10 |
59-7790 |
DISCONTINUED Price: Call Us |
| 11 |
100-9993 |
FRONT COVER ASM This part replaces 59-5840. Price: $44.16 |
| 12 |
59-5580-01 |
HANDLE ASM This part replaces 59-5580. Price: $80.66 |
| 13 |
59-5630 |
ROLLER ASM Price: $479.63 |
| 14 |
253-84 |
SEAL-OIL Price: $10.00 |
| 15 |
257-5 |
WASHER-THRUST Price: $1.83 |
| 16 |
257-6 |
BEARING-THRUST Price: $4.78 |
| 17 |
52-2980 |
S.P.A. PIVOT Price: $107.93 |
| 18 |
52-3000 |
SPRING ARM Price: $35.27 |
| 19 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 20 |
325-7 |
SCREW-HH Price: $1.53 |
| 21 |
3218-18 |
NUT-JAM Price: $0.57 |
| 22 |
52-2990 |
SPRING RET CAPSCREW Price: $8.73 |
| 23 |
3296-28 |
NUT-LOCK, NI Price: $0.61 |
| 24 |
3296-62 |
NUT-LOCK,NI Price: $5.72 |
| 25 |
5-4373 |
SPRING Price: $29.24 |
| 26 |
29-8870 |
WASHER Price: $1.66 |
| 27 |
62-6110 |
BUSHING ASM Price: $15.47 |
| 28 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 29 |
256-292 |
BUSHING-FLANGE, NI Price: $2.54 |
| 30 |
84-6090 |
BOLT-SHOULDER This part replaces 66-5570. Price: $11.86 |
| 31 |
256-252 |
BEARING-FLANGE Price: $5.35 |
| 32 |
75-7680-01 |
DEFLECTOR-GRASS ASM This part replaces 52-9660. Price: $93.26 |
| 33 |
3296-48 |
NUT-LOCK, NI Price: $0.37 |
| 34 |
48-9050 |
SHIELD-PLATE, DRIVE Price: $15.38 |
| 35 |
62-6480-01 |
DRIVE HSG LH (MACH) This part replaces 62-6480. Price: $222.75 |
| 36 |
59-5780 |
ROLLER BUSHING ASM Price: $21.34 |
| 37 |
324-6 |
SCREW-HH Price: $0.81 |
| 39 |
59-5770-01 |
HOUSING-ADJUSTMENT This part replaces 59-5770. Price: $71.35 |
| 40 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 41 |
59-5820 |
NUT-CONE Price: $12.82 |
| 42 |
84-6160 |
COLLAR AND BUSHING ASM This part replaces 59-5700. Price: $118.96 |
| 43 |
47-7170 |
GASKET-COVER Price: $22.96 |
| 44 |
48-9081-01 |
COVER-DRIVE HOUSING, LH This part replaces 48-9081. Price: $52.14 |
| 45 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 46 |
3290-440 |
WASHER-BELLEVILLE Price: $7.46 |
| 47 |
48-9020 |
BOLT-SHOULDER Price: $16.08 |
| 48 |
59-7490 |
PLUG-FITTING, GREASE Price: $3.54 |
| 49 |
32121-50 |
PIN-SPRING Price: $1.21 |
| 50 |
59-6190 |
CAPSCREW-SHAFT, REEL Price: $22.17 |
| 51 |
3254-4 |
WASHER-LOCK/INT Price: $0.34 |
| 52 |
59-6150 |
WASHER-PULLEY Price: $15.54 |
| 53 |
47-7140 |
PULLEY-DRIVEN Price: $290.32 |
| 54 |
59-5570 |
ADJ PIN Price: $44.33 |
| 55 |
32151-71 |
RING-RETAINING, INTERNAL Price: $2.10 |
| 56 |
256-113 |
BUSHING-FLANGE Price: $5.58 |
| 57 |
323-7 |
SCREW-HH Price: $0.65 |
| 58 |
59-5600 |
LH BRACKET Price: $119.40 |
| 59 |
57-5190 |
SCREW-SET, HSH Price: $5.50 |
| 60 |
3296-26 |
NUT-LOCK, NI Price: $2.99 |
| 61 |
62-6090 |
SHIM Price: $2.44 |
| 62 |
3257-3 |
KEY-WOODRUFF Price: $0.99 |
| 63 |
38-7330 |
SHIELD WASHER Price: $6.11 |
| 64 |
12-4459 |
DISCONTINUED X-REF Price: Call Us |
| 65 |
76-3580 |
SPACER-BEDBAR AND SIDEPLATE This part replaces 48-9240. Price: $0.68 |
| 66 |
59-5470-01 |
BEDBAR-5 AND 7 BLADE This part replaces 59-5470. Price: $477.81 |
| 67 |
59-5890 |
BEDKNIFE (FAIRWAY) Price: $99.28 |
| 68 |
119-4151 |
SCREW-BEDKNIFE This part replaces 57-4910. Price: $0.41 |
| 69 |
3290-473 |
WASHER-BELLEVILLE Price: $12.89 |
| 70 |
62-6080 |
BOLT-SHOULDER Price: $12.08 |
| 71 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 72 |
32121-2 |
PIN-ROLL, SLOTTED Price: $0.25 |
| 73 |
77-4810 |
BLOCK-DEFLECTOR This part replaces 62-6070. Price: $7.47 |
| 74 |
32108-101 |
SCREW-FH Price: $0.47 |
| 75 |
47-7160 |
BELT Price: $26.00 |
