| Ref | Part Number | Description |
|---|
| 1 |
170771 |
Control Th/ch Flag Price: Call Us |
| 1 |
340-3 |
FITTING-STRAIGHT Price: $10.42 |
| 2 |
17720408 |
Screw Hex Thd Cut 1/4-20x5/8 T Price: Call Us |
| 2 |
83-1450 |
SENSOR-LEVEL, OIL Price: $265.93 |
| 3 |
237-80 |
O-RING Price: $6.10 |
| 4 |
136-8550 |
KIT-HYDRAULIC TANK This part replaces 105-9783. Price: $1,272.96 |
| 4 |
149723 |
Muffler Exhaust Price: Call Us |
| 5 |
159955 |
Exhaust Tube LH Price: Call Us |
| 5 |
83-1520 |
SCREEN-FILLER Price: $35.12 |
| 6 |
160589 |
Exhaust Tube RH Price: Call Us |
| 6 |
354-121 |
FITTING-STR Price: $17.60 |
| 8 |
171877 |
Bolt 5/16-18 UNC x 3/4 Price: Call Us |
| 8 |
93-7160 |
CAP-OIL, HYD Price: $42.72 |
| 9 |
2412-141 |
CLAMP-DRIVE, WORM Price: $2.40 |
| 10 |
140-5278 |
HOSE-FORMED This part replaces 83-2070. Price: $19.31 |
| 10 |
162797 |
Shield Browning Price: Call Us |
| 11 |
10040500 |
Washer Lock 5/16 Price: Call Us |
| 11 |
83-1550 |
SPACER-TUBE, SHORT Price: $7.73 |
| 12 |
71070512 |
Screw Hex 5/16-18 x 3/4 Price: Call Us |
| 12 |
83-1470 |
WASHER-NEOPRENE Price: $1.97 |
| 13 |
165291 |
Gasket Muffler Price: Call Us |
| 13 |
3256-71 |
WASHER-FLAT Price: $0.81 |
| 14 |
13280336 |
Nipple Pipe 3/8 NPT x 4-1/2 Price: Call Us |
| 14 |
322-14 |
SCREW-HH Price: $1.01 |
| 15 |
13200300 |
Elbow STD 90 Degree 3/8-18 Price: Call Us |
| 15 |
136-8547 |
LEAK DETECTOR TANK KIT This part replaces 83-2100. Price: $724.57 |
| 16 |
11050600 |
Washer Lock Ext Tooth 3/8 Price: Call Us |
| 16 |
68-6150 |
BREATHER Price: $27.22 |
| 17 |
17060624 |
Screw 3/8-16 x 1-1/2 Price: Call Us |
| 17 |
322-29 |
SCREW-HH Price: $2.69 |
| 18 |
83-1560 |
SPACER-TUBE, LONG Price: $8.33 |
| 21 |
354-120 |
FITTING-ELBOW, 90 Price: $30.04 |
| 22 |
321-11 |
SCREW-HH Price: $0.36 |
| 23 |
169837 |
Shield Brn/Dbr Guard Price: Call Us |
| 23 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 24 |
161-4678 |
SOLENOID VALVE ASM This part replaces 83-1460. Price: $932.37 |
| 25 |
139-2716 |
HOSE-FORMED This part replaces 83-2090. Price: $11.29 |
| 25 |
145996 |
Control Choke Price: Call Us |
| 26 |
73920600 |
Nut Keps 3/8-24 Unf Price: Call Us |
| 26 |
83-2080 |
HOSE-VALVE, TANK Price: $8.76 |
| 27 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 28 |
83-0870 |
FITTING-HOSE, BARBED Price: $62.08 |
| 29 |
137180 |
Arrestor Spark Price: Call Us |
| 29 |
323-6 |
SCREW-HH Price: $0.66 |
| 30 |
63-8410 |
WASHER Price: $1.76 |
| 31 |
180645 |
Tank Fuel Front 2 00 Price: Call Us |
| 31 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 32 |
140527 |
Cap Fuel Price: Call Us |
| 32 |
83-2390 |
PAD-TANK Price: $18.44 |
| 33 |
123487X |
Clamp Hose Black Price: Call Us |
| 33 |
83-2400 |
SPACER Price: $6.31 |
| 34 |
321-2 |
SCREW-HH Price: $2.79 |
| 35 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 36 |
92-8020 |
ADAPTER-BREATHER Price: $10.50 |
| 37 |
137040 |
Line Fuel 20" Price: Call Us |
| 40 |
124028X |
Bushing Snap Nyl Blk Fuel Line Price: Call Us |
| 41 |
139277 |
Stem Tank Fuel Price: Call Us |
| 44 |
17670412 |
Screw Hex wsh Thdrol 1/4-20x3/4 Price: Call Us |
| 45 |
17000612 |
Screw Hex Wsh Thdrol 3/8-16 x 3/4 Price: Call Us |
| 46 |
19091416 |
Washer 9/32 X 7/8 X 16 Ga Price: Call Us |
| 81 |
73510400 |
Nut Keps Hex 1/4-20 Unc Price: Call Us |
