| Ref | Part Number | Description |
|---|
| 1 |
108-0638 |
BOTTLE-OVERFLOW Price: $33.20 |
| 2 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 3 |
109-0309 |
HOSE-FUEL Price: $18.99 |
| 3 |
532430771 |
LOGO.HUSQ.GT.LT.CROWN.H This part replaces 532405012. Price: $5.99 |
| 4 |
106-1126 |
HOSE-FUEL Price: $10.06 |
| 5 |
532408701 |
DASH.ASM.HUSQ.GT.E.RECT.W/CK Price: $54.99 |
| 5 |
62-5480 |
ISOLATER-SEAT Price: $33.99 |
| 6 |
138-6160 |
RADIATOR This part replaces 106-5291. Price: $2,209.91 |
| 7 |
131-5779 |
SHROUD-FAN Price: $150.48 |
| 8 |
106-5180-03 |
SHROUD-RADIATOR Price: $244.19 |
| 9 |
106-5185 |
BRACE-RADIATOR Price: $15.47 |
| 10 |
2412-150 |
CLIP-J Price: $1.63 |
| 11 |
240-3 |
GROMMET-RUBBER Price: $17.44 |
| 12 |
32128-20 |
NUT-HF Price: $0.99 |
| 13 |
98-4695 |
SPACER Price: $4.74 |
| 14 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 14 |
532442396 |
HOOD.ASM.HUSQVARNA.GT.TEX.ORAN This part replaces 532411046. Price: $149.99 |
| 15 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 15 |
532198907 |
LENS.LH.TEX.GT.HUSQ.CL Price: $22.99 |
| 16 |
322-3 |
SCREW-HH Price: $0.79 |
| 17 |
322-1 |
SCREW-HH Price: $0.22 |
| 18 |
107-8675 |
SEAL-FOAM Price: $2.44 |
| 18 |
532408607 |
GRILL.ASM.HUSQ.TG/CRD.W/TRIM Price: $129.99 |
| 19 |
107-8676 |
SEAL-FOAM Price: $1.96 |
| 20 |
107-8677 |
SEAL-FOAM Price: $0.73 |
| 21 |
107-8678 |
SEAL-FOAM Price: $0.78 |
| 22 |
3256-56 |
WASHER-FLAT Price: $1.15 |
| 23 |
3269-18 |
RIVET-BLIND Price: $1.15 |
| 24 |
119-4992 |
HOSE-RADIATOR Price: $26.84 |
| 25 |
106-5239 |
HOSE-RADIATOR, UPPER Price: $95.32 |
| 25 |
532198906 |
LENS.RH.TEX.GT.HUSQ.CL Price: $32.99 |
| 26 |
2412-111 |
CLAMP Price: $4.39 |
| 27 |
136-2315 |
BAFFLE-HEAT Price: $3.54 |
| 28 |
119-5037 |
BAFFLE-HEAT, RH Price: $6.70 |
| 29 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 30 |
119-9393 |
SHIELD-FRONT HEAT, ENGINE Price: $308.59 |
| 31 |
3256-82 |
WASHER-FLAT Price: $0.47 |
| 32 |
32104-32 |
SCREW-HWH Price: $1.99 |
| 33 |
94-7007 |
COOLER-OIL Price: $1,430.00 |
| 34 |
125-5880 |
HOSE-COOLER, OIL Price: $46.55 |
| 34 |
580910801 |
PLATE.ENGINE.WELDED.CHASSIS This part replaces 532196125. Price: $59.99 |
| 35 |
112-7835 |
FTG-STR,SPCL Price: $65.32 |
| 36 |
2412-129 |
CLAMP-HOSE Price: $2.10 |
| 36 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 37 |
130-7102-0P |
BRACKET-RESERVOIR This part replaces 130-7102-03. Price: $15.79 |
| 37 |
532441208 |
FENDER.PNT.TX.GT.CH/FW/DL.HUSQ This part replaces 532401825. Price: $219.99 |
| 38 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 40 |
120-0627 |
DECAL-WARNING Price: $5.94 |
| 41 |
106-6755 |
DECAL-CAP, RADIATOR Price: $18.49 |
| 42 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 43 |
136-2316 |
BAFFLE-FOAM Price: $3.97 |
| 44 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 52 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 58 |
532194314 |
BRKT.SUPPORT.FNDR/TANK Price: $17.99 |
