| Ref | Part Number | Description |
|---|
| 0010 |
1757995YP |
ASSEMBLY-PULLEY Price: $36.37 |
| 0020 |
1736105SM |
CLUTCH, ELECTRIC Price: $348.49 |
| 0025 |
703586 |
TIE, SELF LOCKING Price: $4.05 |
| 0030 |
1708264SM |
WASHER, HEX, 0.453ID Price: $7.67 |
| 0060 |
1737421AYP |
GUIDE, Belt Price: $11.34 |
| 0090 |
703054 |
SCREW, 1/4-20X0.625 Price: $3.82 |
| 0095 |
703332 |
WASHER Price: $3.72 |
| 0100 |
1921880SM |
LOCKWASHER-EXTERNALTO Price: $2.97 |
| 0110 |
84008807 |
MUFFLER ASSEMBLY Price: $94.29 |
| 0120 |
1759502AYP |
SHIELD, Heat Price: $58.97 |
| 0140 |
690970 |
GASKET, Exhaust Price: $4.13 |
| 0150 |
703185 |
BOLT, Round Head, Short Square Neck Price: $2.87 |
| 0160 |
703115 |
NUT Price: $3.06 |
| 0170 |
5050831X11FS |
HOSE, FUEL Price: $5.95 |
| 0180 |
691038 |
CLAMP, Hose Price: $3.12 |
| 0190 |
1759205YP |
CONTROL-THROTTLE Price: $40.25 |
| 0210 |
1739312YP |
KNOB, THROTTLE Price: $10.42 |
| 0220 |
797483 |
SCREW Price: $3.66 |
| 0230 |
703460 |
NUT, Hex #8-32 Price: $3.24 |
| 0280 |
1759431AYP |
PANEL, Control (Choke & Hourmeter) Black Price: $36.56 |
| 0285 |
7046780SM |
PLUG, Hole, .44” OD Price: $4.19 |
| 0290 |
5022665SM |
BODY CLIP, 1/4-20 X 1 Price: $2.76 |
| 0310 |
7090999FS |
SCREW Price: $3.62 |
| 0340 |
797420YP |
GUARD, Debris Screen Price: $34.58 |
| 0350 |
799359 |
SCREW Price: $3.70 |
| 0370 |
5025585YP |
BELLEVILLE WASHER Price: $3.85 |
| 0380 |
703350 |
WASHER Price: $3.72 |
| 0390 |
703115 |
NUT Price: $3.06 |