| 68 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 76 |
532402681 |
ROD UPSTOP Price: $14.99 |
| 77 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 99 |
532406642 |
ROD.BYPASS.HYDRO.0510/0610.GT Price: $14.99 |
| 130 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 137 |
532407590 |
BUMPER DASH Price: $3.99 |
| 150 |
532198512 |
AIR.DUCT.HOOD.TEX.GT.HUSQ Price: $29.99 |
| 152 |
531169901 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532199535. Price: $19.99 |
| 161 |
532401801 |
FUEL WINDOW This part replaces 532401826. Price: $5.99 |
| 162 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 165 |
532196826 |
SUPPORT.TANK.REAR.W/TEX Price: $22.99 |
| 175 |
590607702 |
PLATE.PNT.CROSSMEMBER.HUSQ/PRE This part replaces 532196304. Price: $32.99 |
| 176 |
532400776 |
SCREW.#10-24X5/8.RN.QU Price: $4.99 |
| 177 |
532195227 |
BUSHING, STEERING Price: $5.99 |
| 178 |
532199782 |
CARGO.ASM.NET.TXGT.W/C Price: $29.99 |
| 180 |
582033001 |
KITS.WELD.CHASSIS.195477X431 This part replaces 532195477. Price: $249.99 |
| 181 |
532403025 |
BUSHING.MNT.FEND.CRGO. Price: $4.99 |
| 182 |
532406859 |
DASH.LOWER.COMMON.12V.ADAPTOR This part replaces 532194787. Price: $84.99 |
| 183 |
595305701 |
Screws This part replaces 874780520. Price: $3.99 |
| 189 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 194 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 195 |
532404137 |
PLUG.HOLE.DASH.LOWER.12V.BLK Price: $4.99 |
| 196 |
532400299 |
RP CONSOLE.ASM.DECKLFT.W/ Price: $69.99 |
| 199 |
532198259 |
PLATE.DECK.LIFT.HUSQVARNA.GT Price: $17.99 |
| 202 |
532403048 |
VENT.SIDE.HOOD.HUSQ.RH.GREY Price: $7.99 |
| 203 |
532403076 |
VENT.SIDE.HOOD.HUSQ.LH.GRAY Price: $7.99 |
| 204 |
532416615 |
VENT.ASM.TORPHD.HUSQGT.LOGO.CL This part replaces 532198904. Price: $16.99 |
| 205 |
532401709 |
SKIRT.HOOD.SIDE.HUSQ.RH.GREY Price: $6.99 |
| 206 |
532401711 |
SKIRT.HOOD.SIDE.HUSQ.LH.GREY Price: $5.99 |
| 207 |
532197198 |
BEZEL.RH.TEX.GT.HUSQ Price: $19.99 |
| 208 |
532197199 |
BEZEL.LH.TEX.GT.HUSQ Price: $17.99 |
| 209 |
532199130 |
INSERT.HEX.GRILL.HUSQ.GREY Price: $4.99 |
| 210 |
532199131 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 211 |
532199132 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 212 |
532199133 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 213 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 214 |
532199145 |
CLIP.RETAINER.TINNER. Price: $2.99 |
| 217 |
532409167 |
ROD.PIVOT.HOOD This part replaces 532156524. Price: $9.99 |
| 218 |
532196395 |
X-PIECE.HOOD.STOP.NON/ Price: $6.99 |
| 221 |
532198909 |
REFLECTOR.LH.TEX GT HU Price: $14.99 |
| 228 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 234 |
532404742 |
BUMPER.HOOD.TEX.HUSQVARNA Price: $5.99 |
| 235 |
596564201 |
Spacers This part replaces 532406129. Price: $4.99 |
| 236 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
| 238 |
532408606 |
TRIM.HUSQ.TG/CRD.SERVICE Price: $17.99 |
| 239 |
532110452 |
NUT PUSH M Price: $2.99 |
